TGenericData Class Reference

#include <TGenericData.hxx>

Inheritance diagram for TGenericData:

Collaboration diagram for TGenericData:

Public Member Functions
	TGenericData (int bklen, int bktype, const char *name, void *pdata)
virtual	~TGenericData ()
const uint16_t *	GetData16 () const
const uint32_t *	GetData32 () const
const uint64_t *	GetData64 () const
const float *	GetFloat () const
const double *	GetDouble () const
const char *	GetChar () const
int	GetSize () const
int	GetType () const
std::string	GetName () const
void	Dump ()
	Dump the bank contents in an unstructured way.
virtual void	Print ()
	Print the bank contents in a structured way.

Private Attributes
int	fSize
	Size of the bank (in what units?)
int	fBankType
	Bank data type (MIDAS TID_xxx).
std::string	fBankName
	Bank name.
void *	fData

Detailed Description

A generic ABC for storing decoded data banks. Provides methods for accessing unstructured data. INherited classes will provide more user-friendly data access.

Definition at line 11 of file TGenericData.hxx.

Constructor & Destructor Documentation

TGenericData()

TGenericData::TGenericData ( int  bklen, int  bktype, const char *  name, void *  pdata  )

inline

Definition at line 15 of file TGenericData.hxx.

~TGenericData()

virtual TGenericData::~TGenericData ( )

inlinevirtual

Definition at line 21 of file TGenericData.hxx.

Member Function Documentation

Dump()

void TGenericData::Dump ( )

inline

Dump the bank contents in an unstructured way.

Definition at line 49 of file TGenericData.hxx.

Here is the call graph for this function:

Here is the caller graph for this function:

GetChar()

const char * TGenericData::GetChar ( ) const

inline

Definition at line 39 of file TGenericData.hxx.

GetData16()

const uint16_t * TGenericData::GetData16 ( ) const

inline

Definition at line 24 of file TGenericData.hxx.

Here is the caller graph for this function:

GetData32()

const uint32_t * TGenericData::GetData32 ( ) const

inline

Definition at line 27 of file TGenericData.hxx.

Here is the caller graph for this function:

GetData64()

const uint64_t * TGenericData::GetData64 ( ) const

inline

Definition at line 30 of file TGenericData.hxx.

Here is the caller graph for this function:

GetDouble()

const double * TGenericData::GetDouble ( ) const

inline

Definition at line 36 of file TGenericData.hxx.

GetFloat()

const float * TGenericData::GetFloat ( ) const

inline

Definition at line 33 of file TGenericData.hxx.

Here is the caller graph for this function:

GetName()

std::string TGenericData::GetName ( ) const

inline

Definition at line 46 of file TGenericData.hxx.

Here is the caller graph for this function:

GetSize()

int TGenericData::GetSize ( ) const

inline

Definition at line 42 of file TGenericData.hxx.

Here is the caller graph for this function:

GetType()

int TGenericData::GetType ( ) const

inline

Definition at line 44 of file TGenericData.hxx.

Print()

virtual void TGenericData::Print ( )

inlinevirtual

Print the bank contents in a structured way.

Reimplemented in TDT724RawData, TL2249Data, TMesytecData, TTRB3Data, TV1190Data, TV1720RawData, TV1730DppData, TV1730RawData, TV792Data, and TV792NData.

Definition at line 59 of file TGenericData.hxx.

Here is the call graph for this function:

Field Documentation

fBankName

std::string TGenericData::fBankName

private

Bank name.

Definition at line 72 of file TGenericData.hxx.

fBankType

int TGenericData::fBankType

private

Bank data type (MIDAS TID_xxx).

Definition at line 69 of file TGenericData.hxx.

fData

void* TGenericData::fData

private

Pointer to the unstructured data. The data itself is NOT owned by TGenericData.

Definition at line 76 of file TGenericData.hxx.

fSize

int TGenericData::fSize

private

Size of the bank (in what units?)

Definition at line 66 of file TGenericData.hxx.

---

The documentation for this class was generated from the following file:

• include/TGenericData.hxx
