ChannelMeasurement Class Reference

#include <TV1730DppData.hxx>

Collaboration diagram for ChannelMeasurement:

[legend]

List of all members.

Public Member Functions
bool	GetDualTraceEnabled ()
	See CAEN DPP manual for definition of all these variables.
bool	GetChargeEnabled ()
bool	GetTimeEnabled ()
bool	GetBaselineEnabled ()
bool	GetSamplesEnabled ()
int	GetNSamples ()
int	GetChannel ()
uint32_t	GetSample (int i)
	Get Errors.
void	AddSamples (std::vector< uint32_t > Samples)
Private Member Functions
	ChannelMeasurement (int chan, uint32_t iheader0, uint32_t iheader1)
	Constructor; need to pass in header and measurement.
Private Attributes
int	fChan
uint32_t	header0
uint32_t	header1
std::vector< uint32_t >	fSamples
Friends
class	TV1730DppData

---

Detailed Description

Class for each channel measurement For the definition of obscure variables see the CAEN V1730 manual (for DPP readout).

Definition at line 10 of file TV1730DppData.hxx.

---

Constructor & Destructor Documentation

ChannelMeasurement::ChannelMeasurement	(	int	chan,
		uint32_t	iheader0,
		uint32_t	iheader1
	)			[inline, private]

Constructor; need to pass in header and measurement.

Definition at line 50 of file TV1730DppData.hxx.

References fChan, header0, and header1.

                                                                    {
                fChan = chan;
                header0 = iheader0;
                header1 = iheader1;
        }

---

Member Function Documentation

void ChannelMeasurement::AddSamples

(

std::vector< uint32_t >

Samples

)

[inline]

Definition at line 39 of file TV1730DppData.hxx.

References fSamples.

Referenced by TV1730DppData::TV1730DppData().

                                                    {
                fSamples = Samples;
        }

Here is the caller graph for this function:

bool ChannelMeasurement::GetBaselineEnabled

(

)

[inline]

Definition at line 20 of file TV1730DppData.hxx.

References header1.

{return (header1 & 0x10000000) >> 28;}

int ChannelMeasurement::GetChannel

(

)

[inline]

Definition at line 30 of file TV1730DppData.hxx.

References fChan.

{ return fChan;}

bool ChannelMeasurement::GetChargeEnabled

(

)

[inline]

Definition at line 18 of file TV1730DppData.hxx.

References header1.

{return (header1 & 0x40000000) >> 30;}

bool ChannelMeasurement::GetDualTraceEnabled

(

)

[inline]

See CAEN DPP manual for definition of all these variables.

Definition at line 17 of file TV1730DppData.hxx.

References header1.

{return (header1 & 0x80000000) >> 31;}

int ChannelMeasurement::GetNSamples

(

)

[inline]

Definition at line 22 of file TV1730DppData.hxx.

References fSamples, and header1.

                         {
                int header_size = (header1 & 0xfff)*8;
                if(header_size != fSamples.size())
                        std::cerr << "v17390::ChannelMeasurement N samples doesn't match!!"
                                                                << header_size << " " << fSamples.size() <<std::endl;
                return header_size;
        }

uint32_t ChannelMeasurement::GetSample

(

int

i

)

[inline]

Get Errors.

Definition at line 33 of file TV1730DppData.hxx.

References fSamples.

                           {
                if(i >= 0 && i < fSamples.size())
                        return fSamples[i];
                return 9999999;
        }

bool ChannelMeasurement::GetSamplesEnabled

(

)

[inline]

Definition at line 21 of file TV1730DppData.hxx.

References header1.

{return (header1 & 0x08000000) >> 27;}

bool ChannelMeasurement::GetTimeEnabled

(

)

[inline]

Definition at line 19 of file TV1730DppData.hxx.

References header1.

{return (header1 & 0x20000000) >> 29;}

---

Friends And Related Function Documentation

friend class TV1730DppData [friend]

Definition at line 12 of file TV1730DppData.hxx.

---

Member Data Documentation

int ChannelMeasurement::fChan [private]

Definition at line 45 of file TV1730DppData.hxx.

Referenced by ChannelMeasurement(), and GetChannel().

std::vector<uint32_t> ChannelMeasurement::fSamples [private]

Definition at line 56 of file TV1730DppData.hxx.

Referenced by AddSamples(), GetNSamples(), and GetSample().

uint32_t ChannelMeasurement::header0 [private]

Definition at line 46 of file TV1730DppData.hxx.

Referenced by ChannelMeasurement().

uint32_t ChannelMeasurement::header1 [private]

Definition at line 47 of file TV1730DppData.hxx.

Referenced by ChannelMeasurement(), GetBaselineEnabled(), GetChargeEnabled(), GetDualTraceEnabled(), GetNSamples(), GetSamplesEnabled(), and GetTimeEnabled().

---

The documentation for this class was generated from the following file:

• libAnalyzer/TV1730DppData.hxx
