TMidasFile Class Reference

Reader for MIDAS .mid files. More...

#include <TMidasFile.h>

Collaboration diagram for TMidasFile:
Collaboration graph
[legend]

List of all members.

Public Member Functions

 TMidasFile ()
 default constructor
 ~TMidasFile ()
 destructor
bool Open (const char *filename)
 Open input file.
bool OutOpen (const char *filename)
 Open output file.
void Close ()
 Close input file.
void OutClose ()
 Close output file.
bool Read (TMidasEvent *event)
 Read one event from the file.
bool Write (TMidasEvent *event)
 Write one event to the output file.
const char * GetFilename () const
 Get the name of this file.
int GetLastErrno () const
 Get error value for the last file error.
const char * GetLastError () const
 Get error text for the last file error.
 TMidasFile ()
 default constructor
 ~TMidasFile ()
 destructor
bool Open (const char *filename)
 Open input file.
bool OutOpen (const char *filename)
 Open output file.
void Close ()
 Close input file.
void OutClose ()
 Close output file.
bool Read (TMidasEvent *event)
 Read one event from the file.
bool Write (TMidasEvent *event)
 Write one event to the output file.
const char * GetFilename () const
 Get the name of this file.
int GetLastErrno () const
 Get error value for the last file error.
const char * GetLastError () const
 Get error text for the last file error.

Protected Attributes

std::string fFilename
 name of the currently open file
std::string fOutFilename
 name of the currently open file
int fLastErrno
 errno from the last operation
std::string fLastError
 error string from last errno
bool fDoByteSwap
 "true" if file has to be byteswapped
int fFile
 open input file descriptor
void * fGzFile
 zlib compressed input file reader
void * fPoFile
 popen() input file reader
int fOutFile
 open output file descriptor
void * fOutGzFile
 zlib compressed output file reader

Detailed Description

Reader for MIDAS .mid files.

Definition at line 14 of file TMidasFile.h.

Constructor & Destructor Documentation

TMidasFile::TMidasFile (  )

default constructor

Definition at line 20 of file TMidasFile.cxx.

References fDoByteSwap, fFile, fGzFile, fLastErrno, fOutFile, fOutGzFile, and fPoFile.

00021 {
00022   uint32_t endian = 0x12345678;
00023
00024   fFile = -1;
00025   fGzFile = NULL;
00026   fPoFile = NULL;
00027   fLastErrno = 0;
00028
00029   fOutFile = -1;
00030   fOutGzFile = NULL;
00031
00032   fDoByteSwap = *(char*)(&endian) != 0x78;
00033 }

TMidasFile::~TMidasFile (  )

destructor

Definition at line 35 of file TMidasFile.cxx.

References Close(), and OutClose().

00036 {
00037   Close();
00038   OutClose();
00039 }

Here is the call graph for this function:

TMidasFile::TMidasFile (  )

default constructor

TMidasFile::~TMidasFile (  )

destructor

Member Function Documentation

void TMidasFile::Close (  )

Close input file.

void TMidasFile::Close (  )

Close input file.

Definition at line 374 of file TMidasFile.cxx.

References fFile, fFilename, fGzFile, and fPoFile.

Referenced by Open(), TRootanaEventLoop::ProcessMidasFile(), ProcessMidasFile(), and ~TMidasFile().

00375 {
00376   if (fPoFile)
00377     pclose((FILE*)fPoFile);
00378   fPoFile = NULL;
00379 #ifdef HAVE_ZLIB
00380   if (fGzFile)
00381     gzclose(*(gzFile*)fGzFile);
00382   fGzFile = NULL;
00383 #endif
00384   if (fFile > 0)
00385     close(fFile);
00386   fFile = -1;
00387   fFilename = "";
00388 }

Here is the caller graph for this function:

const char* TMidasFile::GetFilename (  )  const [inline]

Get the name of this file.

Definition at line 29 of file TMidasFile.h.

References fFilename.

const char* TMidasFile::GetFilename (  )  const [inline]

Get the name of this file.

Definition at line 29 of file TMidasFile.h.

References fFilename.

int TMidasFile::GetLastErrno (  )  const [inline]

Get error value for the last file error.

Definition at line 30 of file TMidasFile.h.

References fLastErrno.

int TMidasFile::GetLastErrno (  )  const [inline]

Get error value for the last file error.

Definition at line 30 of file TMidasFile.h.

References fLastErrno.

Referenced by ProcessMidasFile().

Here is the caller graph for this function:

const char* TMidasFile::GetLastError (  )  const [inline]

Get error text for the last file error.

Definition at line 31 of file TMidasFile.h.

References fLastError.

const char* TMidasFile::GetLastError (  )  const [inline]

Get error text for the last file error.

Definition at line 31 of file TMidasFile.h.

References fLastError.

Referenced by ProcessMidasFile().

Here is the caller graph for this function:

bool TMidasFile::Open ( const char *  filename  )

Open input file.

bool TMidasFile::Open ( const char *  filename  )

Open input file.

Open a midas .mid file with given file name.

Remote files can be accessed using these special file names:

  • pipein://command - read data produced by given command, see examples below
  • ssh://username@hostname/path/file.mid - read remote file through an ssh pipe
  • ssh://username@hostname/path/file.mid.gz and file.mid.bz2 - same for compressed files
  • dccp://path/file.mid (also file.mid.gz and file.mid.bz2) - read data from dcache, requires dccp in the PATH

Examples:

  • ./event_dump.exe /ladd/data9/t2km11/data/run02696.mid.gz - read normal compressed file
  • ./event_dump.exe ssh://ladd09//ladd/data9/t2km11/data/run02696.mid.gz - read compressed file through ssh to ladd09 (note double "/")
  • ./event_dump.exe pipein://"cat /ladd/data9/t2km11/data/run02696.mid.gz | gzip -dc" - read data piped from a command or script (note quotes)
  • ./event_dump.exe pipein://"gzip -dc /ladd/data9/t2km11/data/run02696.mid.gz" - another way to read compressed files
  • ./event_dump.exe dccp:///pnfs/triumf.ca/data/t2km11/aug2008/run02837.mid.gz - read file directly from a dcache pool (note triple "/")
Parameters:
[in] filename The file to open.
Returns:
"true" for succes, "false" for error, use GetLastError() to see why

Definition at line 50 of file TMidasFile.cxx.

References Close(), fFile, fFilename, fGzFile, fLastErrno, fLastError, fPoFile, hasSuffix(), and O_LARGEFILE.

Referenced by main(), TRootanaEventLoop::ProcessMidasFile(), and ProcessMidasFile().

00051 {
00052   /// Open a midas .mid file with given file name.
00053   ///
00054   /// Remote files can be accessed using these special file names:
00055   /// - pipein://command - read data produced by given command, see examples below
00056   /// - ssh://username\@hostname/path/file.mid - read remote file through an ssh pipe
00057   /// - ssh://username\@hostname/path/file.mid.gz and file.mid.bz2 - same for compressed files
00058   /// - dccp://path/file.mid (also file.mid.gz and file.mid.bz2) - read data from dcache, requires dccp in the PATH
00059   ///
00060   /// Examples:
00061   /// - ./event_dump.exe /ladd/data9/t2km11/data/run02696.mid.gz - read normal compressed file
00062   /// - ./event_dump.exe ssh://ladd09//ladd/data9/t2km11/data/run02696.mid.gz - read compressed file through ssh to ladd09 (note double "/")
00063   /// - ./event_dump.exe pipein://"cat /ladd/data9/t2km11/data/run02696.mid.gz | gzip -dc" - read data piped from a command or script (note quotes)
00064   /// - ./event_dump.exe pipein://"gzip -dc /ladd/data9/t2km11/data/run02696.mid.gz" - another way to read compressed files
00065   /// - ./event_dump.exe dccp:///pnfs/triumf.ca/data/t2km11/aug2008/run02837.mid.gz - read file directly from a dcache pool (note triple "/")
00066   ///
00067   /// \param [in] filename The file to open.
00068   /// \returns "true" for succes, "false" for error, use GetLastError() to see why
00069
00070   if (fFile > 0)
00071     Close();
00072
00073   fFilename = filename;
00074
00075   std::string pipe;
00076
00077   // Do we need these?
00078   //signal(SIGPIPE,SIG_IGN); // crash if reading from closed pipe
00079   //signal(SIGXFSZ,SIG_IGN); // crash if reading from file >2GB without O_LARGEFILE
00080
00081   if (strncmp(filename, "ssh://", 6) == 0)
00082     {
00083       const char* name = filename + 6;
00084       const char* s = strstr(name, "/");
00085
00086       if (s == NULL)
00087         {
00088           fLastErrno = -1;
00089           fLastError = "TMidasFile::Open: Invalid ssh:// URI. Should be: ssh://user@host/file/path/...";
00090           return false;
00091         }
00092
00093       const char* remoteFile = s + 1;
00094
00095       std::string remoteHost;
00096       for (s=name; *s != '/'; s++)
00097         remoteHost += *s;
00098
00099       pipe = "ssh -e none -T -x -n ";
00100       pipe += remoteHost;
00101       pipe += " dd if=";
00102       pipe += remoteFile;
00103       pipe += " bs=1024k";
00104
00105       if (hasSuffix(remoteFile,".gz"))
00106         pipe += " | gzip -dc";
00107       else if (hasSuffix(remoteFile,".bz2"))
00108         pipe += " | bzip2 -dc";
00109     }
00110   else if (strncmp(filename, "dccp://", 7) == 0)
00111     {
00112       const char* name = filename + 7;
00113
00114       pipe = "dccp ";
00115       pipe += name;
00116       pipe += " /dev/fd/1";
00117
00118       if (hasSuffix(filename,".gz"))
00119         pipe += " | gzip -dc";
00120       else if (hasSuffix(filename,".bz2"))
00121         pipe += " | bzip2 -dc";
00122     }
00123   else if (strncmp(filename, "pipein://", 9) == 0)
00124     {
00125       pipe = filename + 9;
00126     }
00127 #if 0 // read compressed files using the zlib library
00128   else if (hasSuffix(filename, ".gz"))
00129     {
00130       pipe = "gzip -dc ";
00131       pipe += filename;
00132     }
00133 #endif
00134   else if (hasSuffix(filename, ".bz2"))
00135     {
00136       pipe = "bzip2 -dc ";
00137       pipe += filename;
00138     }
00139
00140   if (pipe.length() > 0)
00141     {
00142       fprintf(stderr,"TMidasFile::Open: Reading from pipe: %s\n", pipe.c_str());
00143
00144       fPoFile = popen(pipe.c_str(), "r");
00145
00146       if (fPoFile == NULL)
00147         {
00148           fLastErrno = errno;
00149           fLastError = strerror(errno);
00150           return false;
00151         }
00152
00153       fFile = fileno((FILE*)fPoFile);
00154     }
00155   else
00156     {
00157 #ifndef O_LARGEFILE
00158 #define O_LARGEFILE 0
00159 #endif
00160
00161       fFile = open(filename, O_RDONLY | O_LARGEFILE);
00162
00163       if (fFile <= 0)
00164         {
00165           fLastErrno = errno;
00166           fLastError = strerror(errno);
00167           return false;
00168         }
00169
00170       if (hasSuffix(filename, ".gz"))
00171         {
00172           // this is a compressed file
00173 #ifdef HAVE_ZLIB
00174           fGzFile = new gzFile;
00175           (*(gzFile*)fGzFile) = gzdopen(fFile,"rb");
00176           if ((*(gzFile*)fGzFile) == NULL)
00177             {
00178               fLastErrno = -1;
00179               fLastError = "zlib gzdopen() error";
00180               return false;
00181             }
00182 #else
00183           fLastErrno = -1;
00184           fLastError = "Do not know how to read compressed MIDAS files";
00185           return false;
00186 #endif
00187         }
00188     }
00189
00190   return true;
00191 }

Here is the call graph for this function:

Here is the caller graph for this function:

void TMidasFile::OutClose (  )

Close output file.

void TMidasFile::OutClose (  )

Close output file.

Definition at line 390 of file TMidasFile.cxx.

References fOutFile, fOutFilename, and fOutGzFile.

Referenced by OutOpen(), ProcessMidasFile(), and ~TMidasFile().

00391 {
00392 #ifdef HAVE_ZLIB
00393   if (fOutGzFile) {
00394     gzflush(*(gzFile*)fOutGzFile, Z_FULL_FLUSH);
00395     gzclose(*(gzFile*)fOutGzFile);
00396   }
00397   fOutGzFile = NULL;
00398 #endif
00399   if (fOutFile > 0)
00400     close(fOutFile);
00401   fOutFile = -1;
00402   fOutFilename = "";
00403 }

Here is the caller graph for this function:

bool TMidasFile::OutOpen ( const char *  filename  )

Open output file.

bool TMidasFile::OutOpen ( const char *  filename  )

Open output file.

Open a midas .mid file for OUTPUT with given file name.

Remote files not yet implemented

Parameters:
[in] filename The file to open.
Returns:
"true" for succes, "false" for error, use GetLastError() to see why

Definition at line 193 of file TMidasFile.cxx.

References fLastErrno, fLastError, fOutFile, fOutFilename, fOutGzFile, hasSuffix(), O_LARGEFILE, and OutClose().

Referenced by ProcessMidasFile().

00194 {
00195   /// Open a midas .mid file for OUTPUT with given file name.
00196   ///
00197   /// Remote files not yet implemented
00198   ///
00199   /// \param [in] filename The file to open.
00200   /// \returns "true" for succes, "false" for error, use GetLastError() to see why
00201
00202   if (fOutFile > 0)
00203     OutClose();
00204
00205   fOutFilename = filename;
00206
00207   printf ("Attempting normal open of file %s\n", filename);
00208   //fOutFile = open(filename, O_CREAT |  O_WRONLY | O_LARGEFILE , S_IRUSR| S_IWUSR | S_IRGRP | S_IROTH );
00209   //fOutFile = open(filename, O_WRONLY | O_CREAT | O_TRUNC | O_BINARY | O_LARGEFILE, 0644);
00210   fOutFile = open (filename, O_WRONLY | O_CREAT | O_TRUNC | O_LARGEFILE, 0644);
00211
00212   if (fOutFile <= 0)
00213     {
00214       fLastErrno = errno;
00215       fLastError = strerror(errno);
00216       return false;
00217     }
00218
00219   printf("Opened output file %s ; return fOutFile is %i\n",filename,fOutFile);
00220
00221   if (hasSuffix(filename, ".gz"))
00222     // (hasSuffix(filename, ".dummy"))
00223     {
00224       // this is a compressed file
00225 #ifdef HAVE_ZLIB
00226       fOutGzFile = new gzFile;
00227       *(gzFile*)fOutGzFile = gzdopen(fOutFile,"wb");
00228       if ((*(gzFile*)fOutGzFile) == NULL)
00229         {
00230           fLastErrno = -1;
00231           fLastError = "zlib gzdopen() error";
00232           return false;
00233         }
00234       printf("Opened gz file successfully\n");
00235       if (1)
00236         {
00237           if (gzsetparams(*(gzFile*)fOutGzFile, 1, Z_DEFAULT_STRATEGY) != Z_OK) {
00238             printf("Cannot set gzparams\n");
00239             fLastErrno = -1;
00240             fLastError = "zlib gzsetparams() error";
00241             return false;
00242           }
00243           printf("setparams for gz file successfully\n");
00244         }
00245 #else
00246       fLastErrno = -1;
00247       fLastError = "Do not know how to write compressed MIDAS files";
00248       return false;
00249 #endif
00250     }
00251   return true;
00252 }

Here is the call graph for this function:

Here is the caller graph for this function:

bool TMidasFile::Read ( TMidasEvent *  event  )

Read one event from the file.

bool TMidasFile::Read ( TMidasEvent *  event  )

Read one event from the file.

Parameters:
[in] midasEvent Pointer to an empty TMidasEvent
Returns:
"true" for success, "false" for failure, see GetLastError() to see why

Definition at line 279 of file TMidasFile.cxx.

References TMidasEvent::Clear(), fDoByteSwap, fFile, fGzFile, fLastErrno, fLastError, TMidasEvent::GetData(), TMidasEvent::GetDataSize(), TMidasEvent::GetEventHeader(), TMidasEvent::IsGoodSize(), readpipe(), TMidasEvent::SwapBytes(), and TMidasEvent::SwapBytesEventHeader().

Referenced by main(), TRootanaEventLoop::ProcessMidasFile(), and ProcessMidasFile().

00280 {
00281   /// \param [in] midasEvent Pointer to an empty TMidasEvent
00282   /// \returns "true" for success, "false" for failure, see GetLastError() to see why
00283
00284   midasEvent->Clear();
00285
00286   int rd = 0;
00287
00288   if (fGzFile)
00289 #ifdef HAVE_ZLIB
00290     rd = gzread(*(gzFile*)fGzFile, (char*)midasEvent->GetEventHeader(), sizeof(TMidas_EVENT_HEADER));
00291 #else
00292     assert(!"Cannot get here");
00293 #endif
00294   else
00295     rd = readpipe(fFile, (char*)midasEvent->GetEventHeader(), sizeof(TMidas_EVENT_HEADER));
00296
00297   if (rd == 0)
00298     {
00299       fLastErrno = 0;
00300       fLastError = "EOF";
00301       return false;
00302     }
00303   else if (rd != sizeof(TMidas_EVENT_HEADER))
00304     {
00305       fLastErrno = errno;
00306       fLastError = strerror(errno);
00307       return false;
00308     }
00309
00310   if (fDoByteSwap)
00311     midasEvent->SwapBytesEventHeader();
00312
00313   if (!midasEvent->IsGoodSize())
00314     {
00315       fLastErrno = -1;
00316       fLastError = "Invalid event size";
00317       return false;
00318     }
00319
00320   if (fGzFile)
00321 #ifdef HAVE_ZLIB
00322     rd = gzread(*(gzFile*)fGzFile, midasEvent->GetData(), midasEvent->GetDataSize());
00323 #else
00324     assert(!"Cannot get here");
00325 #endif
00326   else
00327     rd = readpipe(fFile, midasEvent->GetData(), midasEvent->GetDataSize());
00328
00329   if (rd != (int)midasEvent->GetDataSize())
00330     {
00331       fLastErrno = errno;
00332       fLastError = strerror(errno);
00333       return false;
00334     }
00335
00336   midasEvent->SwapBytes(false);
00337
00338   return true;
00339 }

Here is the call graph for this function:

Here is the caller graph for this function:

bool TMidasFile::Write ( TMidasEvent *  event  )

Write one event to the output file.

bool TMidasFile::Write ( TMidasEvent *  event  )

Write one event to the output file.

Definition at line 341 of file TMidasFile.cxx.

References fOutFile, fOutGzFile, TMidasEvent::GetData(), TMidasEvent::GetDataSize(), and TMidasEvent::GetEventHeader().

Referenced by ProcessMidasFile().

00342 {
00343   int wr = -2;
00344
00345   if (fOutGzFile)
00346 #ifdef HAVE_ZLIB
00347     wr = gzwrite(*(gzFile*)fOutGzFile, (char*)midasEvent->GetEventHeader(), sizeof(TMidas_EVENT_HEADER));
00348 #else
00349     assert(!"Cannot get here");
00350 #endif
00351   else
00352     wr = write(fOutFile, (char*)midasEvent->GetEventHeader(), sizeof(TMidas_EVENT_HEADER));
00353
00354   if(wr !=  sizeof(TMidas_EVENT_HEADER)){
00355     printf("TMidasFile: error on write event header, return %i, size requested %lu\n",wr,sizeof(TMidas_EVENT_HEADER));
00356     return false;
00357   }
00358
00359   printf("Written event header to outfile , return is %i\n",wr);
00360
00361   if (fOutGzFile)
00362 #ifdef HAVE_ZLIB
00363     wr = gzwrite(*(gzFile*)fOutGzFile, (char*)midasEvent->GetData(), midasEvent->GetDataSize());
00364 #else
00365     assert(!"Cannot get here");
00366 #endif
00367   else
00368     wr = write(fOutFile, (char*)midasEvent->GetData(), midasEvent->GetDataSize());
00369   printf("Written event to outfile , return is %d\n",wr);
00370
00371   return wr;
00372 }

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

bool TMidasFile::fDoByteSwap [protected]

"true" if file has to be byteswapped

Definition at line 41 of file TMidasFile.h.

Referenced by Read(), and TMidasFile().

int TMidasFile::fFile [protected]

open input file descriptor

Definition at line 43 of file TMidasFile.h.

Referenced by Close(), Open(), Read(), and TMidasFile().

std::string TMidasFile::fFilename [protected]

name of the currently open file

Definition at line 35 of file TMidasFile.h.

Referenced by Close(), GetFilename(), and Open().

void * TMidasFile::fGzFile [protected]

zlib compressed input file reader

Definition at line 44 of file TMidasFile.h.

Referenced by Close(), Open(), Read(), and TMidasFile().

int TMidasFile::fLastErrno [protected]

errno from the last operation

Definition at line 38 of file TMidasFile.h.

Referenced by GetLastErrno(), Open(), OutOpen(), Read(), and TMidasFile().

std::string TMidasFile::fLastError [protected]

error string from last errno

Definition at line 39 of file TMidasFile.h.

Referenced by GetLastError(), Open(), OutOpen(), and Read().

int TMidasFile::fOutFile [protected]

open output file descriptor

Definition at line 46 of file TMidasFile.h.

Referenced by OutClose(), OutOpen(), TMidasFile(), and Write().

std::string TMidasFile::fOutFilename [protected]

name of the currently open file

Definition at line 36 of file TMidasFile.h.

Referenced by OutClose(), and OutOpen().

void * TMidasFile::fOutGzFile [protected]

zlib compressed output file reader

Definition at line 47 of file TMidasFile.h.

Referenced by OutClose(), OutOpen(), TMidasFile(), and Write().

void * TMidasFile::fPoFile [protected]

popen() input file reader

Definition at line 45 of file TMidasFile.h.

Referenced by Close(), Open(), and TMidasFile().

The documentation for this class was generated from the following files:
Generated on 5 May 2014 for ROOT Analyzer by  doxygen 1.6.1
