TMidasOnline Class Reference

MIDAS online connection, including access to online ODB. More...

#include <TMidasOnline.h>

Inheritance diagram for TMidasOnline:

[legend]

Collaboration diagram for TMidasOnline:

[legend]

List of all members.

Public Types
typedef void(*	TransitionHandler )(int transition, int run_number, int trans_time)
	User handler for run state transition events.
typedef void(*	EventHandler )(const void header, const void data, int length)
	User handler for data events.
typedef void(*	TransitionHandler )(int transition, int run_number, int trans_time)
	User handler for run state transition events.
typedef void(*	EventHandler )(const void header, const void data, int length)
	User handler for data events.
Public Member Functions
int	connect (const char hostname, const char exptname, const char *progname)
	Connect to MIDAS experiment.
int	disconnect ()
	Disconnect from MIDAS.
bool	poll (int mdelay)
	Check for MIDAS events (run transitions, data requests).
void	registerTransitions ()
	Ask MIDAS to tell us about run transitions.
void	setTransitionHandlers (TransitionHandler start, TransitionHandler stop, TransitionHandler pause, TransitionHandler resume)
	Specify user handlers for run transitions.
bool	checkTransitions ()
	Check for pending transitions, call user handlers. Returns "true" if there were transitions.
void	setEventHandler (EventHandler handler)
	Specify user handler for data events.
int	eventRequest (const char *bufferName, int eventId, int triggerMask, int samplingType, bool poll=false)
	Request data for delivery via callback (setEventHandler) or by polling (via receiveEvent).
void	deleteEventRequest (int requestId)
	Delete data request.
int	receiveEvent (int requestId, void *pevent, int size, bool async)
	Receive event by polling.
int	getBufferLevel ()
	Get buffer level (ie the number of bytes in buffer).
int	getBufferSize ()
	Get buffer size.
int	odbReadArraySize (const char *name)
	Read size of an array.
int	odbReadAny (const char name, int index, int tid, void buf, int bufsize=0)
	Read value of arbitrary type.
int	odbReadInt (const char *name, int index=0, int defaultValue=0)
	Read an integer value, midas type TID_INT.
uint32_t	odbReadUint32 (const char *name, int index=0, uint32_t defaultValue=0)
	Read an unsigned 32-bit integer value, midas type TID_DWORD.
double	odbReadDouble (const char *name, int index=0, double defaultValue=0)
	Read an 64-bit floating point value, midas type TID_DOUBLET.
float	odbReadFloat (const char *name, int index=0, float defaultValue=0)
	Read an 32-bit floating point value, midas type TID_FLOAT.
bool	odbReadBool (const char *name, int index=0, bool defaultValue=false)
	Read a boolean value, midas type TID_BOOL.
const char *	odbReadString (const char name, int index=0, const char defaultValue=NULL)
	Read a string value, midas type TID_STRING.
int	connect (const char hostname, const char exptname, const char *progname)
	Connect to MIDAS experiment.
int	disconnect ()
	Disconnect from MIDAS.
bool	poll (int mdelay)
	Check for MIDAS events (run transitions, data requests).
void	registerTransitions ()
	Ask MIDAS to tell us about run transitions.
void	setTransitionHandlers (TransitionHandler start, TransitionHandler stop, TransitionHandler pause, TransitionHandler resume)
	Specify user handlers for run transitions.
bool	checkTransitions ()
	Check for pending transitions, call user handlers. Returns "true" if there were transitions.
void	setEventHandler (EventHandler handler)
	Specify user handler for data events.
int	eventRequest (const char *bufferName, int eventId, int triggerMask, int samplingType, bool poll=false)
	Request data for delivery via callback (setEventHandler) or by polling (via receiveEvent).
void	deleteEventRequest (int requestId)
	Delete data request.
int	receiveEvent (int requestId, void *pevent, int size, bool async)
	Receive event by polling.
int	getBufferLevel ()
	Get buffer level (ie the number of bytes in buffer).
int	getBufferSize ()
	Get buffer size.
int	odbReadArraySize (const char *name)
	Read size of an array.
int	odbReadAny (const char name, int index, int tid, void buf, int bufsize=0)
	Read value of arbitrary type.
int	odbReadInt (const char *name, int index=0, int defaultValue=0)
	Read an integer value, midas type TID_INT.
uint32_t	odbReadUint32 (const char *name, int index=0, uint32_t defaultValue=0)
	Read an unsigned 32-bit integer value, midas type TID_DWORD.
double	odbReadDouble (const char *name, int index=0, double defaultValue=0)
	Read an 64-bit floating point value, midas type TID_DOUBLET.
float	odbReadFloat (const char *name, int index=0, float defaultValue=0)
	Read an 32-bit floating point value, midas type TID_FLOAT.
bool	odbReadBool (const char *name, int index=0, bool defaultValue=false)
	Read a boolean value, midas type TID_BOOL.
const char *	odbReadString (const char name, int index=0, const char defaultValue=NULL)
	Read a string value, midas type TID_STRING.
Static Public Member Functions
static TMidasOnline *	instance ()
static TMidasOnline *	instance ()
Public Attributes
std::string	fHostname
	hostname where the mserver is running, blank if using shared memory
std::string	fExptname
	experiment name, blank if only one experiment defined in exptab
int	fDB
	ODB handle.
TransitionHandler	fStartHandler
TransitionHandler	fStopHandler
TransitionHandler	fPauseHandler
TransitionHandler	fResumeHandler
EventRequest *	fEventRequests
EventHandler	fEventHandler
Private Member Functions
	TMidasOnline ()
	default constructor is private for singleton classes
virtual	~TMidasOnline ()
	destructor is private for singleton classes
	TMidasOnline ()
	default constructor is private for singleton classes
virtual	~TMidasOnline ()
	destructor is private for singleton classes
Static Private Attributes
static TMidasOnline *	gfMidas = NULL

Detailed Description

MIDAS online connection, including access to online ODB.

Definition at line 36 of file TMidasOnline.h.

Member Typedef Documentation

typedef void(* TMidasOnline::EventHandler)(const void *header, const void *data, int length)

User handler for data events.

Definition at line 44 of file TMidasOnline.h.

typedef void(* TMidasOnline::EventHandler)(const void *header, const void *data, int length)

User handler for data events.

Definition at line 44 of file TMidasOnline.h.

typedef void(* TMidasOnline::TransitionHandler)(int transition, int run_number, int trans_time)

User handler for run state transition events.

Definition at line 41 of file TMidasOnline.h.

typedef void(* TMidasOnline::TransitionHandler)(int transition, int run_number, int trans_time)

User handler for run state transition events.

Definition at line 41 of file TMidasOnline.h.

Constructor & Destructor Documentation

TMidasOnline::TMidasOnline ( ) [private]

default constructor is private for singleton classes

Definition at line 22 of file TMidasOnline.cxx.

References fDB, fEventHandler, fEventRequests, fPauseHandler, fResumeHandler, fStartHandler, and fStopHandler.

Referenced by instance().

00023 {
00024   fDB = 0;
00025   fStartHandler  = 0;
00026   fStopHandler   = 0;
00027   fPauseHandler  = 0;
00028   fResumeHandler = 0;
00029   fEventRequests = 0;
00030   fEventHandler  = 0;
00031 }

Here is the caller graph for this function:

TMidasOnline::~TMidasOnline ( ) [private, virtual]

destructor is private for singleton classes

Definition at line 33 of file TMidasOnline.cxx.

References disconnect().

00034 {
00035   disconnect();
00036 }

Here is the call graph for this function:

TMidasOnline::TMidasOnline ( ) [private]

default constructor is private for singleton classes

virtual TMidasOnline::~TMidasOnline ( ) [private, virtual]

destructor is private for singleton classes

Member Function Documentation

bool TMidasOnline::checkTransitions ( )

Check for pending transitions, call user handlers. Returns "true" if there were transitions.

bool TMidasOnline::checkTransitions ( )

Check for pending transitions, call user handlers. Returns "true" if there were transitions.

Definition at line 120 of file TMidasOnline.cxx.

References fPauseHandler, fResumeHandler, fStartHandler, and fStopHandler.

Referenced by poll().

00121 {
00122   int transition, run_number, trans_time;
00123
00124   int status = cm_query_transition(&transition, &run_number, &trans_time);
00125   if (status != CM_SUCCESS)
00126     return false;
00127
00128   //printf("cm_query_transition: status %d, tr %d, run %d, time %d\n",status,transition,run_number,trans_time);
00129
00130   if (transition == TR_START)
00131     {
00132       if (fStartHandler)
00133         (*fStartHandler)(transition,run_number,trans_time);
00134       return true;
00135     }
00136   else if (transition == TR_STOP)
00137     {
00138       if (fStopHandler)
00139         (*fStopHandler)(transition,run_number,trans_time);
00140       return true;
00141
00142     }
00143   else if (transition == TR_PAUSE)
00144     {
00145       if (fPauseHandler)
00146         (*fPauseHandler)(transition,run_number,trans_time);
00147       return true;
00148
00149     }
00150   else if (transition == TR_RESUME)
00151     {
00152       if (fResumeHandler)
00153         (*fResumeHandler)(transition,run_number,trans_time);
00154       return true;
00155     }
00156
00157   return false;
00158 }

Here is the caller graph for this function:

int TMidasOnline::connect	(	const char *	hostname,
		const char *	exptname,
		const char *	progname
	)

Connect to MIDAS experiment.

int TMidasOnline::connect	(	const char *	hostname,
		const char *	exptname,
		const char *	progname
	)

Connect to MIDAS experiment.

Definition at line 46 of file TMidasOnline.cxx.

References fDB, fExptname, and fHostname.

Referenced by main().

00047 {
00048   int status;
00049
00050   char xhostname[HOST_NAME_LENGTH];
00051   char xexptname[NAME_LENGTH];
00052
00053   /* get default from environment */
00054   status = cm_get_environment(xhostname, sizeof(xhostname), xexptname, sizeof(xexptname));
00055   assert(status == CM_SUCCESS);
00056
00057   if (hostname)
00058     strlcpy(xhostname,hostname,sizeof(xhostname));
00059
00060   if (exptname)
00061     strlcpy(xexptname,exptname,sizeof(xexptname));
00062
00063   fHostname = xhostname;
00064   fExptname = xexptname;
00065
00066   fprintf(stderr, "TMidasOnline::connect: Connecting to experiment \"%s\" on host \"%s\"\n", fExptname.c_str(), fHostname.c_str());
00067
00068   //int watchdog = DEFAULT_WATCHDOG_TIMEOUT;
00069   int watchdog = 60*1000;
00070
00071   status = cm_connect_experiment1((char*)fHostname.c_str(), (char*)fExptname.c_str(), (char*)progname, NULL, DEFAULT_ODB_SIZE, watchdog);
00072
00073   if (status == CM_UNDEF_EXP)
00074     {
00075       fprintf(stderr, "TMidasOnline::connect: Error: experiment \"%s\" not defined.\n", fExptname.c_str());
00076       return -1;
00077     }
00078   else if (status != CM_SUCCESS)
00079     {
00080       fprintf(stderr, "TMidasOnline::connect: Cannot connect to MIDAS, status %d.\n", status);
00081       return -1;
00082     }
00083
00084   status = cm_get_experiment_database(&fDB, NULL);
00085   assert(status == CM_SUCCESS);
00086
00087   cm_set_watchdog_params(true, 60*1000);
00088
00089   return 0;
00090 }

Here is the caller graph for this function:

void TMidasOnline::deleteEventRequest ( int requestId )

Delete data request.

void TMidasOnline::deleteEventRequest ( int requestId )

Delete data request.

Definition at line 312 of file TMidasOnline.cxx.

References fEventRequests, and EventRequest::fNext.

00313 {
00314   for (EventRequest* r = fEventRequests; r != NULL; r = r->fNext)
00315     if (r->fRequestId == requestId)
00316       {
00317         int status = bm_delete_request(r->fRequestId);
00318         assert(status == BM_SUCCESS);
00319
00320         r->fBufferHandle = -1;
00321         r->fRequestId    = -1;
00322       }
00323 }

int TMidasOnline::disconnect ( )

Disconnect from MIDAS.

int TMidasOnline::disconnect ( )

Disconnect from MIDAS.

Definition at line 92 of file TMidasOnline.cxx.

References fDB, fExptname, and fHostname.

Referenced by poll(), and ~TMidasOnline().

00093 {
00094   if (fDB)
00095     {
00096       fprintf(stderr, "TMidasOnline::disconnect: Disconnecting from experiment \"%s\" on host \"%s\"\n", fExptname.c_str(), fHostname.c_str());
00097       cm_disconnect_experiment();
00098       fDB = 0;
00099     }
00100
00101   return 0;
00102 }

Here is the caller graph for this function:

int TMidasOnline::eventRequest	(	const char *	bufferName,
		int	eventId,
		int	triggerMask,
		int	samplingType,
		bool	poll = `false`
	)

Request data for delivery via callback (setEventHandler) or by polling (via receiveEvent).

int TMidasOnline::eventRequest	(	const char *	bufferName,
		int	eventId,
		int	triggerMask,
		int	samplingType,
		bool	poll = `false`
	)

Request data for delivery via callback (setEventHandler) or by polling (via receiveEvent).

Definition at line 250 of file TMidasOnline.cxx.

References EVENT_BUFFER_SIZE, eventCallback(), EventRequest::fBufferHandle, EventRequest::fBufferName, EventRequest::fEventId, fEventRequests, EventRequest::fNext, EventRequest::fRequestId, EventRequest::fSamplingType, and EventRequest::fTriggerMask.

00251 {
00252   int status;
00253   EventRequest* r = new EventRequest();
00254
00255   if (bufferName == NULL)
00256     bufferName = EVENT_BUFFER_NAME;
00257
00258   r->fNext         = NULL;
00259   r->fBufferName   = bufferName;
00260   r->fEventId      = eventId;
00261   r->fTriggerMask  = triggerMask;
00262   r->fSamplingType = samplingType;
00263
00264
00265   /*---- open event buffer ---------------------------------------*/
00266   status = bm_open_buffer((char*)bufferName, EVENT_BUFFER_SIZE, &r->fBufferHandle);
00267   if (status!=SUCCESS && status!=BM_CREATED)
00268     {
00269       fprintf(stderr, "TMidasOnline::eventRequest: Cannot find data buffer \"%s\", bm_open_buffer() error %d\n", bufferName, status);
00270       return -1;
00271     }
00272
00273   /* set the default buffer cache size */
00274   status = bm_set_cache_size(r->fBufferHandle, 100000, 0);
00275   assert(status == BM_SUCCESS);
00276
00277   if (poll)
00278     status = bm_request_event(r->fBufferHandle, r->fEventId, r->fTriggerMask, r->fSamplingType, &r->fRequestId, NULL);
00279   else
00280     status = bm_request_event(r->fBufferHandle, r->fEventId, r->fTriggerMask, r->fSamplingType, &r->fRequestId, eventCallback);
00281   assert(status == BM_SUCCESS);
00282
00283   fprintf(stderr, "TMidasOnline::eventRequest: Event request: buffer \"%s\" (%d), event id 0x%x, trigger mask 0x%x, sample %d, request id: %d\n",bufferName,r->fBufferHandle,r->fEventId,r->fTriggerMask,r->fSamplingType,r->fRequestId);
00284
00285   r->fNext = fEventRequests;
00286   fEventRequests = r;
00287
00288   return r->fRequestId;
00289 };

Here is the call graph for this function:

int TMidasOnline::getBufferLevel ( )

Get buffer level (ie the number of bytes in buffer).

int TMidasOnline::getBufferLevel ( )

Get buffer level (ie the number of bytes in buffer).

Definition at line 291 of file TMidasOnline.cxx.

References EventRequest::fBufferHandle, and fEventRequests.

00291                                 {
00292
00293   if(!fEventRequests || !fEventRequests->fBufferHandle) return -1;
00294
00295   int n_bytes;
00296   bm_get_buffer_level(fEventRequests->fBufferHandle, &n_bytes);
00297
00298   return n_bytes;
00299
00300 }

int TMidasOnline::getBufferSize ( )

Get buffer size.

int TMidasOnline::getBufferSize ( )

Get buffer size.

Definition at line 302 of file TMidasOnline.cxx.

References EventRequest::fBufferHandle, and fEventRequests.

00302                                {
00303
00304   if(!fEventRequests || !fEventRequests->fBufferHandle) return -1;
00305
00306   BUFFER_HEADER buffer_header;
00307   bm_get_buffer_info(fEventRequests->fBufferHandle,&buffer_header);
00308
00309   return buffer_header.size;
00310
00311 }

static TMidasOnline* TMidasOnline::instance ( ) [static]

TMidasOnline is a singleton class. Call instance() to get a reference to the one instance of this class.

TMidasOnline * TMidasOnline::instance ( ) [static]

TMidasOnline is a singleton class. Call instance() to get a reference to the one instance of this class.

Definition at line 38 of file TMidasOnline.cxx.

References gfMidas, and TMidasOnline().

Referenced by eventCallback(), and main().

00039 {
00040   if (!gfMidas)
00041     gfMidas = new TMidasOnline();
00042
00043   return gfMidas;
00044 }

Here is the call graph for this function:

Here is the caller graph for this function:

int TMidasOnline::odbReadAny	(	const char *	name,
		int	index,
		int	tid,
		void *	buf,
		int	bufsize = `0`
	)			`[virtual]`

Read value of arbitrary type.

Implements VirtualOdb.

int TMidasOnline::odbReadAny	(	const char *	name,
		int	index,
		int	tid,
		void *	buf,
		int	bufsize = `0`
	)			`[virtual]`

Read value of arbitrary type.

Implements VirtualOdb.

Definition at line 401 of file TMidasOnline.cxx.

References fDB.

Referenced by odbReadBool(), odbReadDouble(), odbReadFloat(), odbReadInt(), odbReadString(), and odbReadUint32().

00402 {
00403   int status;
00404   int size = bufsize;
00405   HNDLE hdir = 0;
00406   HNDLE hkey;
00407
00408   if (size == 0)
00409     size = rpc_tid_size(tid);
00410
00411   status = db_find_key (fDB, hdir, (char*)name, &hkey);
00412   if (status == SUCCESS)
00413     {
00414       status = db_get_data_index(fDB, hkey, buf, &size, index, tid);
00415       if (status != SUCCESS)
00416         {
00417           cm_msg(MERROR, "TMidasOnline", "Cannot read \'%s\'[%d] of type %d from odb, db_get_data_index() status %d", name, index, tid, status);
00418           return -1;
00419         }
00420
00421       return 0;
00422     }
00423   else if (status == DB_NO_KEY)
00424     {
00425       cm_msg(MINFO, "TMidasOnline", "Creating \'%s\'[%d] of type %d", name, index, tid);
00426
00427       status = db_create_key(fDB, hdir, (char*)name, tid);
00428       if (status != SUCCESS)
00429         {
00430           cm_msg (MERROR, "TMidasOnline", "Cannot create \'%s\' of type %d, db_create_key() status %d", name, tid, status);
00431           return -1;
00432         }
00433
00434       status = db_find_key (fDB, hdir, (char*)name, &hkey);
00435       if (status != SUCCESS)
00436         {
00437           cm_msg(MERROR, "TMidasOnline", "Cannot create \'%s\', db_find_key() status %d", name, status);
00438           return -1;
00439         }
00440
00441       status = db_set_data_index(fDB, hkey, buf, size, index, tid);
00442       if (status != SUCCESS)
00443         {
00444           cm_msg(MERROR, "TMidasOnline", "Cannot write \'%s\'[%d] of type %d to odb, db_set_data_index() status %d", name, index, tid, status);
00445           return -1;
00446         }
00447
00448       return 0;
00449     }
00450   else
00451     {
00452       cm_msg(MERROR, "TMidasOnline", "Cannot read \'%s\'[%d] from odb, db_find_key() status %d", name, index, status);
00453       return -1;
00454     }
00455 };

Here is the caller graph for this function:

int TMidasOnline::odbReadArraySize ( const char * name ) [virtual]

Read size of an array.

Implements VirtualOdb.

int TMidasOnline::odbReadArraySize ( const char * name ) [virtual]

Read size of an array.

Implements VirtualOdb.

Definition at line 383 of file TMidasOnline.cxx.

References fDB.

00384 {
00385   int status;
00386   HNDLE hdir = 0;
00387   HNDLE hkey;
00388   KEY key;
00389
00390   status = db_find_key (fDB, hdir, (char*)name, &hkey);
00391   if (status != SUCCESS)
00392     return 0;
00393
00394   status = db_get_key(fDB, hkey, &key);
00395   if (status != SUCCESS)
00396     return 0;
00397
00398   return key.num_values;
00399 }

bool TMidasOnline::odbReadBool	(	const char *	name,
		int	index = `0`,
		bool	defaultValue = `false`
	)			`[virtual]`

Read a boolean value, midas type TID_BOOL.

Implements VirtualOdb.

bool TMidasOnline::odbReadBool	(	const char *	name,
		int	index = `0`,
		bool	defaultValue = `false`
	)			`[virtual]`

Read a boolean value, midas type TID_BOOL.

Implements VirtualOdb.

Definition at line 346 of file TMidasOnline.cxx.

References odbReadAny().

00347 {
00348   uint32_t value = defaultValue;
00349   if (odbReadAny(name,index,TID_BOOL,&value) == 0)
00350     return value;
00351   else
00352     return defaultValue;
00353 };

Here is the call graph for this function:

double TMidasOnline::odbReadDouble	(	const char *	name,
		int	index = `0`,
		double	defaultValue = `0`
	)			`[virtual]`

Read an 64-bit floating point value, midas type TID_DOUBLET.

Implements VirtualOdb.

double TMidasOnline::odbReadDouble	(	const char *	name,
		int	index = `0`,
		double	defaultValue = `0`
	)			`[virtual]`

Read an 64-bit floating point value, midas type TID_DOUBLET.

Implements VirtualOdb.

Definition at line 364 of file TMidasOnline.cxx.

References odbReadAny().

00365 {
00366   double value = defaultValue;
00367   if (odbReadAny(name,index,TID_DOUBLE,&value) == 0)
00368     return value;
00369   else
00370     return defaultValue;
00371 };

Here is the call graph for this function:

float TMidasOnline::odbReadFloat	(	const char *	name,
		int	index = `0`,
		float	defaultValue = `0`
	)			`[virtual]`

Read an 32-bit floating point value, midas type TID_FLOAT.

Implements VirtualOdb.

float TMidasOnline::odbReadFloat	(	const char *	name,
		int	index = `0`,
		float	defaultValue = `0`
	)			`[virtual]`

Read an 32-bit floating point value, midas type TID_FLOAT.

Implements VirtualOdb.

Definition at line 355 of file TMidasOnline.cxx.

References odbReadAny().

00356 {
00357   float value = defaultValue;
00358   if (odbReadAny(name,index,TID_FLOAT,&value) == 0)
00359     return value;
00360   else
00361     return defaultValue;
00362 };

Here is the call graph for this function:

int TMidasOnline::odbReadInt	(	const char *	name,
		int	index = `0`,
		int	defaultValue = `0`
	)			`[virtual]`

Read an integer value, midas type TID_INT.

Implements VirtualOdb.

int TMidasOnline::odbReadInt	(	const char *	name,
		int	index = `0`,
		int	defaultValue = `0`
	)			`[virtual]`

Read an integer value, midas type TID_INT.

Implements VirtualOdb.

Definition at line 328 of file TMidasOnline.cxx.

References odbReadAny().

00329 {
00330   int value = defaultValue;
00331   if (odbReadAny(name,index,TID_INT,&value) == 0)
00332     return value;
00333   else
00334     return defaultValue;
00335 };

Here is the call graph for this function:

const char* TMidasOnline::odbReadString	(	const char *	name,
		int	index = `0`,
		const char *	defaultValue = `NULL`
	)			`[virtual]`

Read a string value, midas type TID_STRING.

Implements VirtualOdb.

const char * TMidasOnline::odbReadString	(	const char *	name,
		int	index = `0`,
		const char *	defaultValue = `NULL`
	)			`[virtual]`

Read a string value, midas type TID_STRING.

Implements VirtualOdb.

Definition at line 373 of file TMidasOnline.cxx.

References odbReadAny().

00374 {
00375   const int bufsize = 1024;
00376   static char buf[bufsize];
00377   if (odbReadAny(name, index, TID_STRING, buf, bufsize) == 0)
00378     return buf;
00379   else
00380     return defaultValue;
00381 };

Here is the call graph for this function:

uint32_t TMidasOnline::odbReadUint32	(	const char *	name,
		int	index = `0`,
		uint32_t	defaultValue = `0`
	)			`[virtual]`

Read an unsigned 32-bit integer value, midas type TID_DWORD.

Implements VirtualOdb.

uint32_t TMidasOnline::odbReadUint32	(	const char *	name,
		int	index = `0`,
		uint32_t	defaultValue = `0`
	)			`[virtual]`

Read an unsigned 32-bit integer value, midas type TID_DWORD.

Implements VirtualOdb.

Definition at line 337 of file TMidasOnline.cxx.

References odbReadAny().

00338 {
00339   uint32_t value = defaultValue;
00340   if (odbReadAny(name,index,TID_DWORD,&value) == 0)
00341     return value;
00342   else
00343     return defaultValue;
00344 };

Here is the call graph for this function:

bool TMidasOnline::poll ( int mdelay )

Check for MIDAS events (run transitions, data requests).

bool TMidasOnline::poll ( int mdelay )

Check for MIDAS events (run transitions, data requests).

Definition at line 160 of file TMidasOnline.cxx.

References checkTransitions(), and disconnect().

00161 {
00162   //printf("poll!\n");
00163
00164   if (checkTransitions())
00165     return true;
00166
00167   int status = cm_yield(mdelay);
00168   if (status == RPC_SHUTDOWN || status == SS_ABORT)
00169     {
00170       fprintf(stderr, "TMidasOnline::poll: cm_yield(%d) status %d, shutting down.\n",mdelay,status);
00171       disconnect();
00172       return false;
00173     }
00174
00175   return true;
00176 }

Here is the call graph for this function:

int TMidasOnline::receiveEvent	(	int	requestId,
		void *	pevent,
		int	size,
		bool	async
	)

Receive event by polling.

int TMidasOnline::receiveEvent	(	int	requestId,
		void *	pevent,
		int	size,
		bool	async
	)

Receive event by polling.

Definition at line 202 of file TMidasOnline.cxx.

References EventRequest::fBufferHandle, fEventRequests, EventRequest::fNext, and EventRequest::fRequestId.

00203 {
00204   EventRequest* r = fEventRequests;
00205
00206   while (1)
00207     {
00208       if (!r)
00209         {
00210           fprintf(stderr, "TMidasOnline::receiveEvent: Cannot find request %d\n", requestId);
00211           return -1;
00212         }
00213
00214       if (r->fRequestId == requestId)
00215         break;
00216
00217       r = r->fNext;
00218     }
00219
00220   int flag = 0;
00221   if (async){
00222 #ifdef BM_NO_WAIT
00223     flag = BM_NO_WAIT;
00224 #else
00225     flag = ASYNC;
00226 #endif
00227   }
00228
00229
00230   int status = bm_receive_event(r->fBufferHandle, pevent, &size, flag);
00231
00232   if (status == BM_ASYNC_RETURN)
00233     {
00234       return 0;
00235     }
00236
00237   if (status != BM_SUCCESS)
00238     {
00239       fprintf(stderr, "TMidasOnline::receiveEvent: bm_receive_event() error %d\n", status);
00240       return -1;
00241     }
00242
00243   return size;
00244 }

void TMidasOnline::registerTransitions ( )

Ask MIDAS to tell us about run transitions.

void TMidasOnline::registerTransitions ( )

Ask MIDAS to tell us about run transitions.

Definition at line 104 of file TMidasOnline.cxx.

00105 {
00106   cm_register_transition(TR_START,  NULL, 300);
00107   cm_register_transition(TR_PAUSE,  NULL, 700);
00108   cm_register_transition(TR_RESUME, NULL, 300);
00109   cm_register_transition(TR_STOP,   NULL, 700);
00110 }

void TMidasOnline::setEventHandler ( EventHandler handler )

Specify user handler for data events.

void TMidasOnline::setEventHandler ( EventHandler handler )

Specify user handler for data events.

Definition at line 178 of file TMidasOnline.cxx.

References fEventHandler.

00179 {
00180   fEventHandler  = handler;
00181 }

void TMidasOnline::setTransitionHandlers	(	TransitionHandler	start,
		TransitionHandler	stop,
		TransitionHandler	pause,
		TransitionHandler	resume
	)

Specify user handlers for run transitions.

void TMidasOnline::setTransitionHandlers	(	TransitionHandler	start,
		TransitionHandler	stop,
		TransitionHandler	pause,
		TransitionHandler	resume
	)

Specify user handlers for run transitions.

Definition at line 112 of file TMidasOnline.cxx.

References fPauseHandler, fResumeHandler, fStartHandler, and fStopHandler.

00113 {
00114   fStartHandler  = start;
00115   fStopHandler   = stop;
00116   fPauseHandler  = pause;
00117   fResumeHandler = resume;
00118 }

Member Data Documentation

int TMidasOnline::fDB

ODB handle.

Definition at line 51 of file TMidasOnline.h.

Referenced by connect(), disconnect(), odbReadAny(), odbReadArraySize(), and TMidasOnline().

EventHandler TMidasOnline::fEventHandler

Definition at line 59 of file TMidasOnline.h.

Referenced by eventCallback(), setEventHandler(), and TMidasOnline().

EventRequest * TMidasOnline::fEventRequests

Definition at line 58 of file TMidasOnline.h.

Referenced by deleteEventRequest(), eventRequest(), getBufferLevel(), getBufferSize(), receiveEvent(), and TMidasOnline().

std::string TMidasOnline::fExptname

experiment name, blank if only one experiment defined in exptab

Definition at line 49 of file TMidasOnline.h.

Referenced by connect(), and disconnect().

std::string TMidasOnline::fHostname

hostname where the mserver is running, blank if using shared memory

Definition at line 48 of file TMidasOnline.h.

Referenced by connect(), and disconnect().

TransitionHandler TMidasOnline::fPauseHandler

Definition at line 55 of file TMidasOnline.h.

Referenced by checkTransitions(), setTransitionHandlers(), and TMidasOnline().

TransitionHandler TMidasOnline::fResumeHandler

Definition at line 56 of file TMidasOnline.h.

Referenced by checkTransitions(), setTransitionHandlers(), and TMidasOnline().

TransitionHandler TMidasOnline::fStartHandler

Definition at line 53 of file TMidasOnline.h.

Referenced by checkTransitions(), setTransitionHandlers(), and TMidasOnline().

TransitionHandler TMidasOnline::fStopHandler

Definition at line 54 of file TMidasOnline.h.

Referenced by checkTransitions(), setTransitionHandlers(), and TMidasOnline().

static TMidasOnline * TMidasOnline::gfMidas = NULL [static, private]

TMidasOnline is a singleton class: only one instance is allowed at any time

Definition at line 64 of file TMidasOnline.h.

Referenced by instance().

The documentation for this class was generated from the following files:

include/TMidasOnline.h
libMidasInterface/TMidasOnline.h
libMidasInterface/TMidasOnline.cxx

TMidasOnline Class Reference

Public Types

Public Member Functions

Static Public Member Functions

Public Attributes

Private Member Functions

Static Private Attributes

Detailed Description

Member Typedef Documentation

Constructor & Destructor Documentation

Member Function Documentation

Member Data Documentation
