TDbiFieldType Class Reference

Concept Database neutral table column field types. More...

#include <TDbiFieldType.hxx>

Collaboration diagram for TDbiFieldType:
Collaboration graph
[legend]

List of all members.

Public Types

enum  PrecisionLimits {
  kMaxTinyInt = 4, kMaxSmallInt = 6, kMaxInt = 11, kMaxChar = 3,
  kMaxMySQLVarchar = 255, kMaxMySQLText = 65535
}

Public Member Functions

 TDbiFieldType (Int_t type=TDbi::kInt)
 TDbiFieldType (Int_t type, Int_t size, const char *typeName)
 TDbiFieldType (const TDbiFieldType &from)
 TDbiFieldType (const string &sql, Int_t size)
virtual ~TDbiFieldType ()
string AsString () const
string AsSQLString () const
string UndefinedValue () const
UInt_t GetConcept () const
UInt_t GetSize () const
UInt_t GetType () const
Bool_t IsCompatible (const TDbiFieldType &other) const
Bool_t IsEqual (const TDbiFieldType &other) const
Bool_t IsSmaller (const TDbiFieldType &other) const
Bool_t IsSigned () const
void SetUnsigned ()

Private Member Functions

void Init (Int_t type, Int_t size=-1)

Private Attributes

unsigned int fConcept
 Concept e.g. kInt or kFloat.
unsigned int fSize
 Size in bytes(0 if unknown).
unsigned int fType
 Concept e.g. kShort or kDouble.

Detailed Description

Concept Database neutral table column field types.

Id
TDbiFieldType.hxx,v 1.1 2011/01/18 05:49:20 finch Exp

Purpose To provide mappings and check compatibility between database types and application types. Contact: A.Finch@lancaster.ac.uk

Definition at line 35 of file TDbiFieldType.hxx.

Member Enumeration Documentation

enum TDbiFieldType::PrecisionLimits
Enumerator:
kMaxTinyInt
kMaxSmallInt
kMaxInt
kMaxChar
kMaxMySQLVarchar
kMaxMySQLText

Definition at line 41 of file TDbiFieldType.hxx.

00041                      { kMaxTinyInt       = 4,
00042                        kMaxSmallInt      = 6,
00043                        kMaxInt           = 11,
00044                        kMaxChar          = 3,
00045                        kMaxMySQLVarchar  = 255,
00046                        kMaxMySQLText     = 65535
00047 };

Constructor & Destructor Documentation

TDbiFieldType::TDbiFieldType ( Int_t  type = TDbi::kInt  )
TDbiFieldType::TDbiFieldType ( Int_t  type,
Int_t  size,
const char *  typeName
)

Definition at line 52 of file TDbiFieldType.cxx.

References Init(), TDbi::kChar, TDbi::kDate, TDbi::kDouble, TDbi::kFloat, TDbi::kInt, TDbi::kLong, kMaxChar, kMaxInt, kMaxMySQLText, kMaxMySQLVarchar, kMaxSmallInt, kMaxTinyInt, TDbi::kShort, TDbi::kString, TDbi::kTiny, TDbi::kUnknown, and SK_DBI_Severe.

00054                                                  {
00055
00056
00057 //
00058 //
00059 //  Purpose:  Constructor for TSQL meta-data.
00060 //
00061 //  Arguments:
00062 //    type      in    value from TSQLColumnInfo::GetSQLType()
00063 //    size      in    value from TSQLColumnInfo::GetLength()
00064 //    typeName  in    value from TSQLColumnInfo::GetTypeName()
00065
00066
00067   TString name(typeName);
00068   name.ToUpper();
00069
00070   // Handle integer types.
00071
00072   if ( type == TSQLServer::kSQL_INTEGER || type == TSQLServer::kSQL_NUMERIC ) {
00073
00074     // TSQLServer reports e.g. int(32) as size 32, (even though maximum display is 11)
00075     // so treat any type starting int or INT as size kMaxInt (i.e. standard 4 byte int)
00076     if ( name.BeginsWith("INT") ) size = kMaxInt;
00077     if      ( size <= kMaxTinyInt  ) { this->Init(TDbi::kTiny);  return; }
00078     else if ( size <= kMaxSmallInt ) { this->Init(TDbi::kShort); return; }
00079     else if ( size <= kMaxInt      ) { this->Init(TDbi::kInt);   return; }
00080     else                             { this->Init(TDbi::kLong);  return; }
00081
00082   }
00083
00084   // Handle floating point types
00085
00086   if ( type == TSQLServer::kSQL_FLOAT  ) { this->Init(TDbi::kFloat);  return; }
00087   if ( type == TSQLServer::kSQL_DOUBLE ) { this->Init(TDbi::kDouble);  return; }
00088
00089   // Handle cases where type is determined uniquely by type name.
00090
00091   if ( name == "BINARY_FLOAT" )  { this->Init(TDbi::kFloat);  return; }
00092   if ( name == "BINARY_DOUBLE" ) { this->Init(TDbi::kDouble); return; }
00093   if ( name == "TINYTEXT" )      { this->Init(TDbi::kString,kMaxMySQLVarchar);   return; }
00094   if ( name == "TEXT" )          { this->Init(TDbi::kString,kMaxMySQLText);   return; }
00095   if ( name == "DATE" )          { this->Init(TDbi::kDate);   return; }
00096   if ( name == "DATETIME" )      { this->Init(TDbi::kDate);   return; }
00097
00098   // Handle character types
00099
00100   if ( type == TSQLServer::kSQL_CHAR && size <= kMaxChar ) {
00101     this->Init(TDbi::kChar,size);
00102     return;
00103   }
00104   if ( type == TSQLServer::kSQL_CHAR || type == TSQLServer::kSQL_VARCHAR ) {
00105     if ( size < kMaxMySQLVarchar ) Init(TDbi::kString,size);
00106     else                           Init(TDbi::kString,kMaxMySQLText);
00107     return;
00108   }
00109
00110   // Anything else is bad news!
00111
00112      SK_DBI_Severe(  "Unable to form SQL TDbiFieldType from: " << type << "  ");
00113   this->Init(TDbi::kUnknown);
00114
00115 }

Here is the call graph for this function:

TDbiFieldType::TDbiFieldType ( const TDbiFieldType &  from  )

Definition at line 119 of file TDbiFieldType.cxx.

00120 {
00121 //
00122 //
00123 //  Purpose:  Copy constructor
00124
00125 //  Program Notes:-
00126 //  =============
00127
00128 //  Make explicit for leak checking.
00129
00130
00131   *this = from;
00132 }

TDbiFieldType::TDbiFieldType ( const string &  sql,
Int_t  size
)

Definition at line 136 of file TDbiFieldType.cxx.

References fSize, Init(), TDbi::kChar, TDbi::kDate, TDbi::kDouble, TDbi::kFloat, TDbi::kInt, TDbi::kLong, kMaxChar, kMaxMySQLText, kMaxMySQLVarchar, TDbi::kShort, TDbi::kString, TDbi::kTiny, TDbi::kUnknown, and SK_DBI_Severe.

00138 {
00139 //
00140 //
00141 //  Purpose:  Constructor from a MySQL type string
00142
00143
00144
00145
00146   if (         sql == "TINYINT" )   this->Init(TDbi::kTiny);
00147
00148   else if (    sql == "SMALLINT" )  this->Init(TDbi::kShort);
00149
00150   else if (    sql == "INT"
00151             || sql == "INTEGER"
00152             || sql == "NUMERIC" )   this->Init(TDbi::kInt);
00153
00154   else if (     sql == "BIGINT" )   this->Init(TDbi::kLong);
00155
00156   else if (    sql == "FLOAT"
00157             || sql == "REAL")       this->Init(TDbi::kFloat);
00158
00159   else if (    sql == "DOUBLE" )    this->Init(TDbi::kDouble);
00160
00161   else if (    sql == "CHAR"
00162             || sql == "VARCHAR"
00163             || sql == "TEXT"
00164             || sql == "TINYTEXT" ) {
00165
00166     if      ( sql == "TINYTEXT" ) size = kMaxMySQLVarchar;
00167     else if ( sql == "TEXT"     ) size = kMaxMySQLText;
00168     else {
00169       if ( size < 0 ) {
00170         if ( sql == "CHAR" ) size = 1;
00171         else                 size = kMaxMySQLVarchar -1;
00172       }
00173     }
00174     if ( fSize <= kMaxChar ) this->Init(TDbi::kChar,size);
00175     else                     this->Init(TDbi::kString,size);
00176
00177   }
00178
00179   else if ( sql == "DATETIME" )     this->Init(TDbi::kDate);
00180
00181   else {
00182        SK_DBI_Severe(  "Unable to type from SQL: " << sql << "  ");
00183                                     this->Init(TDbi::kUnknown);
00184   }
00185
00186 }

Here is the call graph for this function:

TDbiFieldType::~TDbiFieldType (  )  [virtual]

Definition at line 191 of file TDbiFieldType.cxx.

00191                               {
00192 //
00193 //
00194 //  Purpose: Destructor
00195 //
00196 //  Arguments:
00197 //    None.
00198 //
00199 //  Return:    n/a
00200 //
00201 //  Contact:   N. West
00202 //
00203 //  Specification:-
00204 //  =============
00205 //
00206 //  o  Destroy FieldType.
00207
00208
00209 //  Program Notes:-
00210 //  =============
00211
00212 //  None.
00213
00214
00215
00216 }

Member Function Documentation

string TDbiFieldType::AsSQLString (  )  const

Definition at line 264 of file TDbiFieldType.cxx.

References fSize, fType, TDbi::kBool, TDbi::kChar, TDbi::kDate, TDbi::kDouble, TDbi::kFloat, TDbi::kInt, TDbi::kLong, kMaxChar, kMaxMySQLVarchar, TDbi::kShort, TDbi::kString, TDbi::kTiny, TDbi::kTString, TDbi::kUChar, TDbi::kUInt, TDbi::kULong, TDbi::kUShort, and TDbi::kUTiny.

Referenced by TDbiTableMetaData::Sql().

00264                                         {
00265 //
00266 //
00267 //  Purpose:  Return field type as a string suitable for MySQL column.
00268
00269   ostringstream os;
00270
00271   switch ( fType ) {
00272
00273   case  TDbi::kBool    :   os << "CHAR";          break;
00274
00275   case  TDbi::kUTiny   :
00276   case  TDbi::kTiny    :   os << "TINYINT";       break;
00277
00278   case  TDbi::kShort   :
00279   case  TDbi::kUShort  :   os << "SMALLINT";      break;
00280
00281   case  TDbi::kInt     :
00282   case  TDbi::kUInt    :   os << "INT";           break;
00283
00284   case  TDbi::kLong    :
00285   case  TDbi::kULong   :   os << "BIGINT";        break;
00286
00287   case  TDbi::kFloat   :   os << "FLOAT";         break;
00288
00289   case  TDbi::kDouble  :   os << "DOUBLE";        break;
00290
00291   case  TDbi::kChar    :
00292   case  TDbi::kUChar   :
00293   case  TDbi::kString  :
00294   case  TDbi::kTString :
00295     if      ( fSize == 1)                os << "CHAR";
00296     else if ( fSize <= kMaxChar)         os << "CHAR("    << fSize << ')';
00297     else if ( fSize <  kMaxMySQLVarchar) os << "VARCHAR(" << fSize << ')';
00298     else if ( fSize == kMaxMySQLVarchar) os << "TINYTEXT";
00299     else                                 os << "TEXT";
00300     break;
00301
00302   case  TDbi::kDate    :   os << "DATETIME";      break;
00303
00304   default :               os << "Unknown";
00305
00306   }
00307
00308   return os.str();
00309
00310 }

Here is the caller graph for this function:

string TDbiFieldType::AsString (  )  const

Definition at line 220 of file TDbiFieldType.cxx.

References fType, TDbi::kBool, TDbi::kChar, TDbi::kDate, TDbi::kDouble, TDbi::kFloat, TDbi::kInt, TDbi::kLong, TDbi::kShort, TDbi::kString, TDbi::kTiny, TDbi::kTString, TDbi::kUChar, TDbi::kUInt, TDbi::kULong, TDbi::kUShort, and TDbi::kUTiny.

Referenced by TDbiInRowStream::AsString(), operator<<(), TDbiTableMetaData::SetFromSql(), and TDbiOutRowStream::StoreDefaultIfInvalid().

00220                                      {
00221 //
00222 //
00223 //  Purpose:  Return field type as a string.
00224 //
00225 //  Arguments: None.
00226 //
00227 //  Return:    Field type as a string e.g. "Int"
00228 //
00229 //  Contact:   N. West
00230 //
00231 //  Specification:-
00232 //  =============
00233 //
00234 //  o Return field type as a string.
00235
00236 //  Program Notes:-
00237 //  =============
00238
00239 //  None.
00240
00241   switch ( fType ) {
00242
00243   case  TDbi::kBool    : return "Bool";
00244   case  TDbi::kChar    : return "Char";
00245   case  TDbi::kUChar   : return "UChar";
00246   case  TDbi::kTiny    : return "Tiny";
00247   case  TDbi::kUTiny   : return "UTiny";
00248   case  TDbi::kShort   : return "Short";
00249   case  TDbi::kUShort  : return "UShort";
00250   case  TDbi::kInt     : return "Int";
00251   case  TDbi::kUInt    : return "UInt";
00252   case  TDbi::kLong    : return "Long";
00253   case  TDbi::kULong   : return "ULong";
00254   case  TDbi::kFloat   : return "Float";
00255   case  TDbi::kDouble  : return "Double";
00256   case  TDbi::kString  : return "String";
00257   case  TDbi::kTString : return "TString";
00258   case  TDbi::kDate    : return "Date";
00259   }
00260   return "Unknown";
00261 }

Here is the caller graph for this function:

UInt_t TDbiFieldType::GetConcept (  )  const [inline]

Definition at line 64 of file TDbiFieldType.hxx.

References fConcept.

Referenced by TDbiInRowStream::AsString(), IsCompatible(), TDbiTableMetaData::SetColFieldType(), and TDbiOutRowStream::Store().

00064 { return fConcept; }

Here is the caller graph for this function:

UInt_t TDbiFieldType::GetSize (  )  const [inline]

Definition at line 65 of file TDbiFieldType.hxx.

References fSize.

00065 { return fSize; }

UInt_t TDbiFieldType::GetType (  )  const [inline]

Definition at line 66 of file TDbiFieldType.hxx.

References fType.

Referenced by TDbiInRowStream::RowAsCsv().

00066 { return fType; }

Here is the caller graph for this function:

void TDbiFieldType::Init ( Int_t  type,
Int_t  size = -1
) [private]

Definition at line 316 of file TDbiFieldType.cxx.

References fConcept, fSize, fType, TDbi::kBool, TDbi::kChar, TDbi::kDate, TDbi::kDouble, TDbi::kFloat, TDbi::kInt, TDbi::kLong, TDbi::kShort, TDbi::kString, TDbi::kTiny, TDbi::kTString, TDbi::kUChar, TDbi::kUInt, TDbi::kULong, TDbi::kUnknown, TDbi::kUShort, TDbi::kUTiny, and SK_DBI_Severe.

Referenced by TDbiFieldType().

00317                                                              : -1 - take size from type)*/ ) {
00318 //
00319 //
00320 //  Purpose:  Initialise object.
00321 //
00322
00323   switch ( type ) {
00324
00325   case TDbi::kBool :
00326       fType      = TDbi::kBool;
00327       fConcept   = TDbi::kBool;
00328       fSize      = 1;
00329       break;
00330
00331     case TDbi::kChar :
00332       fType      = TDbi::kChar;
00333       fConcept   = TDbi::kChar;
00334       fSize      = 1;
00335       break;
00336
00337     case TDbi::kUChar :
00338       fType      = TDbi::kUChar;
00339       fConcept   = TDbi::kUChar;
00340       fSize      = 1;
00341       break;
00342
00343     case TDbi::kTiny :
00344       fType      = TDbi::kTiny;
00345       fConcept   = TDbi::kInt;
00346       fSize      = 1;
00347       break;
00348
00349     case TDbi::kUTiny :
00350       fType      = TDbi::kUTiny;
00351       fConcept   = TDbi::kUInt;
00352       fSize      = 1;
00353       break;
00354
00355     case TDbi::kShort :
00356       fType      = TDbi::kShort;
00357       fConcept   = TDbi::kInt;
00358       fSize      = 2;
00359       break;
00360
00361     case TDbi::kUShort :
00362       fType      = TDbi::kUShort;
00363       fConcept   = TDbi::kUInt;
00364       fSize      = 2;
00365       break;
00366
00367     case TDbi::kInt :
00368       fType      = TDbi::kInt;
00369       fConcept   = TDbi::kInt;
00370       fSize      = 4;
00371       break;
00372
00373     case TDbi::kUInt :
00374       fType      = TDbi::kUInt;
00375       fConcept   = TDbi::kUInt;
00376       fSize      = 4;
00377       break;
00378
00379     case TDbi::kLong :
00380       fType    = TDbi::kLong;
00381       fConcept = TDbi::kInt;
00382       fSize    = 8;
00383       break;
00384
00385     case TDbi::kULong :
00386       fType    = TDbi::kULong;
00387       fConcept = TDbi::kUInt;
00388       fSize    = 8;
00389       break;
00390
00391     case TDbi::kFloat :
00392       fType      = TDbi::kFloat;
00393       fConcept   = TDbi::kFloat;
00394       fSize      = 4;
00395       break;
00396
00397     case TDbi::kDouble :
00398       fType      = TDbi::kDouble;
00399       fConcept   = TDbi::kFloat;
00400       fSize      = 8;
00401       break;
00402
00403     case TDbi::kString :
00404       fType      = TDbi::kString;
00405       fConcept   = TDbi::kString;
00406       fSize      = 65535;
00407       break;
00408
00409     case TDbi::kTString :
00410       fType      = TDbi::kTString;
00411       fConcept   = TDbi::kString;
00412       fSize      = 65535;
00413       break;
00414
00415     case TDbi::kDate :
00416       fType      = TDbi::kDate;
00417       fConcept   = TDbi::kDate;
00418       fSize      = 4;
00419       break;
00420
00421     case TDbi::kUnknown :
00422       fType      = TDbi::kUnknown;
00423       fConcept   = TDbi::kUnknown;
00424       break;
00425
00426     default :
00427          SK_DBI_Severe(  "Unable to form Root TDbiFieldType from: " << type << "  ");
00428       fType      = TDbi::kUnknown;
00429       fConcept   = TDbi::kUnknown;
00430       fSize      = 0;
00431   }
00432
00433   // Override fSize if necessary.
00434
00435   if ( size      >= 0  ) fSize      = size;
00436
00437 }

Here is the caller graph for this function:

Bool_t TDbiFieldType::IsCompatible ( const TDbiFieldType &  other  )  const

Definition at line 441 of file TDbiFieldType.cxx.

References fConcept, GetConcept(), TDbi::kBool, TDbi::kChar, TDbi::kInt, TDbi::kString, TDbi::kUChar, TDbi::kUInt, and MATCHES.

Referenced by TDbiInRowStream::AsString(), and TDbiOutRowStream::StoreDefaultIfInvalid().

00441                                                                    {
00442 //
00443 //
00444 //  Purpose: Return kTRUE if this is compatible with or can accept
00445 //           the other type.
00446 //
00447 //  Arguments:
00448 //    other        in    The TDbiFieldType to be compared
00449 //
00450 //  Return: kTRUE if the this type can accept other type.
00451 //
00452 //  Contact:   N. West
00453 //
00454 //  Specification:-
00455 //  =============
00456 //
00457 //  o If the two types have the same concept or have compatible
00458 //    concepts return kTRUE.
00459 //
00460 //  o Also return true if the other type can be be used as input.
00461 //
00462
00463 //  Program Notes:-
00464 //  =============
00465
00466 //  None.
00467
00468 #define MATCHES(x,y)  \
00469     ( (fConcept == x) && (concept == y) )\
00470   || ((fConcept == y) && (concept == x) )
00471   UInt_t concept = other.GetConcept();
00472   if ( fConcept == concept ) return kTRUE;
00473   if ( MATCHES(TDbi::kBool,  TDbi::kChar)  ) return kTRUE;
00474   if ( MATCHES(TDbi::kBool,  TDbi::kUChar) ) return kTRUE;
00475   if ( MATCHES(TDbi::kInt,   TDbi::kChar)  ) return kTRUE;
00476   if ( MATCHES(TDbi::kUInt,  TDbi::kUChar) ) return kTRUE;
00477 //  Allow unsigned to match signed because the TSQLResultSetL interface
00478 //  does not support unsigned types but its GetShort and GetInt
00479 //  methods will return unsigned data intact so we must trust
00480 //  that the user knows what they are doing!
00481   if ( MATCHES(TDbi::kUInt,  TDbi::kInt)   ) return kTRUE;
00482 //  Allow char to be input to string.
00483   if ( concept == TDbi::kChar && fConcept == TDbi::kString ) return kTRUE;
00484
00485 return kFALSE;
00486
00487 }

Here is the call graph for this function:

Here is the caller graph for this function:

Bool_t TDbiFieldType::IsEqual ( const TDbiFieldType &  other  )  const [inline]

Definition at line 68 of file TDbiFieldType.hxx.

References fType.

00069                                         { return fType == other.fType; }

Bool_t TDbiFieldType::IsSigned (  )  const [inline]

Definition at line 72 of file TDbiFieldType.hxx.

References fConcept, and TDbi::kInt.

Referenced by SetUnsigned().

00072 { return fConcept ==  TDbi::kInt; }

Here is the caller graph for this function:

Bool_t TDbiFieldType::IsSmaller ( const TDbiFieldType &  other  )  const [inline]

Definition at line 70 of file TDbiFieldType.hxx.

References fSize.

Referenced by TDbiInRowStream::AsString().

00071                                   { return fSize < other.fSize; }

Here is the caller graph for this function:

void TDbiFieldType::SetUnsigned (  )  [inline]

Definition at line 77 of file TDbiFieldType.hxx.

References fConcept, fType, and IsSigned().

00077 {if (this->IsSigned()) {++fConcept; ++fType;}}

Here is the call graph for this function:

string TDbiFieldType::UndefinedValue (  )  const

Definition at line 491 of file TDbiFieldType.cxx.

References fConcept, TDbi::kBool, TDbi::kChar, TDbi::kDate, TDbi::kFloat, TDbi::kInt, TDbi::kString, TDbi::kUChar, TDbi::kUInt, and SK_DBI_Severe.

Referenced by TDbiInRowStream::AsString(), and TDbiOutRowStream::StoreDefaultIfInvalid().

00491                                            {
00492 //
00493 //
00494 //  Purpose:  Return value to be used when unknown.
00495 //
00496 //  Arguments: None
00497 //
00498 //  Return:   Value as a string to be used when unknown.
00499 //
00500 //  Contact:   N. West
00501 //
00502 //  Specification:-
00503 //  =============
00504 //
00505 //  o Return value to be used when unknown.
00506
00507 //  Program Notes:-
00508 //  =============
00509
00510 //  For each conceptual data type there is an associated
00511 //  data type to be used when attemping to get value from outside
00512 //  the table or when table type incompatible with data.
00513
00514
00515   switch ( fConcept ) {
00516     case TDbi::kBool   : return "0";
00517     case TDbi::kChar   : return "";
00518     case TDbi::kUChar  : return "";
00519     case TDbi::kInt    : return "-999";
00520     case TDbi::kUInt   : return " 999";
00521     case TDbi::kFloat  : return "-999.";
00522     case TDbi::kString : return "";
00523     case TDbi::kDate   : return "1980-00-00 00:00:00";
00524
00525     default :
00526          SK_DBI_Severe( "Unable to define undefined type for: "
00527             << fConcept << "  ");
00528       return "";
00529   }
00530 }

Here is the caller graph for this function:

Member Data Documentation

unsigned int TDbiFieldType::fConcept [private]

Concept e.g. kInt or kFloat.

Definition at line 86 of file TDbiFieldType.hxx.

Referenced by GetConcept(), Init(), IsCompatible(), IsSigned(), SetUnsigned(), and UndefinedValue().

unsigned int TDbiFieldType::fSize [private]

Size in bytes(0 if unknown).

Definition at line 88 of file TDbiFieldType.hxx.

Referenced by AsSQLString(), GetSize(), Init(), IsSmaller(), and TDbiFieldType().

unsigned int TDbiFieldType::fType [private]

Concept e.g. kShort or kDouble.

Definition at line 90 of file TDbiFieldType.hxx.

Referenced by AsSQLString(), AsString(), GetType(), Init(), IsEqual(), and SetUnsigned().

The documentation for this class was generated from the following files:
Generated on 11 Aug 2013 for SKDatabase by  doxygen 1.6.1
