TDbiTimer Class Reference

Concept: Simple timer, record query progress and final times. More...

#include <TDbiTimer.hxx>

Collaboration diagram for TDbiTimer:

Public Member Functions
	TDbiTimer ()
virtual	~TDbiTimer ()
void	RecBegin (string tableName, UInt_t rowSize)
void	RecEnd (UInt_t numRows)
void	RecFillAgg (Int_t aggNo)
void	RecMainQuery ()
void	Resume ()
void	StartSubWatch (UInt_t subWatch)
void	Suspend ()
Private Types
enum	QueryStage { kPassive, kInitialQuery, kMainQuery }
enum	{ kMaxSubWatch = 4 }
Private Attributes
Int_t	fCurSubWatch
UInt_t	fRowSize
QueryStage	fQueryStage
TStopwatch	fSubWatches [kMaxSubWatch]
string	fTableName
TStopwatch	fWatch

Detailed Description

Concept: Simple timer, record query progress and final times.

Purpose: To find out why this is all soooo sssllloooowwww!

Definition at line 24 of file TDbiTimer.hxx.

Member Enumeration Documentation

anonymous enum [private]

Enumerator:

kMaxSubWatch

Definition at line 49 of file TDbiTimer.hxx.

00049 { kMaxSubWatch = 4 };  // Must be > 0.

enum TDbiTimer::QueryStage [private]

Enumerator:

kPassive
kInitialQuery
kMainQuery

Definition at line 48 of file TDbiTimer.hxx.

00048 { kPassive, kInitialQuery, kMainQuery };

Constructor & Destructor Documentation

TDbiTimer::TDbiTimer ( )

TDbiTimer::~TDbiTimer ( ) [virtual]

Definition at line 59 of file TDbiTimer.cxx.

References SK_DBI_Trace.

00059                       {
00060 //
00061 //
00062 //  Purpose: Destructor
00063 //
00064 //  Contact:   N. West
00065 //
00066
00067
00068   SK_DBI_Trace( "Destroying TDbiTimer" << "  ");
00069
00070 }

Member Function Documentation

void TDbiTimer::RecBegin	(	string	tableName,
		UInt_t	rowSize
	)

Definition at line 74 of file TDbiTimer.cxx.

References fCurSubWatch, fQueryStage, fRowSize, fSubWatches, fTableName, fWatch, kInitialQuery, kMaxSubWatch, and StartSubWatch().

Referenced by TDbiTimerManager::RecBegin().

00074                                                          {
00075 //
00076 //
00077 //  Purpose:  Record the start of initial query on supplied table.
00078 //
00079 //  Arguments:
00080 //    tableName    in    Name of table.
00081 //    rowSize      in    Size of row object
00082 //
00083 //  Contact:   N. West
00084
00085   fQueryStage = kInitialQuery;
00086   fTableName = tableName;
00087   fRowSize = rowSize;
00088   fWatch.Start();
00089   for ( int subWatch = 0; subWatch <  kMaxSubWatch; ++subWatch) {
00090     // Use Start to reset the counter (Reset doesn't do this).
00091     fSubWatches[subWatch].Start();
00092     fSubWatches[subWatch].Stop();
00093   }
00094   if ( fCurSubWatch >= 0 ) this->StartSubWatch(0);
00095
00096 }

Here is the call graph for this function:

Here is the caller graph for this function:

void TDbiTimer::RecEnd ( UInt_t numRows )

Definition at line 99 of file TDbiTimer.cxx.

References fCurSubWatch, fQueryStage, fRowSize, fSubWatches, fTableName, fWatch, kMainQuery, kMaxSubWatch, kPassive, and SK_DBI_Info.

Referenced by TDbiTimerManager::RecEnd().

00099                                      {
00100 //
00101 //
00102 //  Purpose:  Record the end of query.
00103 //
00104 //  Arguments:
00105 //    numRows    in    Number of rows found in query
00106 //
00107 //  Contact:   N. West
00108 //
00109 //  Specification:-
00110 //  =============
00111 //
00112 //  o Record the end of query.  If query never reached the Main Query
00113 //    phase then quit as query must have been satisfied
00114 //    by the cache.
00115 //
00116 // o  If SubWatches enabled print them out if the main timer has
00117 //    recorded significant activity.
00118
00119 //  None.
00120
00121   if ( fQueryStage != kMainQuery ) return;
00122
00123   Float_t tableSize = numRows * fRowSize/1.0e+3;
00124   string units = "Kb";
00125   if ( tableSize > 1000. ) {
00126     tableSize /= 1000.;
00127     units = "Mb";
00128   }
00129   MsgFormat ffmt("%6.1f");
00130
00131   SK_DBI_Info( "TDbiTimer:" <<  fTableName
00132                         << ": Query done. "  << numRows
00133                         << "rows, " << ffmt(tableSize) << units
00134                         << " Cpu" << ffmt(fWatch.CpuTime())
00135                         << " , elapse" << ffmt(fWatch.RealTime())
00136                         << "  ");
00137
00138   fWatch.Stop();
00139   fQueryStage = kPassive;
00140
00141   if ( fCurSubWatch >= 0 && fWatch.RealTime() > 5. ) {
00142     for ( int subWatch = 0; subWatch <  kMaxSubWatch; ++subWatch) {
00143     static const Char_t* subWatchNames[kMaxSubWatch]
00144       = { "Query database     ",
00145           "Create row objects ",
00146           "Retrieve TSQL rows ",
00147           "Fill row objects   "};
00148        SK_DBI_Info(  "      SubWatch " <<  subWatchNames[subWatch]
00149             << ": Cpu" << ffmt(fSubWatches[subWatch].CpuTime())
00150             << " , elapse" << ffmt(fSubWatches[subWatch].RealTime())
00151             << " , Starts " << fSubWatches[subWatch].Counter()
00152             << "  ");
00153     }
00154   }
00155 }

Here is the caller graph for this function:

void TDbiTimer::RecFillAgg ( Int_t aggNo )

Definition at line 170 of file TDbiTimer.cxx.

00170                                             {
00171 //
00172 //
00173 //  Purpose:  Record filling of aggregate.
00174 //
00175 //  Arguments:
00176 //    aggNo        in    Aggregate number.
00177 //
00178 //  Contact:   N. West
00179
00180 }

void TDbiTimer::RecMainQuery ( )

Definition at line 158 of file TDbiTimer.cxx.

References fQueryStage, and kMainQuery.

Referenced by TDbiTimerManager::RecMainQuery().

00158                              {
00159 //
00160 //
00161 //  Purpose:  Record the start of main query.
00162 //
00163 //  Contact:   N. West
00164
00165   fQueryStage = kMainQuery;
00166
00167 }

Here is the caller graph for this function:

void TDbiTimer::Resume ( )

Definition at line 182 of file TDbiTimer.cxx.

References fCurSubWatch, fSubWatches, and fWatch.

Referenced by TDbiTimerManager::Pop().

00182                        {
00183 //
00184 //
00185 //  Purpose:  Resume timer and any partial timer.
00186 //
00187 //  Contact:   N. West
00188
00189   if ( fCurSubWatch >= 0 ) fSubWatches[fCurSubWatch].Start(kFALSE);
00190   fWatch.Start(kFALSE);
00191 }

Here is the caller graph for this function:

void TDbiTimer::StartSubWatch ( UInt_t subWatch )

Definition at line 195 of file TDbiTimer.cxx.

References fCurSubWatch, fSubWatches, and kMaxSubWatch.

Referenced by RecBegin(), and TDbiTimerManager::StartSubWatch().

00195                                              {
00196 //
00197 //
00198 //  Purpose:  Start specified SubWatch if SubWatch timers enabled.
00199 //
00200 //  Arguments:
00201 //    subWatch     in    SubWatch number ( 0 .. kMaxSubWatch-1 ).
00202 //
00203 //  Contact:   N. West
00204
00205   if (     fCurSubWatch < 0
00206         || subWatch >= kMaxSubWatch ) return;
00207
00208   fSubWatches[fCurSubWatch].Stop();
00209   fCurSubWatch = subWatch;
00210   fSubWatches[fCurSubWatch].Start(kFALSE);
00211
00212 }

Here is the caller graph for this function:

void TDbiTimer::Suspend ( )

Definition at line 214 of file TDbiTimer.cxx.

References fCurSubWatch, fSubWatches, and fWatch.

Referenced by TDbiTimerManager::Push().

00214                         {
00215 //
00216 //
00217 //  Purpose:  Suspend timer and any partial timer.
00218 //
00219 //  Contact:   N. West
00220
00221   if ( fCurSubWatch >= 0 ) fSubWatches[fCurSubWatch].Stop();
00222   fWatch.Stop();
00223 }
