TSK_DBI_Context Class Reference

#include <TSK_DBI_Context.hxx>

Collaboration diagram for TSK_DBI_Context:

Public Types
typedef unsigned int	Time
Public Member Functions
	TSK_DBI_Context ()
	Construct an empty context.
	TSK_DBI_Context (int run, int subRun, int event, int timestamp, int spill, int dataMC=1)
	Construct a context.
virtual	~TSK_DBI_Context ()
int	GetDataMC () const
bool	IsMC () const
	Add a convenient check to see if this is MC data.
void	SetDataMC (int dm)
int	GetRun () const
	Return the run number for this context.
void	SetRun (int r)
	Set the run number for this context.
int	GetSubRun () const
	Return the sub-run number for this context.
void	SetSubRun (int s)
	Set the sub-run number for this context.
int	GetEvent () const
	Return the event number for this context.
void	SetEvent (int e)
	Set the event number for this context.
int	GetSpill () const
	Return the spill number for this context.
void	SetSpill (int s)
	Set the spill number for this context.
int	GetTimeStamp () const
	Return the time stamp for this event (only valid to 1 sec).
std::string	GetTimeStampString () const
	Return the time stamp for this event as a MYSQL compatible time string.
void	SetTimeStamp (int t)
	Set the time stamp for this event.
bool	Valid () const
Static Public Attributes
static const int	Invalid = 0xDEADBEEF
	A special field value that specifies that the field is invalid.
Private Member Functions
	ClassDef (TSK_DBI_Context, 1)
Private Attributes
int	fRun
	The run number associated with this context.
int	fSubRun
	The sub-run number associated with this context.
int	fEvent
	The event number associated with this context.
int	fSpill
	The spill number associated with this context.
Time	fTimeStamp
	The unix time stamp associated with this context.
int	fDataMC
	data/MC flag. data = 1, MC = 4

Detailed Description

Define the context of an event. The event context uniquely identifies an event within SK_DBI. Due to the way events are formed, not all event (or slow control data) will have all fields of the context information defined. Fields that do not contain valid data should be marked using the value TSK_DBI_Context::Invalid.

Definition at line 14 of file TSK_DBI_Context.hxx.

Member Typedef Documentation

typedef unsigned int TSK_DBI_Context::Time

Definition at line 16 of file TSK_DBI_Context.hxx.

Constructor & Destructor Documentation

TSK_DBI_Context::TSK_DBI_Context ( )

Construct an empty context.

Definition at line 10 of file TSK_DBI_Context.cxx.

00011     : fRun(Invalid), fSubRun(Invalid), fEvent(Invalid),
00012       fSpill(Invalid), fTimeStamp(Invalid), fDataMC(1){}

TSK_DBI_Context::TSK_DBI_Context	(	int	run,
		int	subRun,
		int	event,
		int	timestamp,
		int	spill,
		int	dataMC = `1`
	)

Construct a context.

Definition at line 14 of file TSK_DBI_Context.cxx.

00016     : fRun(run), fSubRun(subRun), fEvent(event),
00017       fSpill(spill), fTimeStamp(stamp), fDataMC(dataMC) {}

virtual TSK_DBI_Context::~TSK_DBI_Context ( ) [virtual]

Member Function Documentation

TSK_DBI_Context::ClassDef	(	TSK_DBI_Context	,
		1
	)			`[private]`

int TSK_DBI_Context::GetDataMC ( ) const [inline]

Get dataMC variable data = 1, MC = 4

Definition at line 31 of file TSK_DBI_Context.hxx.

References fDataMC.

00031 { return fDataMC;}

int TSK_DBI_Context::GetEvent ( ) const

Return the event number for this context.

Definition at line 21 of file TSK_DBI_Context.cxx.

References fEvent.

Referenced by operator<<(), and Valid().

00021 {return fEvent;}

Here is the caller graph for this function:

int TSK_DBI_Context::GetRun ( ) const

Return the run number for this context.

Definition at line 19 of file TSK_DBI_Context.cxx.

References fRun.

Referenced by operator<<(), and Valid().

00019 {return fRun;}

Here is the caller graph for this function:

int TSK_DBI_Context::GetSpill ( ) const

Return the spill number for this context.

Definition at line 22 of file TSK_DBI_Context.cxx.

References fSpill.

Referenced by operator<<(), and Valid().

00022 {return fSpill;}

Here is the caller graph for this function:

int TSK_DBI_Context::GetSubRun ( ) const

Return the sub-run number for this context.

Definition at line 20 of file TSK_DBI_Context.cxx.

References fSubRun.

Referenced by operator<<(), and Valid().

00020 {return fSubRun;}

Here is the caller graph for this function:

int TSK_DBI_Context::GetTimeStamp ( ) const

Return the time stamp for this event (only valid to 1 sec).

Definition at line 29 of file TSK_DBI_Context.cxx.

References fTimeStamp.

Referenced by GetTimeStampString(), operator<<(), and Valid().

00029 {return fTimeStamp;}

Here is the caller graph for this function:

std::string TSK_DBI_Context::GetTimeStampString ( ) const

Return the time stamp for this event as a MYSQL compatible time string.

Definition at line 31 of file TSK_DBI_Context.cxx.

References GetTimeStamp().

00031                                                     {
00032     std::time_t t = GetTimeStamp();
00033     char buf[256];
00034     std::strftime(buf,sizeof(buf),"'%Y-%m-%d %H:%M:%S'",std::gmtime(&t));
00035     return std::string(buf);
00036 }

Here is the call graph for this function:

bool TSK_DBI_Context::IsMC ( ) const

Add a convenient check to see if this is MC data.

Definition at line 23 of file TSK_DBI_Context.cxx.

References fDataMC.

Referenced by operator<<(), and TVldContext::TVldContext().

00023                                  {
00024   if(fDataMC == 4)
00025     return true;
00026   return false;
00027 }

Here is the caller graph for this function:

void TSK_DBI_Context::SetDataMC ( int dm )

Set dataMC variable data = 1, MC = 4

Definition at line 43 of file TSK_DBI_Context.cxx.

References fDataMC.

00043 {fDataMC = dataMC;}

void TSK_DBI_Context::SetEvent ( int e )

Set the event number for this context.

Definition at line 40 of file TSK_DBI_Context.cxx.

References fEvent.

00040 {fEvent = v;}

void TSK_DBI_Context::SetRun ( int r )

Set the run number for this context.

Definition at line 38 of file TSK_DBI_Context.cxx.

References fRun.

00038 {fRun = v;}

void TSK_DBI_Context::SetSpill ( int s )

Set the spill number for this context.

Definition at line 41 of file TSK_DBI_Context.cxx.

References fSpill.

00041 {fSpill = v;}

void TSK_DBI_Context::SetSubRun ( int s )

Set the sub-run number for this context.

Definition at line 39 of file TSK_DBI_Context.cxx.

References fSubRun.

00039 {fSubRun = v;}

void TSK_DBI_Context::SetTimeStamp ( int t )

Set the time stamp for this event.

Definition at line 42 of file TSK_DBI_Context.cxx.

References fTimeStamp.

Referenced by main().

00042 {fTimeStamp = v;}

Here is the caller graph for this function:

bool TSK_DBI_Context::Valid ( ) const

Return true if the context is valid. A valid context is defined as a context where one or more fields is valid.

Definition at line 45 of file TSK_DBI_Context.cxx.

References fDataMC, GetEvent(), GetRun(), GetSpill(), GetSubRun(), GetTimeStamp(), and Invalid.

00045                                   {
00046     if (GetRun()!=TSK_DBI_Context::Invalid)  return true;
00047     if (GetSubRun()!=TSK_DBI_Context::Invalid) return true;
00048     if (GetEvent()!=TSK_DBI_Context::Invalid) return true;
00049     if (GetSpill()!=TSK_DBI_Context::Invalid) return true;
00050     if (GetTimeStamp()!=TSK_DBI_Context::Invalid) return true;
00051     if (fDataMC!=TSK_DBI_Context::Invalid) return true;
00052     return false;
00053 }
