To follow up; with some help from Konstantin and Stefan, we realized that this
particular problem should already be fixed.  While I was using the most recent version
of MIDAS, I hadn't rebuild the EPICS frontend programs when I was doing this test.  Once
I did that the error no longer occurred.  This is because the most recent version of
MIDAS includes a check that will resize these particular string variables before using
them (technically, this is included in db_get_record1()); this resizing only happens for
these couple strings that must have a fixed size.

We are still having a separate discussion about whether this treatment of string lengths
that need to have a fixed size can be further improved.  Will update once discussion
converges.


> I guess this might be related to the changes in the last elog conversation; but
> I'll break it out as a separate problem.
>
> The new mhttpd ODB editor seems to resize all strings (not just strings that are
> greater than 256 characters).  So, when I change some string with the mhttpd ODB
> editor to 'ffffff', then I find that the string size is now ~7 characters.
>
> This might be fine in general; but it seems to cause a problem when dealing with
> alarms.  In particular, I find that if I try to set (through mhttpd) the
> "execute command" for an alarm class or the "condition" for an alarm, then I get
> into lots of trouble.  For instance, I changed the "execute command" for my
> alarm class through mhttpd; when associated alarms were triggered, I got errors
>
> 21:58:12 [feSourceEpics,ERROR] [odb.c:9133:db_get_record,ERROR] struct size
> mismatch for "/Alarms/Classes/Alarm" (expected size: 348, size in ODB: 100)
> 21:58:12 [feSourceEpics,ERROR] [alarm.c:379:al_trigger_class,ERROR] Cannot get
> alarm class record
>
> This makes sense, since ALARM_CLASS has a fixed size
>
> typedef struct {
>    BOOL write_system_message;
>    ...
>    char execute_command[256];
>    ...
>    char display_fgcolor[32];
> } ALARM_CLASS;
>
> so problems will clearly occur when I change the size and try to grab it:
>
>    ALARM_CLASS ac;
>    status = db_get_record1(hDB, hkeyclass, &ac, &size, 0, strcomb(alarm_class_str));
>
> I guess that similar problems also occur if you edit the string for ALARM or
> PROGRAM_INFO instances.  These problems do not occur when I change my strings
> with odbedit, which doesn't resize strings below 256.
>
> I'm not sure what the proper solution is.  A temporary solution is that the
> mhttpd ODB editor shouldn't resize strings if the new size is less than 256
> characters; in that case the size should be left as 256 characters.
>
> This test was done with MIDAS git repository as of today:
> commit 45a90dc329554f528485da121501daf6ecde100d

bug in init
-----------

I used the lv.c class driver, combined with a custom device driver, to control
our Keithley2611B source meter. This to set negative voltage on Si detectors.

In the 'init' routing, the class driver sets the hv:

  hv_info->demand_mirror[i] = MIN(hv_info->demand[i], hv_info->voltage_limit[i]);

This fails for negative voltage, as it sets the (negative) voltage limit, instead
of the demand voltage. A simple 'fabs' solves this.

suggestion for 'idle'
---------------------

I let the device do the ramping, not the driver. This also means I have to reset
the state of the device (current limit) after ramping. The easiest way to to
this, is using CMD_IDLE of the device driver. This is currently not done in the
hv.c class driver.

Hi, Frederick, this is my personal opinion on the slow controls hv classes, I have
used them a couple of times and I found them full of little buglets like this,
plus some incomplete functions, plus some missing features, plus it is all
written in C trying to do object oriented programming. On the balance my opinion
is that it is less work to write a high voltage control program in C++ from scratch
using the regular midas frontend infrastructure compared to having to understand
the hv class driver, write the missing bits, fix the little buglets, debug
the crashes in the C string handling, and what not. (For example I had to debug
mysterious failures to pass float and double values through the C stdarg interface,
there are more fun things to do out there).

K.O.

> bug in init
> -----------
>
> I used the lv.c class driver, combined with a custom device driver, to control
> our Keithley2611B source meter. This to set negative voltage on Si detectors.
>
> In the 'init' routing, the class driver sets the hv:
>
>   hv_info->demand_mirror[i] = MIN(hv_info->demand[i], hv_info->voltage_limit[i]);
>
> This fails for negative voltage, as it sets the (negative) voltage limit, instead
> of the demand voltage. A simple 'fabs' solves this.
>
> suggestion for 'idle'
> ---------------------
>
> I let the device do the ramping, not the driver. This also means I have to reset
> the state of the device (current limit) after ramping. The easiest way to to
> this, is using CMD_IDLE of the device driver. This is currently not done in the
> hv.c class driver.

> bug in init
> -----------
>
> I used the lv.c class driver, combined with a custom device driver, to control
> our Keithley2611B source meter. This to set negative voltage on Si detectors.
>
> In the 'init' routing, the class driver sets the hv:
>
>   hv_info->demand_mirror[i] = MIN(hv_info->demand[i], hv_info->voltage_limit[i]);
>
> This fails for negative voltage, as it sets the (negative) voltage limit, instead
> of the demand voltage. A simple 'fabs' solves this.
>
> suggestion for 'idle'
> ---------------------
>
> I let the device do the ramping, not the driver. This also means I have to reset
> the state of the device (current limit) after ramping. The easiest way to to
> this, is using CMD_IDLE of the device driver. This is currently not done in the
> hv.c class driver.

I can't find the line you quote in the class driver. Why don't you make a git pull request
and I will approve it.

The original idea behind the hv driver is that all voltages in the ODB and the class driver are
positive. If you have a negative power supply, then the voltage is inverted at the device
driver level. That's why you have MIN and MAX in the class driver.

Stefan

>
> The original idea behind the hv driver is that all voltages in the ODB and the class driver are
> positive. If you have a negative power supply, then the voltage is inverted at the device
> driver level. That's why you have MIN and MAX in the class driver.
>

This rings a bell. I used the hv class driver to write a frontend for the L1440 mainframe (negative voltage),
on ODB it will be positive values, when writing to the device I had to add a minus sign,
and when reading back they came back negative and I had to add an fabs() in the comparison
between readback and demand.

Persons with bipolar power supplies need not apply.

K.O.

There is a small bug in the mfe.c initialization for the EQ_POLLED mode. There
is a routine where the number of polls fitting in eq_info->period is counted:


         count = 1;
         do {
            if (display_period)
               printf(".");

            start_time = ss_millitime();

            poll_event(equipment[idx].info.source, (INT)count, TRUE);

            delta_time = ss_millitime() - start_time;

            ...

            if (delta_time > 0)
               count = count * eq_info->period / delta_time;
            else
               count *= 100;

            // avoid overflows
            if (count > 2147483647.0) {
               count = 2147483647.0;
               break;
            }

         } while (delta_time > eq_info->period * 1.2 || delta_time < eq_info-
>period * 0.8);

As "start_time = ss_millitime();" resets "delta_time" each time, only the
"avoid overflows" addition saves the day.

start_time = ss_millitime(); show be out of the loop.

> There is a small bug in the mfe.c initialization for the EQ_POLLED mode. There
> is a routine where the number of polls fitting in eq_info->period is counted:
>
>
>          count = 1;
>          do {
>             if (display_period)
>                printf(".");
>
>             start_time = ss_millitime();
>
>             poll_event(equipment[idx].info.source, (INT)count, TRUE);
>
>             delta_time = ss_millitime() - start_time;
>
>             ...
>
>             if (delta_time > 0)
>                count = count * eq_info->period / delta_time;
>             else
>                count *= 100;
>
>             // avoid overflows
>             if (count > 2147483647.0) {
>                count = 2147483647.0;
>                break;
>             }
>
>          } while (delta_time > eq_info->period * 1.2 || delta_time < eq_info-
> >period * 0.8);
>
> As "start_time = ss_millitime();" resets "delta_time" each time, only the
> "avoid overflows" addition saves the day.
>
> start_time = ss_millitime(); show be out of the loop.

Nope.

What I want is to determine how often I have to call poll_event to stay there for a certain time (usually 100ms). So I iterate "count" until I roughly get to my 100ms. Each call to
poll_event with a different count is a new measurement, therefore I initialize start_time before each measurement. If i do it outside the loop, and kind of incrementally increase
it, then the whole code inside the loop is added to the measurement which makes it (slightly) wrong.

The whole loop optimization has some background. Polling can be sow (think of talking to a device via Ethernet which can easily take milli seconds). So how often do we poll
before we do other things in the main look (like looking if a run has been started). If I only poll once, then the average front-end response time would be poor, because I mostly
look if a run has been started in the main loop. This is not effective. If I poll too often inside the poll_event loop, then the front-end does not react on run stops any more. So
there is some optimum, and this is set by the polling time of usually 100ms. This ensures that the front-end does optimal polling - without ANYTHING in between - for about
100ms. But how can I know how often I should poll for 100 ms? As said above, polling can be very fast (reading a memory cell) or very slow (network). The the best method I
found is to do a calibration at the startup, and this is what the code above does. Maybe there are better ways today, but that code worked nicely in the last 25 years.

Stefan

> > There is a small bug in the mfe.c initialization for the EQ_POLLED mode. There
> > is a routine where the number of polls fitting in eq_info->period is counted:
> >
> >
> >          count = 1;
> >          do {
> >             if (display_period)
> >                printf(".");
> >
> >             start_time = ss_millitime();
> >
> >             poll_event(equipment[idx].info.source, (INT)count, TRUE);
> >
> >             delta_time = ss_millitime() - start_time;
> >
> >             ...
> >
> >             if (delta_time > 0)
> >                count = count * eq_info->period / delta_time;
> >             else
> >                count *= 100;
> >
> >             // avoid overflows
> >             if (count > 2147483647.0) {
> >                count = 2147483647.0;
> >                break;
> >             }
> >
> >          } while (delta_time > eq_info->period * 1.2 || delta_time < eq_info-
> > >period * 0.8);
> >
> > As "start_time = ss_millitime();" resets "delta_time" each time, only the
> > "avoid overflows" addition saves the day.
> >
> > start_time = ss_millitime(); show be out of the loop.
>
> Nope.
>
> What I want is to determine how often I have to call poll_event to stay there for a certain time (usually 100ms). So I iterate "count" until I roughly get to my 100ms. Each call to
> poll_event with a different count is a new measurement, therefore I initialize start_time before each measurement. If i do it outside the loop, and kind of incrementally increase
> it, then the whole code inside the loop is added to the measurement which makes it (slightly) wrong.
>
> The whole loop optimization has some background. Polling can be sow (think of talking to a device via Ethernet which can easily take milli seconds). So how often do we poll
> before we do other things in the main look (like looking if a run has been started). If I only poll once, then the average front-end response time would be poor, because I mostly
> look if a run has been started in the main loop. This is not effective. If I poll too often inside the poll_event loop, then the front-end does not react on run stops any more. So
> there is some optimum, and this is set by the polling time of usually 100ms. This ensures that the front-end does optimal polling - without ANYTHING in between - for about
> 100ms. But how can I know how often I should poll for 100 ms? As said above, polling can be very fast (reading a memory cell) or very slow (network). The the best method I
> found is to do a calibration at the startup, and this is what the code above does. Maybe there are better ways today, but that code worked nicely in the last 25 years.
>
> Stefan

Thanks, I misunderstood the loop then. If poll_event(equipment[idx].info.source, (INT)count, TRUE); doesn`t do anything with "count", the loop becomes infinite except for the overflow
check.

> Thanks, I misunderstood the loop then. If poll_event(equipment[idx].info.source, (INT)count, TRUE); doesn`t do anything with "count", the loop becomes infinite except for the overflow
> check.

Well, the function poll_event() is _supposed_ to use "count" in a for loop as written in the example frontend:

   for (i = 0; i < count; i++) {
      /* poll hardware and set flag to TRUE if new event is available */
      flag = TRUE;

      if (flag)
         if (!test)
            return TRUE;
   }

where "flag = TRUE" must be replaced with the proper hardware check. This can be a VME access, a network TCP exchange with some Ethernet based hardware, or even a mutex check if the events are collected by a
separate thread in the frontend.

The idea of having the for (i=0 ; i<count ; i++) loop _inside_ the poll_event() function and not outside is the fact that each function call to poll_event() takes time, and we want the minimal possible response time to new
events. It might be just a micro-second, but having an experiment running at 100 Hz for one year (like Mu3e), this adds up to about one hour per year, which is a considerable amount of precious beam time.

Stefan

Description of the problem (starting with 61be7a1):

When starting a new experiment, creating a fresh ODB and than adding the
directory '/Custom', the mhttpd runs into a problem on RHEL/Fedora, but not on
Ubuntu and macOS. When trying to open the ODB from within whatever browser I get
the following error message in the midas message queque:

[mhttpd,ERROR] [mhttpd.cxx:563:rread,ERROR] Cannot read file '/root', read of
4096 returned -1, errno 21 (Is a directory)

and in the browser I get a popup which tries to save a file called 'root'.

I track this down to the following: in mhttpd, interprete (line 18046) it is
check if a custom page file exists (ss_file_exist) and if yes, it tries to 'load'
it. Now, at this stage the variable dec_path contains '/root'.

Here now what goes wrong: ss_file_exist tries to open the given path, and if a
valid file descriptor is returned it assumes the file exists. This is not
perfectly correct since it also will get a valid file descriptor is path is an
accessible directory!

Now for whatever reason, on RHEL/Fedora '/root' will return a valid file
descriptor, but not on macOS and Ubuntu. Others I haven't tested. A possible fix
would be to check explicitly if path is a directory and if yes return 0 in
ss_file_exist (see attached diff).

Perhaps there is cleaner way to deal with this issue?!

> [mhttpd,ERROR] [mhttpd.cxx:563:rread,ERROR] Cannot read file '/root', read of
> 4096 returned -1, errno 21 (Is a directory)

On some linux systems, "/root" exists, it is a directory used as the home directory
of user "root" (~root is /root; traditional UNIX has ~root as /).

open() of a directory succeeds on some UNIX systems, on some of them,
read() also works, but on other systems one is supposed
to use opendir() and readdir().

MacOS is of course a BSD system (not SysV like Solaris, not Linux), so things
are different yet again. I think MacOS does not have a /root.

In any case, IMO, mhttpd has no business serving the contents of /root,
or serving any files outside of the mhttpd user $HOME directory. (but also
should not serve files from ~user/.ssh, or any other "secret" files, good
luck making a complete axhuastive list of all secret files that should not be
served).

K.O.


>
> and in the browser I get a popup which tries to save a file called 'root'.
>
> I track this down to the following: in mhttpd, interprete (line 18046) it is
> check if a custom page file exists (ss_file_exist) and if yes, it tries to 'load'
> it. Now, at this stage the variable dec_path contains '/root'.
>
> Here now what goes wrong: ss_file_exist tries to open the given path, and if a
> valid file descriptor is returned it assumes the file exists. This is not
> perfectly correct since it also will get a valid file descriptor is path is an
> accessible directory!
>
> Now for whatever reason, on RHEL/Fedora '/root' will return a valid file
> descriptor, but not on macOS and Ubuntu. Others I haven't tested. A possible fix
> would be to check explicitly if path is a directory and if yes return 0 in
> ss_file_exist (see attached diff).
>
> Perhaps there is cleaner way to deal with this issue?!

> In any case, IMO, mhttpd has no business serving the contents of /root,
> or serving any files outside of the mhttpd user $HOME directory. (but also
> should not serve files from ~user/.ssh, or any other "secret" files, good
> luck making a complete axhuastive list of all secret files that should not be
> served).

I fully agree with Konstantin. mhttpd should only serve files under certain directories. One is the
midas/resources directory, another is the one defined in the ODB under /Custom/Path. I plan to modify
mhttpd to only serve these files (and also prevent tricks like putting "../../../" into the URL). This will then
also fix Andreas' problem.

Stefan

> > In any case, IMO, mhttpd has no business serving the contents of /root,
> > or serving any files outside of the mhttpd user $HOME directory. (but also
> > should not serve files from ~user/.ssh, or any other "secret" files, good
> > luck making a complete axhuastive list of all secret files that should not be
> > served).
>
> I fully agree with Konstantin. mhttpd should only serve files under certain directories. One is the
> midas/resources directory, another is the one defined in the ODB under /Custom/Path. I plan to modify
> mhttpd to only serve these files (and also prevent tricks like putting "../../../" into the URL). This will then
> also fix Andreas' problem.
>
> Stefan

Yes, I think this is a good idea as well. But just to make sure that you get the problem: it's not the custom page call by itself! If you currently type e.g. <midas-server>/root it will open the ODB html-page.

Pierre Gorel identified a problem with the 'start program' button on the new version of MIDAS that uses the
mjsonrpc functions for building the webpages.  In particular, he tracked the problem down to some
questionable std::string / char* handling.

Interestingly, the particular 'start program' problem was seen on Pierre's Ubuntu 16.04.3 LTS machine, but
could not be reproduced on RHEL-7 or Macos 10.13 machines.  So the manifestation of the code error
seemed to depend on the compiler.

The problem should now be fixed in the HEAD version of MIDAS.  If you are using the newer MIDAS (since last
summer), particularly on Ubuntu, then you may want to update your installation.

Details of the problem are on the bitbucket issue tracker:

https://bitbucket.org/tmidas/midas/issues/132/corruption-of-char-in-mjsonrpccxx

There is a bug in the string handling when changing ODB string entries via the
mhttpd (git sha 07dfb83). It truncates the string length in the ODB.

For instance I create a string with length 32 and set it with odbedit to 'a'.
Then the string length stays 32, as expected. If the same is done through the
web-interface, the string length will be truncated to 2.

This can lead to problems if some frontend has a hotlink to a structure
containing this string since it will complain about structure size mismatch.

> There is a bug in the string handling when changing ODB string entries via the
> mhttpd (git sha 07dfb83). It truncates the string length in the ODB.
>
> For instance I create a string with length 32 and set it with odbedit to 'a'.
> Then the string length stays 32, as expected. If the same is done through the
> web-interface, the string length will be truncated to 2.
>
> This can lead to problems if some frontend has a hotlink to a structure
> containing this string since it will complain about structure size mismatch.

I know about this problem since last summer. I mentioned it to KO, since it's deep down in his
JSONRPC code. We had a long discussion, where he kind of insisted that this is not a bug but a
feature. The ODB should store strings with variable lengths, and thus adapt it according to the
current string length. This makes some sense, since in the future we plan to put C++ string
support for the ODB, where strings have dynamically varying lengths. But this will take a while, so
I asked KO to change the truncation of the strings though the web interface, because this breaks
many experiments. He did not react so far. Several people complained. Maybe your request will
help now.

Stefan

> > There is a bug in the string handling when changing ODB string entries via the
> > mhttpd (git sha 07dfb83). It truncates the string length in the ODB.
> >
> > For instance I create a string with length 32 and set it with odbedit to 'a'.
> > Then the string length stays 32, as expected. If the same is done through the
> > web-interface, the string length will be truncated to 2.
> >
> > This can lead to problems if some frontend has a hotlink to a structure
> > containing this string since it will complain about structure size mismatch.
>
> I know about this problem since last summer. I mentioned it to KO, since it's deep down in his
> JSONRPC code. We had a long discussion, where he kind of insisted that this is not a bug but a
> feature. The ODB should store strings with variable lengths, and thus adapt it according to the
> current string length. This makes some sense, since in the future we plan to put C++ string
> support for the ODB, where strings have dynamically varying lengths. But this will take a while, so
> I asked KO to change the truncation of the strings though the web interface, because this breaks
> many experiments. He did not react so far. Several people complained. Maybe your request will
> help now.
>
> Stefan

Well I appreciate the direction towards more C++ string handling, yet it must not break the hotlink
functionality which is very important at many places.

Further to my last message, I see that a midas version from 2013 does indeed display
links to arrays as I would expect (see attachment). Therefore the problem in later
versions  is a bug rather than a feature.


> A link to an array variable such as
>
> [local:npet:Stopped]/>ls /rcparams/ControlVariables/
> TRFC:PB5 (V) -> /Equipment/Beamline/Variables/Demand[56]
>                                 17835
>
> displays the whole Demand array on the mhttpd ODB page (see attachment)
> rather than just the one element Demand[56].
> This behaviour also occurs with older versions of mhttpd.
>
> Not sure if it's a bug or a feature, but my suggestion is that it
> ought to display the one element only (as odbedit does) and not the whole array.
>
> Suzannah

It might have worked some ~5 years ago, but it never really showed the target value of a link, just the
link itself. I reworked the code now to show both the link and the target of the link, so you can change
both in the mhttpd ODB page. Should be consistent now with odbedit. Have a look if it works for you.

Stefan

> It might have worked some ~5 years ago, but it never really showed the target value of a link, just the
> link itself. I reworked the code now to show both the link and the target of the link, so you can change
> both in the mhttpd ODB page. Should be consistent now with odbedit. Have a look if it works for you.
>
> Stefan

Thank you. That has solved the problem.
Suzannah
