TComplicatedExampleCanvas Class Reference

A complicated canvas example, using the values from V792 module. More...

#include <TComplicatedExampleCanvas.hxx>

Inheritance diagram for TComplicatedExampleCanvas:

[legend]

Collaboration diagram for TComplicatedExampleCanvas:

[legend]

List of all members.

Public Member Functions
	TComplicatedExampleCanvas ()
void	ResetCanvasHistograms ()
	Reset the histograms for this canvas.
void	UpdateCanvasHistograms (TDataContainer &dataContainer)
	Update the histograms for this canvas.
void	PlotCanvas (TDataContainer &dataContainer, TRootEmbeddedCanvas *embedCanvas)
	Plot the histograms for this canvas.
void	SetUpCompositeFrame (TGCompositeFrame compFrame, TRootanaDisplay display)
void	BeginRun (int transition, int run, int time)
	Take actions at begin run.
	TComplicatedExampleCanvas ()
void	ResetCanvasHistograms ()
	Reset the histograms for this canvas.
void	UpdateCanvasHistograms (TDataContainer &dataContainer)
	Update the histograms for this canvas.
void	PlotCanvas (TDataContainer &dataContainer, TRootEmbeddedCanvas *embedCanvas)
	Plot the histograms for this canvas.
void	SetUpCompositeFrame (TGCompositeFrame compFrame, TRootanaDisplay display)
void	BeginRun (int transition, int run, int time)
	Take actions at begin run.
virtual void	EndRun (int transition, int run, int time)
	Take actions at end run.
virtual void	EndRun (int transition, int run, int time)
	Take actions at end run.
std::string	GetTabName ()
std::string	GetTabName ()
TRootEmbeddedCanvas *	GetEmbeddedCanvas ()
	This method is only.
TRootEmbeddedCanvas *	GetEmbeddedCanvas ()
	This method is only.
Private Attributes
TH1F *	adcValue [32]
TGNumberEntry *	fBankCounterButton

Detailed Description

A complicated canvas example, using the values from V792 module.

Definition at line 13 of file TComplicatedExampleCanvas.hxx.

Constructor & Destructor Documentation

TComplicatedExampleCanvas::TComplicatedExampleCanvas ( )

Definition at line 9 of file TComplicatedExampleCanvas.cxx.

References adcValue.

00009                                                     : TCanvasHandleBase("V792 ADC Values"){
00010
00011   for(int i = 0; i < 32; i++){
00012     char name[100];
00013     char title[100];
00014     sprintf(name,"adcValue%i",i+10);
00015     sprintf(title,"ADC values for channel %i",i);
00016     adcValue[i] = new TH1F(name,title,2000,0,4000);
00017   }
00018 }

TComplicatedExampleCanvas::TComplicatedExampleCanvas ( )

Member Function Documentation

void TComplicatedExampleCanvas::BeginRun	(	int	transition,
		int	run,
		int	time
	)			`[inline, virtual]`

Take actions at begin run.

Reimplemented from TCanvasHandleBase.

Definition at line 29 of file TComplicatedExampleCanvas.hxx.

00029                                                 {
00030     std::cout << "BOR: User can do something here... " << std::endl;
00031   }

void TComplicatedExampleCanvas::BeginRun	(	int	transition,
		int	run,
		int	time
	)			`[inline, virtual]`

Take actions at begin run.

Reimplemented from TCanvasHandleBase.

Definition at line 29 of file TComplicatedExampleCanvas.hxx.

00029                                                 {
00030     std::cout << "BOR: User can do something here... " << std::endl;
00031   }

virtual void TCanvasHandleBase::EndRun	(	int	transition,
		int	run,
		int	time
	)			`[inline, virtual, inherited]`

Take actions at end run.

Reimplemented in TFancyHistogramCanvas, and TFancyHistogramCanvas.

Definition at line 36 of file TCanvasHandleBase.hxx.

00036 {};

virtual void TCanvasHandleBase::EndRun	(	int	transition,
		int	run,
		int	time
	)			`[inline, virtual, inherited]`

Take actions at end run.

Reimplemented in TFancyHistogramCanvas, and TFancyHistogramCanvas.

Definition at line 36 of file TCanvasHandleBase.hxx.

00036 {};

TRootEmbeddedCanvas* TCanvasHandleBase::GetEmbeddedCanvas ( ) [inline, inherited]

This method is only.

Definition at line 41 of file TCanvasHandleBase.hxx.

00041                                           {
00042     std::cerr<< "Not implemented for base class; exiting." << std::endl;
00043     exit(0);
00044     return 0;
00045   }

TRootEmbeddedCanvas* TCanvasHandleBase::GetEmbeddedCanvas ( ) [inline, inherited]

This method is only.

Definition at line 41 of file TCanvasHandleBase.hxx.

00041                                           {
00042     std::cerr<< "Not implemented for base class; exiting." << std::endl;
00043     exit(0);
00044     return 0;
00045   }

std::string TCanvasHandleBase::GetTabName ( ) [inline, inherited]

Definition at line 38 of file TCanvasHandleBase.hxx.

References TCanvasHandleBase::fTabName.

00038 {return fTabName;}

std::string TCanvasHandleBase::GetTabName ( ) [inline, inherited]

Definition at line 38 of file TCanvasHandleBase.hxx.

References TCanvasHandleBase::fTabName.

Referenced by TRootanaDisplay::AddSingleCanvas().

00038 {return fTabName;}

Here is the caller graph for this function:

void TComplicatedExampleCanvas::PlotCanvas	(	TDataContainer &	dataContainer,
		TRootEmbeddedCanvas *	embedCanvas
	)			`[virtual]`

Plot the histograms for this canvas.

Implements TCanvasHandleBase.

void TComplicatedExampleCanvas::PlotCanvas	(	TDataContainer &	dataContainer,
		TRootEmbeddedCanvas *	embedCanvas
	)			`[virtual]`

Plot the histograms for this canvas.

Implements TCanvasHandleBase.

Definition at line 74 of file TComplicatedExampleCanvas.cxx.

References adcValue, and fBankCounterButton.

00074                                                                                                          {
00075
00076   TCanvas* c1 = embedCanvas->GetCanvas();
00077   c1->Clear();
00078   int whichbank = fBankCounterButton->GetNumberEntry()->GetIntNumber();
00079   if(whichbank >=0 && whichbank <32)
00080     adcValue[whichbank]->Draw();
00081   c1->Modified();
00082   c1->Update();
00083
00084 }

void TComplicatedExampleCanvas::ResetCanvasHistograms ( ) [virtual]

Reset the histograms for this canvas.

Implements TCanvasHandleBase.

void TComplicatedExampleCanvas::ResetCanvasHistograms ( ) [virtual]

Reset the histograms for this canvas.

Implements TCanvasHandleBase.

Definition at line 46 of file TComplicatedExampleCanvas.cxx.

References adcValue.

00046                                                      {
00047
00048   for(int i = 0; i < 32; i++)
00049     adcValue[i]->Reset();
00050 }

void TComplicatedExampleCanvas::SetUpCompositeFrame	(	TGCompositeFrame *	compFrame,
		TRootanaDisplay *	display
	)			`[virtual]`

Reimplemented from TCanvasHandleBase.

void TComplicatedExampleCanvas::SetUpCompositeFrame	(	TGCompositeFrame *	compFrame,
		TRootanaDisplay *	display
	)			`[virtual]`

Reimplemented from TCanvasHandleBase.

Definition at line 20 of file TComplicatedExampleCanvas.cxx.

References fBankCounterButton.

00020                                                                                                         {
00021
00022
00023   // Now create my embedded canvas, along with the various buttons for this canvas.
00024
00025   TGHorizontalFrame *labelframe = new TGHorizontalFrame(compFrame,200,40);
00026
00027   fBankCounterButton = new TGNumberEntry(labelframe, 0, 9,999, TGNumberFormat::kNESInteger,
00028                                               TGNumberFormat::kNEANonNegative,
00029                                               TGNumberFormat::kNELLimitMinMax,
00030                                               0, 31);
00031
00032   fBankCounterButton->Connect("ValueSet(Long_t)", "TRootanaDisplay", display, "UpdatePlotsAction()");
00033   fBankCounterButton->GetNumberEntry()->Connect("ReturnPressed()", "TRootanaDisplay", display, "UpdatePlotsAction()");
00034   labelframe->AddFrame(fBankCounterButton, new TGLayoutHints(kLHintsTop | kLHintsLeft, 5, 5, 5, 5));
00035   TGLabel *labelMinicrate = new TGLabel(labelframe, "ADC Channel (0-31)");
00036   labelframe->AddFrame(labelMinicrate, new TGLayoutHints(kLHintsTop | kLHintsLeft, 5, 5, 5, 5));
00037
00038   compFrame->AddFrame(labelframe, new TGLayoutHints(kLHintsCenterX,2,2,2,2));
00039
00040
00041 }

void TComplicatedExampleCanvas::UpdateCanvasHistograms ( TDataContainer & dataContainer ) [virtual]

Update the histograms for this canvas.

Implements TCanvasHandleBase.

void TComplicatedExampleCanvas::UpdateCanvasHistograms ( TDataContainer & dataContainer ) [virtual]

Update the histograms for this canvas.

Implements TCanvasHandleBase.

Definition at line 53 of file TComplicatedExampleCanvas.cxx.

References adcValue, VADCMeasurement::GetChannel(), TDataContainer::GetEventData(), VADCMeasurement::GetMeasurement(), and TV792Data::GetMeasurements().

00053                                                                                    {
00054
00055   // Get the V792 data
00056   TV792Data *v792 = dataContainer.GetEventData<TV792Data>("ADC0");
00057   if(v792 ){
00058
00059     // Loop over ADC measurements
00060     std::vector<VADCMeasurement>& measurements = v792->GetMeasurements();
00061     for(unsigned int i = 0; i < measurements.size(); i++){
00062       VADCMeasurement adcmeas = measurements[i];
00063
00064       // For each measurement, update histogram
00065       int chan = adcmeas.GetChannel();
00066       if(chan >= 0 && chan < 32){
00067         adcValue[chan]->Fill(adcmeas.GetMeasurement());
00068       }
00069     }
00070   }
00071 }

Here is the call graph for this function:

Member Data Documentation

TH1F * TComplicatedExampleCanvas::adcValue [private]

Definition at line 34 of file TComplicatedExampleCanvas.hxx.

Referenced by PlotCanvas(), ResetCanvasHistograms(), TComplicatedExampleCanvas(), and UpdateCanvasHistograms().

TGNumberEntry * TComplicatedExampleCanvas::fBankCounterButton [private]

Definition at line 35 of file TComplicatedExampleCanvas.hxx.

Referenced by PlotCanvas(), and SetUpCompositeFrame().

The documentation for this class was generated from the following files:

include/TComplicatedExampleCanvas.hxx
libAnalyzerDisplay/TComplicatedExampleCanvas.hxx
libAnalyzerDisplay/TComplicatedExampleCanvas.cxx
