TDbiBinaryFile Class Reference

Concept Binary file for reading/writing TDbi related objects. More...

#include <TDbiBinaryFile.hxx>

Collaboration diagram for TDbiBinaryFile:

Public Member Functions
	TDbiBinaryFile (const char *fileName="", Bool_t input=kTRUE)
	~TDbiBinaryFile ()
	Purpose: Default Destructor.
string	GetFileName () const
Bool_t	IsOK () const
Bool_t	IsReading () const
Bool_t	IsWriting () const
void	Close ()
	Purpose: Close file.
TDbiBinaryFile &	operator>> (Bool_t &num)
	Builtin data type I/O.
TDbiBinaryFile &	operator<< (const Bool_t &num)
TDbiBinaryFile &	operator>> (Int_t &num)
TDbiBinaryFile &	operator<< (const Int_t &num)
TDbiBinaryFile &	operator>> (UInt_t &num)
TDbiBinaryFile &	operator<< (const UInt_t &num)
TDbiBinaryFile &	operator>> (Double_t &num)
TDbiBinaryFile &	operator<< (const Double_t &num)
TDbiBinaryFile &	operator>> (TVldTimeStamp &ts)
TDbiBinaryFile &	operator<< (const TVldTimeStamp &ts)
TDbiBinaryFile &	operator>> (string &str)
TDbiBinaryFile &	operator<< (const string &str)
TDbiBinaryFile &	operator>> (TVldRange &vr)
	Compound object I/O.
TDbiBinaryFile &	operator<< (const TVldRange &vr)
TDbiBinaryFile &	operator>> (vector< TDbiTableRow * > &arr)
	Vector I/O.
TDbiBinaryFile &	operator<< (vector< TDbiTableRow * > &arr)
char *	ReleaseArrayBuffer ()
Static Public Member Functions
static Bool_t	CanReadL2Cache ()
	Global control of all created TDbiBinaryFile objects.
static Bool_t	CanWriteL2Cache ()
static void	SetWorkDir (const string &dir)
static void	SetReadAccess (Bool_t access=kTRUE)
static void	SetWriteAccess (Bool_t access=kTRUE)
Private Member Functions
Bool_t	CanRead ()
	The functions that do the low-level I/O.
Bool_t	CanWrite ()
void	CheckFileStatus ()
Bool_t	Read (char *bytes, UInt_t numBytes)
Bool_t	Write (const char *bytes, UInt_t numBytes)
Private Attributes
fstream *	fFile
	Associated file, may be null.
Bool_t	fReading
Bool_t	fHasErrors
char *	fArrayBuffer
string	fFileName
Static Private Attributes
static string	fgWorkDir
static Bool_t	fgReadAccess = kTRUE
static Bool_t	fgWriteAccess = kTRUE

Detailed Description

Concept Binary file for reading/writing TDbi related objects.

Purpose To save/restore cache to speed up startup when running in the same context. Contact: A.Finch@lancaster.ac.uk

Definition at line 42 of file TDbiBinaryFile.hxx.

Constructor & Destructor Documentation

TDbiBinaryFile::TDbiBinaryFile	(	const char *	fileName = `""`,
		Bool_t	input = `kTRUE`
	)

     Purpose:  Default Constructor.

     Arguments:
       fileName     in    File name (default: "" => file is a dummy)
       input        in    true if reading (default = kTRUE)

     Specification:-
     =============

     If file name or fgWorkDir is dummy, or the appropriate access is not set

JJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJJjjjjjjjjjjjjjjjjjjjjjjjjjjjjjjjjj / then name is set to dummy otherwise fgWorkDir is prepended to the name.

Definition at line 55 of file TDbiBinaryFile.cxx.

References fFile, fFileName, fgReadAccess, fgWorkDir, fgWriteAccess, fHasErrors, and SK_DBI_Debug.

00055                                                                   :
00056 fFile(0),
00057 fReading(input),
00058 fHasErrors(kFALSE),
00059 fArrayBuffer(0)
00060 {
00061 //
00062 //
00063 //  Purpose:  Default Constructor.
00064 //
00065 //  Arguments:
00066 //    fileName     in    File name (default: "" => file is a dummy)
00067 //    input        in    true if reading (default = kTRUE)
00068
00069 //  Specification:-
00070 //  =============
00071 //
00072 //  If file name or fgWorkDir is dummy, or the appropriate access is not set
00073 //  then name is set to dummy otherwise fgWorkDir is prepended to the name.
00074
00075   // Complete the file name.
00076   fFileName = fileName;
00077   if ( fFileName != "" ) {
00078     Bool_t access = input ? fgReadAccess : fgWriteAccess;
00079     if ( fgWorkDir == "" || ! access ) fFileName = "";
00080     else                               fFileName = fgWorkDir +  fFileName;
00081   }
00082
00083   // Open the file.
00084   ios_base::openmode mode = ios_base::in|ios_base::binary;
00085   if ( ! input ) mode = ios_base::out|ios_base::binary;
00086
00087   if ( fFileName == "" ) fHasErrors = kTRUE;
00088   else {
00089     fFile = new fstream(fFileName.c_str(),mode);
00090     if ( ! fFile->is_open() || ! fFile->good() ) {
00091       SK_DBI_Debug( "Cannot open " << fFileName
00092                              << "; all I/O will fail." << "  ");
00093       fHasErrors = kTRUE;
00094     }
00095   }
00096
00097 }
//.....................................................................

TDbiBinaryFile::~TDbiBinaryFile ( )

Purpose: Default Destructor.

Definition at line 100 of file TDbiBinaryFile.cxx.

References Close(), fArrayBuffer, and fFile.

00101 {
00102 //
00103 //
00104
00105
00106   delete[] fArrayBuffer;
00107   fArrayBuffer = 0;
00108   this->Close();
00109   delete fFile;
00110   fFile = 0;
00111
00112 }

Here is the call graph for this function:

Member Function Documentation

Bool_t TDbiBinaryFile::CanRead ( ) [private]

The functions that do the low-level I/O.

Definition at line 403 of file TDbiBinaryFile.cxx.

References fReading, IsOK(), and SK_DBI_Severe.

Referenced by operator>>(), and Read().

00403                                {
00404
00405   if ( ! fReading ) {
00406        SK_DBI_Severe( "Attempting to read from a write-only file" << "  ");
00407     return kFALSE;
00408   }
00409   return this->IsOK();
00410
00411 }

Here is the call graph for this function:

Here is the caller graph for this function:

static Bool_t TDbiBinaryFile::CanReadL2Cache ( ) [inline, static]

Global control of all created TDbiBinaryFile objects.

Definition at line 114 of file TDbiBinaryFile.hxx.

References fgReadAccess, and fgWorkDir.

00114 { return fgWorkDir.size() && fgReadAccess; }

Bool_t TDbiBinaryFile::CanWrite ( ) [private]

Definition at line 414 of file TDbiBinaryFile.cxx.

References fReading, IsOK(), and SK_DBI_Severe.

Referenced by operator<<(), and Write().

00414                                 {
00415
00416   if ( fReading ) {
00417        SK_DBI_Severe( "Attempting to write to a read-only file" << "  ");
00418     return kFALSE;
00419   }
00420   return this->IsOK();
00421
00422 }

Here is the call graph for this function:

Here is the caller graph for this function:

static Bool_t TDbiBinaryFile::CanWriteL2Cache ( ) [inline, static]

Definition at line 115 of file TDbiBinaryFile.hxx.

References fgWorkDir, and fgWriteAccess.

Referenced by TDbiTableProxy::SaveToL2Cache().

00115 { return fgWorkDir.size() && fgWriteAccess; }

Here is the caller graph for this function:

void TDbiBinaryFile::CheckFileStatus ( ) [private]

Definition at line 426 of file TDbiBinaryFile.cxx.

References Close(), fFile, fFileName, fHasErrors, fReading, and SK_DBI_Severe.

Referenced by Read(), and Write().

00426                                      {
00427
00428 //  If file was good but has just gone bad, report and close it.
00429 //  Delete it if writing.
00430
00431   if (    fFile
00432        && ! fHasErrors
00433        && ( ! fFile->is_open() || ! fFile->good() ) ) {
00434        SK_DBI_Severe( "File not open or has gone bad,"
00435                            << " all further I/O will fail." << "  ");
00436     fHasErrors = kTRUE;
00437     this->Close();
00438
00439     //Delete file if writing.
00440     if ( ! fReading ) {
00441          SK_DBI_Severe( "Erasing " << fFileName << "  ");
00442       gSystem->Unlink(fFileName.c_str());
00443     }
00444
00445   }
00446
00447 }

Here is the call graph for this function:

Here is the caller graph for this function:

void TDbiBinaryFile::Close ( )

Purpose: Close file.

Definition at line 115 of file TDbiBinaryFile.cxx.

References fFile.

Referenced by CheckFileStatus(), and ~TDbiBinaryFile().

00116 {
00117 //
00118 //
00119
00120
00121   if ( fFile ) fFile->close();
00122 }

Here is the caller graph for this function:

string TDbiBinaryFile::GetFileName ( ) const [inline]

Definition at line 66 of file TDbiBinaryFile.hxx.

References fFileName.

00066 { return fFileName; }

Bool_t TDbiBinaryFile::IsOK ( ) const [inline]

Definition at line 67 of file TDbiBinaryFile.hxx.

References fHasErrors.

Referenced by CanRead(), CanWrite(), IsReading(), and IsWriting().

00067 { return ! fHasErrors;}

Here is the caller graph for this function:

Bool_t TDbiBinaryFile::IsReading ( ) const [inline]

Definition at line 68 of file TDbiBinaryFile.hxx.

References fReading, and IsOK().

Referenced by TDbiValidityRec::Streamer(), TDbiResultSetNonAgg::Streamer(), and TDbiResultSet::Streamer().

00068 { return this->IsOK() && fReading; }

Here is the call graph for this function:

Here is the caller graph for this function:

Bool_t TDbiBinaryFile::IsWriting ( ) const [inline]

Definition at line 69 of file TDbiBinaryFile.hxx.

References fReading, and IsOK().

Referenced by TDbiValidityRec::Streamer(), TDbiResultSetNonAgg::Streamer(), and TDbiResultSet::Streamer().

00069 { return this->IsOK() && ! fReading; }

Here is the call graph for this function:

Here is the caller graph for this function:

TDbiBinaryFile & TDbiBinaryFile::operator<< ( vector< TDbiTableRow * > & arr )

    Vector I/O.
    ***********


     Purpose: Read a vector of objects inheriting from TDbiTableRow.

      NB:     On entry, array must be empty.


              The objects are written into a buffer that is a contiguous
              area of memory that is allocated to receive it. After a
              successful read the user must call ReleaseArrayBuffer to take
              control over this buffer as it will be automatically release
              when the next array input occurs otherwise.
    */
//  For the format of record see the operator <<.
///

TDbiBinaryFile& TDbiBinaryFile::operator >> (vector<TDbiTableRow*>& arr) {

if ( ! this->CanRead() ) return *this;

if ( arr.size() ) { SK_DBI_Severe( "Attempting to read into non-empty array" << " "); return *this; }

Check for start of array marker.

UInt_t marker = 0; (*this) >> marker; if ( marker != StartMarker ) { SK_DBI_Severe( "Cannot find start of array marker" << " "); this->Close(); this->CheckFileStatus(); return *this; }

Get array size and deal with non-empty arrays.

Int_t arrSize = 0; (*this) >> arrSize;

if ( arrSize ) { Int_t objSize = 0; string objName; (*this) >> objName >> objSize;

Ensure that sizes look sensible and use ROOT to instatiate an example object so that we can get the address of the virtual table.

TClass objClass(objName.c_str()); Int_t objSizefromRoot = objClass.Size(); void* obj = objClass.New(); void* vt = GetVTptr(obj); This only works if the address of the sub-class object is the same as the underlying base class, which should be true in this simple case. TDbiTableRow* tr = reinterpret_cast<TDbiTableRow*>(obj); delete tr;

SK_DBI_Verbose( "Restoring array of " << arrSize << " " << objName << " objects" << " VTaddr " << std::ios::hex << vt << std::ios::dec << " object size " << objSize << "(from file) " << objSizefromRoot << "(from ROOT)" << " ");

if ( arrSize < 0 || objSize != objSizefromRoot ) { SK_DBI_Severe( "Illegal array size ("<< arrSize << ") or object size(" << objSize << "," << objSizefromRoot << ")" << " "); this->Close(); this->CheckFileStatus(); return *this; }

Allocate buffer and load in array. delete[] fArrayBuffer; Int_t buffSize = arrSize*objSize; fArrayBuffer = new char[buffSize]; this->Read(fArrayBuffer,buffSize);

Fix up VT pointers and populate the vector.

char* elem = fArrayBuffer; arr.reserve(arrSize); for (int row = 0; row < arrSize; ++row ) { SetVTptr(elem,vt); arr.push_back(reinterpret_cast<TDbiTableRow*>(elem)); elem += objSize; }

}

Check for end of array marker.

(*this) >> marker; if ( marker != EndMarker ) { SK_DBI_Severe( "Cannot find end of array marker" << " "); this->Close(); this->CheckFileStatus(); }

return *this;

}

/**.....................................................................


     Purpose: Write a vector of objects inheriting from TDbiTableRow.

     Format of record:-

     Int_t   StartMarker  Start of record marker = 0xaabbccdd
     Int_t   arrSize      Size of vector

     If size of vector > 0 this is folowed by:-

     string  objName      Name of object
     Int_t   objSize      Size of object
     char*                The data arrSize*objSize bytes long

     The record concludes:-

     Int_t     EndMarker  End of record marker = 0xddbbccaa

Definition at line 368 of file TDbiBinaryFile.cxx.

References EndMarker, and StartMarker.

00368                                                                        {
00369
00370
00371   if ( ! this->CanWrite() ) return *this;
00372
00373   UInt_t marker = StartMarker;
00374   (*this) << marker;
00375   Int_t arrSize = arr.size();
00376   (*this) << arrSize;
00377
00378   if ( arrSize ) {
00379     TDbiTableRow* obj = arr[0];
00380     Int_t objSize  = obj->IsA()->Size();
00381     string objName = obj->ClassName();
00382     (*this) << objName << objSize;
00383     for (int row = 0; row < arrSize; ++row ) {
00384       obj = arr[row];
00385       const char* p = reinterpret_cast<const char*>(arr[row]);
00386       this->Write(p,objSize);
00387     }
00388
00389   }
00390
00391   marker = EndMarker;
00392   (*this) << marker;
00393
00394   return *this;
00395
00396 }

TDbiBinaryFile & TDbiBinaryFile::operator<< ( const TVldRange & vr )

Definition at line 225 of file TDbiBinaryFile.cxx.

References CanWrite(), TVldRange::GetDataSource(), TVldRange::GetDetectorMask(), TVldRange::GetSimMask(), TVldRange::GetTimeEnd(), and TVldRange::GetTimeStart().

00225                                                                 {
00226
00227   if ( this->CanWrite() ) {
00228     string str(vr.GetDataSource().Data());
00229     (*this) << vr.GetDetectorMask()
00230             << vr.GetSimMask()
00231             << vr.GetTimeStart()
00232             << vr.GetTimeEnd()
00233             << str;
00234   }
00235   return *this;
00236 }

Here is the call graph for this function:

TDbiBinaryFile & TDbiBinaryFile::operator<< ( const string & str )

Definition at line 195 of file TDbiBinaryFile.cxx.

References Write().

00195                                                               {
00196
00197   UInt_t numBytes = str.size()+1;
00198   this->Write(str.c_str(),numBytes);
00199   return *this;
00200 }

Here is the call graph for this function:

TDbiBinaryFile& TDbiBinaryFile::operator<< ( const TVldTimeStamp & ts )

TDbiBinaryFile& TDbiBinaryFile::operator<< ( const Double_t & num )

TDbiBinaryFile& TDbiBinaryFile::operator<< ( const UInt_t & num )

TDbiBinaryFile& TDbiBinaryFile::operator<< ( const Int_t & num )

TDbiBinaryFile& TDbiBinaryFile::operator<< ( const Bool_t & num )

TDbiBinaryFile& TDbiBinaryFile::operator>> ( vector< TDbiTableRow * > & arr )

Vector I/O.

TDbiBinaryFile & TDbiBinaryFile::operator>> ( TVldRange & vr )

Compound object I/O.

Definition at line 204 of file TDbiBinaryFile.cxx.

References CanRead().

00204                                                           {
00205
00206   if ( this->CanRead() ) {
00207     Int_t        detectorMask;
00208     Int_t        simMask;
00209     TVldTimeStamp timeStart;
00210     TVldTimeStamp timeEnd;
00211     string str;
00212     (*this) >> detectorMask
00213             >> simMask
00214             >> timeStart
00215             >> timeEnd
00216             >> str;
00217     TString dataSource(str.c_str());
00218     TVldRange tmp(detectorMask,simMask,timeStart,timeEnd,dataSource);
00219     vr = tmp;
00220   }
00221   return *this;
00222 }

Here is the call graph for this function:

TDbiBinaryFile & TDbiBinaryFile::operator>> ( string & str )

String I/O. Warning: Implimentation assumes that string does not contain a null character.

Definition at line 185 of file TDbiBinaryFile.cxx.

00185                                                         {
00186
00187   if ( this->CanRead() ) {
00188     getline(*fFile,str,'\0');
00189     this->CheckFileStatus();
00190   }
00191   return *this;
00192 }

TDbiBinaryFile& TDbiBinaryFile::operator>> ( TVldTimeStamp & ts )

Simple Virtual object I/O. (i.e. object with vptr but only built-in data types)

TDbiBinaryFile& TDbiBinaryFile::operator>> ( Double_t & num )

TDbiBinaryFile& TDbiBinaryFile::operator>> ( UInt_t & num )

TDbiBinaryFile& TDbiBinaryFile::operator>> ( Int_t & num )

TDbiBinaryFile& TDbiBinaryFile::operator>> ( Bool_t & num )

Builtin data type I/O.

Bool_t TDbiBinaryFile::Read	(	char *	bytes,
		UInt_t	numBytes
	)			`[private]`

Definition at line 451 of file TDbiBinaryFile.cxx.

References CanRead(), CheckFileStatus(), fFile, and fHasErrors.

00451                                                         {
00452 //
00453 //
00454 //  Purpose: Low-level I/O with error checking.
00455 //
00456
00457   if ( ! this->CanRead() ) return kFALSE;
00458
00459   fFile->read(bytes,numBytes);
00460   this->CheckFileStatus();
00461   return ! fHasErrors;
00462 }

Here is the call graph for this function:

char* TDbiBinaryFile::ReleaseArrayBuffer ( ) [inline]

Definition at line 108 of file TDbiBinaryFile.hxx.

References fArrayBuffer.

Referenced by TDbiResultSetNonAgg::Streamer().

00108                              { char* buff = fArrayBuffer;
00109                                fArrayBuffer = 0;
00110                                return buff; }

Here is the caller graph for this function:

static void TDbiBinaryFile::SetReadAccess ( Bool_t access = kTRUE ) [inline, static]

Definition at line 118 of file TDbiBinaryFile.hxx.

References fgReadAccess.

00118 { fgReadAccess = access; }

static void TDbiBinaryFile::SetWorkDir ( const string & dir ) [inline, static]

Definition at line 116 of file TDbiBinaryFile.hxx.

References fgWorkDir.

Referenced by TDbiDatabaseManager::Config().

00116                                               { fgWorkDir = dir;
00117                   if ( fgWorkDir[fgWorkDir.size()-1] != '/' ) fgWorkDir += '/'; }

Here is the caller graph for this function:

static void TDbiBinaryFile::SetWriteAccess ( Bool_t access = kTRUE ) [inline, static]

Definition at line 119 of file TDbiBinaryFile.hxx.

References fgWriteAccess.

00119 { fgWriteAccess = access; }

Bool_t TDbiBinaryFile::Write	(	const char *	bytes,
		UInt_t	numBytes
	)			`[private]`

Definition at line 466 of file TDbiBinaryFile.cxx.

References CanWrite(), CheckFileStatus(), fFile, and fHasErrors.

Referenced by operator<<().

00466                                                                {
00467 //
00468 //
00469 //  Purpose: Low-level I/O with error checking.
00470 //
00471
00472   if ( ! this->CanWrite() ) return kFALSE;
00473
00474   fFile->write(bytes,numBytes);
00475   this->CheckFileStatus();
00476   return ! fHasErrors;
00477 }
