TRootanaEventLoop Class Reference

#include <TRootanaEventLoop.hxx>

Inheritance diagram for TRootanaEventLoop:
Inheritance graph
[legend]
Collaboration diagram for TRootanaEventLoop:
Collaboration graph
[legend]

List of all members.

Public Member Functions

virtual ~TRootanaEventLoop ()
TDataContainer * GetDataContainer ()
 Method to get the data container that event loop owns.
virtual bool ProcessMidasEvent (TDataContainer &dataContainer)=0
virtual void Initialize (void)
virtual void BeginRun (int transition, int run, int time)
virtual void EndRun (int transition, int run, int time)
virtual void Finalize ()
virtual void Usage (void)
virtual bool CheckOption (std::string option)
virtual bool PreFilter (TDataContainer &dataContainer)
bool IsOnline () const
 Are we processing online data?
bool IsOffline () const
 Are we processing offline data?
int GetCurrentRunNumber () const
 Current Run Number.
void SetCurrentRunNumber (int run)
 Current Run Number.
int ExecuteLoop (int argc, char *argv[])
 Method to actually process the Midas information, either as file or online.
int ProcessMidasFile (TApplication *app, const char *fname)
void DisableAutoMainWindow ()
 Disable automatic creation of MainWindow.
VirtualOdb * GetODB ()
 Get pointer to ODB variables.
void OpenRootFile (int run)
 Open output ROOT file.
void CloseRootFile ()
 Cloe output ROOT file.
bool IsRootFileValid ()
 Check if output ROOT file is valid and open.
void DisableRootOutput (bool disable=true)
int IsRootOutputEnabled ()
void SetOutputFilename (std::string name)
void SetOnlineName (std::string name)
void ProcessThisEventID (int eventID)
bool CheckEventID (int eventId)
 Little helper method to check if EventID matchs requested EventID list.
void SuppressTimestampWarnings ()
bool GetSuppressTimestampWarnings ()
 Suppress timestamp warnings? true = suppress warnings.
virtual ~TRootanaEventLoop ()
TDataContainer * GetDataContainer ()
 Method to get the data container that event loop owns.
virtual bool ProcessMidasEvent (TDataContainer &dataContainer)=0
virtual void Initialize (void)
virtual void BeginRun (int transition, int run, int time)
virtual void EndRun (int transition, int run, int time)
virtual void Finalize ()
virtual void Usage (void)
virtual bool CheckOption (std::string option)
virtual bool PreFilter (TDataContainer &dataContainer)
bool IsOnline () const
 Are we processing online data?
bool IsOffline () const
 Are we processing offline data?
int GetCurrentRunNumber () const
 Current Run Number.
void SetCurrentRunNumber (int run)
 Current Run Number.
int ExecuteLoop (int argc, char *argv[])
 Method to actually process the Midas information, either as file or online.
int ProcessMidasFile (TApplication *app, const char *fname)
void DisableAutoMainWindow ()
 Disable automatic creation of MainWindow.
VirtualOdb * GetODB ()
 Get pointer to ODB variables.
void OpenRootFile (int run)
 Open output ROOT file.
void CloseRootFile ()
 Cloe output ROOT file.
bool IsRootFileValid ()
 Check if output ROOT file is valid and open.
void DisableRootOutput (bool disable=true)
int IsRootOutputEnabled ()
void SetOutputFilename (std::string name)
void SetOnlineName (std::string name)
void ProcessThisEventID (int eventID)
bool CheckEventID (int eventId)
 Little helper method to check if EventID matchs requested EventID list.
void SuppressTimestampWarnings ()
bool GetSuppressTimestampWarnings ()
 Suppress timestamp warnings? true = suppress warnings.

Static Public Member Functions

static TRootanaEventLoop & Get (void)
template<typename T >
static void CreateSingleton ()
static TRootanaEventLoop & Get (void)
template<typename T >
static void CreateSingleton ()

Protected Member Functions

bool CreateOutputFile (std::string name, std::string options="RECREATE")
 TRootanaEventLoop ()
virtual bool CheckOptionRAD (std::string option)
virtual void UsageRAD (void)
 Also a special version of usage for TRootanaDisplay. See CheckOptionRAD.
bool CreateOutputFile (std::string name, std::string options="RECREATE")
 TRootanaEventLoop ()
virtual bool CheckOptionRAD (std::string option)
virtual void UsageRAD (void)
 Also a special version of usage for TRootanaDisplay. See CheckOptionRAD.

Protected Attributes

TDirectory * fOnlineHistDir
 TDirectory for online histograms.

Static Protected Attributes

static TRootanaEventLoop * fTRootanaEventLoop = NULL
 The static pointer to the singleton instance.

Private Member Functions

void PrintHelp ()
 Help Message.
void PrintHelp ()
 Help Message.

Private Attributes

TFile * fOutputFile
 Output ROOT file.
std::string fOutputFilename
bool fDisableRootOutput
 Variable for disabling/enabling Root output.
VirtualOdb * fODB
 Pointer to the ODB access instance.
bool fIsOffline
 Are we processing offline or online data?
int fCurrentRunNumber
 Current run number.
TDataContainer * fDataContainer
std::vector< int > fProcessEventIDs
 This is the set of eventIDs to process.
std::string fBufferName
 Buffer to connect to.
std::string fOnlineName
 Name of program, as seen by MIDAS.
bool fSuppressTimestampWarnings
 Bool for suppressing the warnings about old timestamps.
int fMaxEvents
TApplication * fApp
bool fCreateMainWindow

Detailed Description

This is a base class for event loops that are derived from rootana.

The user should create a class that derives from this TRootanaEventLoop class and then fill in the methods that they want to implement.

The user must implement the method ProcessMidasEvent(), which will get executed on each event.

The user can also implement methods like Initialize, BeginRun, EndRun, Finalize if there are actions they want to execute at certain points.

The event loop will work in both offline and online mode (online only if the user has MIDAS installed).

In example of this type of event loop is shown in examples/analyzer_example.cxx

Definition at line 40 of file TRootanaEventLoop.hxx.

Constructor & Destructor Documentation

TRootanaEventLoop::~TRootanaEventLoop (  )  [virtual]

Definition at line 96 of file TRootanaEventLoop.cxx.

References CloseRootFile(), and fODB.

00096                                       {
00097
00098   if(fODB) delete fODB;
00099   CloseRootFile();
00100
00101 }

Here is the call graph for this function:

TRootanaEventLoop::TRootanaEventLoop (  )  [protected]

Create the TApplication

Definition at line 71 of file TRootanaEventLoop.cxx.

References fApp, fBufferName, fCreateMainWindow, fCurrentRunNumber, fDataContainer, fDisableRootOutput, fIsOffline, fMaxEvents, fODB, fOnlineHistDir, fOnlineName, fOutputFile, fOutputFilename, and fSuppressTimestampWarnings.

00071                                      {
00072
00073   fOutputFile = 0;
00074   fOutputFilename = std::string("output");
00075   fDisableRootOutput = false;
00076   fODB = 0;
00077   fOnlineHistDir = 0;
00078   fMaxEvents = 0;
00079   fCurrentRunNumber = 0;
00080   fIsOffline = true;
00081
00082   fCreateMainWindow = true;
00083   fSuppressTimestampWarnings = false;
00084
00085   fBufferName = std::string("SYSTEM");
00086   fOnlineName = std::string("rootana");
00087
00088   fDataContainer = new TDataContainer();
00089
00090   /// Create the TApplication
00091   char **argv2 = NULL;
00092   fApp = new TApplication("rootana", 0, argv2);
00093
00094 }

virtual TRootanaEventLoop::~TRootanaEventLoop (  )  [virtual]
TRootanaEventLoop::TRootanaEventLoop (  )  [protected]

Member Function Documentation

virtual void TRootanaEventLoop::BeginRun ( int  transition,
int  run,
int  time
) [virtual]

Called before the first event of a file is read, but you should prefer Initialize() for general initialization. This method will be called once for each input file.

Reimplemented in Analyzer, TRootanaDisplay, MyTestLoop, and TRootanaDisplay.

void TRootanaEventLoop::BeginRun ( int  transition,
int  run,
int  time
) [virtual]

Called before the first event of a file is read, but you should prefer Initialize() for general initialization. This method will be called once for each input file.

Reimplemented in Analyzer, TRootanaDisplay, MyTestLoop, and TRootanaDisplay.

Definition at line 106 of file TRootanaEventLoop.cxx.

Referenced by ProcessMidasFile().

00106 {};

Here is the caller graph for this function:

bool TRootanaEventLoop::CheckEventID ( int  eventId  )

Little helper method to check if EventID matchs requested EventID list.

bool TRootanaEventLoop::CheckEventID ( int  eventId  )

Little helper method to check if EventID matchs requested EventID list.

Definition at line 120 of file TRootanaEventLoop.cxx.

References fProcessEventIDs.

Referenced by ProcessMidasFile().

00120                                                {
00121
00122   // If we didn't specify list of accepted IDs, then accept all.
00123   if(fProcessEventIDs.size()==0) return true;
00124
00125   // Otherwise check event ID against list
00126   for(unsigned int i = 0; i < fProcessEventIDs.size(); i++){
00127     if(fProcessEventIDs[i] == (eventId & 0xFFFF))
00128       return true;
00129   }
00130
00131   return false;
00132 }

Here is the caller graph for this function:

virtual bool TRootanaEventLoop::CheckOption ( std::string  option  )  [virtual]

Check an option and return true if it is valid. The return value is used to flag errors during option handling. If the options are valid, then CheckOption should return true to indicate success. If there is a problem processing the options, then CheckOption should return false. If this returns false, then the event loop will print the Usage message and exit with a non zero value (i.e. indicate failure).

Reimplemented in MyTestLoop.

bool TRootanaEventLoop::CheckOption ( std::string  option  )  [virtual]

Check an option and return true if it is valid. The return value is used to flag errors during option handling. If the options are valid, then CheckOption should return true to indicate success. If there is a problem processing the options, then CheckOption should return false. If this returns false, then the event loop will print the Usage message and exit with a non zero value (i.e. indicate failure).

Reimplemented in MyTestLoop.

Definition at line 116 of file TRootanaEventLoop.cxx.

Referenced by ExecuteLoop().

00116 {return false;}

Here is the caller graph for this function:

virtual bool TRootanaEventLoop::CheckOptionRAD ( std::string  option  )  [protected, virtual]

This is a special version of CheckOption that is only used by TRootanaDisplay. This is just so that users still have the ability to set options for executables derived from TRootanaDisplay.

Reimplemented in TRootanaDisplay, and TRootanaDisplay.

bool TRootanaEventLoop::CheckOptionRAD ( std::string  option  )  [protected, virtual]

This is a special version of CheckOption that is only used by TRootanaDisplay. This is just so that users still have the ability to set options for executables derived from TRootanaDisplay.

Reimplemented in TRootanaDisplay, and TRootanaDisplay.

Definition at line 117 of file TRootanaEventLoop.cxx.

Referenced by ExecuteLoop().

00117 {return false;}

Here is the caller graph for this function:

void TRootanaEventLoop::CloseRootFile (  )

Cloe output ROOT file.

void TRootanaEventLoop::CloseRootFile (  )

Cloe output ROOT file.

Definition at line 397 of file TRootanaEventLoop.cxx.

References fOutputFile.

Referenced by ProcessMidasFile(), TRootanaDisplay::QuitButtonAction(), and ~TRootanaEventLoop().

00397                                      {
00398
00399   if(fOutputFile) {
00400                 std::cout << "Closing ROOT file " << std::endl;
00401     fOutputFile->Write();
00402     fOutputFile->Close();
00403     fOutputFile=0;
00404   }
00405
00406 }

Here is the caller graph for this function:

bool TRootanaEventLoop::CreateOutputFile ( std::string  name,
std::string  options = "RECREATE"
) [inline, protected]

Definition at line 184 of file TRootanaEventLoop.hxx.

References fOutputFile.

00184                                                                        {
00185
00186     fOutputFile = new TFile(name.c_str(),options.c_str());
00187
00188     return true;
00189   }

bool TRootanaEventLoop::CreateOutputFile ( std::string  name,
std::string  options = "RECREATE"
) [inline, protected]

Definition at line 184 of file TRootanaEventLoop.hxx.

References fOutputFile.

00184                                                                        {
00185
00186     fOutputFile = new TFile(name.c_str(),options.c_str());
00187
00188     return true;
00189   }

template<typename T >
static void TRootanaEventLoop::CreateSingleton (  )  [inline, static]

This static templated function will make it a little easier for users to create the singleton instance.

Definition at line 125 of file TRootanaEventLoop.hxx.

References fTRootanaEventLoop.

00126   {
00127     if(fTRootanaEventLoop)
00128       std::cout << "Singleton has already been created" << std::endl;
00129     else
00130       fTRootanaEventLoop = new T();
00131   }

template<typename T >
static void TRootanaEventLoop::CreateSingleton (  )  [inline, static]

This static templated function will make it a little easier for users to create the singleton instance.

Definition at line 125 of file TRootanaEventLoop.hxx.

References fTRootanaEventLoop.

00126   {
00127     if(fTRootanaEventLoop)
00128       std::cout << "Singleton has already been created" << std::endl;
00129     else
00130       fTRootanaEventLoop = new T();
00131   }

void TRootanaEventLoop::DisableAutoMainWindow (  )  [inline]

Disable automatic creation of MainWindow.

Definition at line 135 of file TRootanaEventLoop.hxx.

References fCreateMainWindow.

00135 {  fCreateMainWindow = false;}

void TRootanaEventLoop::DisableAutoMainWindow (  )  [inline]

Disable automatic creation of MainWindow.

Definition at line 135 of file TRootanaEventLoop.hxx.

References fCreateMainWindow.

Referenced by Analyzer::Analyzer().

00135 {  fCreateMainWindow = false;}

Here is the caller graph for this function:

void TRootanaEventLoop::DisableRootOutput ( bool  disable = true  )  [inline]

Definition at line 154 of file TRootanaEventLoop.hxx.

References fDisableRootOutput.

00154 {fDisableRootOutput = disable;};

void TRootanaEventLoop::DisableRootOutput ( bool  disable = true  )  [inline]

Definition at line 154 of file TRootanaEventLoop.hxx.

References fDisableRootOutput.

Referenced by MyTestLoop::MyTestLoop().

00154 {fDisableRootOutput = disable;};

Here is the caller graph for this function:

virtual void TRootanaEventLoop::EndRun ( int  transition,
int  run,
int  time
) [virtual]

Called after the last event of a file is read, but you should prefer Finalize() for general finalization. This method will be called once for each input file.

Reimplemented in TRootanaDisplay, MyTestLoop, and TRootanaDisplay.

void TRootanaEventLoop::EndRun ( int  transition,
int  run,
int  time
) [virtual]

Called after the last event of a file is read, but you should prefer Finalize() for general finalization. This method will be called once for each input file.

Reimplemented in TRootanaDisplay, MyTestLoop, and TRootanaDisplay.

Definition at line 108 of file TRootanaEventLoop.cxx.

Referenced by ProcessMidasFile().

00108 {};

Here is the caller graph for this function:

int TRootanaEventLoop::ExecuteLoop ( int  argc,
char *  argv[]
)

Method to actually process the Midas information, either as file or online.

int TRootanaEventLoop::ExecuteLoop ( int  argc,
char *  argv[]
)

Method to actually process the Midas information, either as file or online.

Definition at line 159 of file TRootanaEventLoop.cxx.

References TDirectory::cd(), CheckOption(), CheckOptionRAD(), fApp, fBufferName, fCreateMainWindow, Finalize(), fIsOffline, fMaxEvents, fOnlineHistDir, Initialize(), PrintHelp(), ProcessMidasFile(), and StartNetDirectoryServer().

Referenced by main().

00159                                                         {
00160
00161   setbuf(stdout,NULL);
00162   setbuf(stderr,NULL);
00163
00164   signal(SIGILL,  SIG_DFL);
00165   signal(SIGBUS,  SIG_DFL);
00166   signal(SIGSEGV, SIG_DFL);
00167
00168   std::vector<std::string> args;
00169   for (int i=0; i<argc; i++)
00170     {
00171       if (strcmp(argv[i],"-h")==0)
00172         PrintHelp(); // does not return
00173       args.push_back(argv[i]);
00174     }
00175
00176
00177   if(gROOT->IsBatch()) {
00178     printf("Cannot run in batch mode\n");
00179     return 1;
00180   }
00181
00182   bool forceEnableGraphics = false;
00183   bool testMode = false;
00184   int  tcpPort = 0;
00185   const char* hostname = NULL;
00186   const char* exptname = NULL;
00187
00188   for (unsigned int i=1; i<args.size(); i++) // loop over the commandline options
00189     {
00190       const char* arg = args[i].c_str();
00191       //printf("argv[%d] is %s\n",i,arg);
00192
00193       if (strncmp(arg,"-e",2)==0)  // Event cutoff flag (only applicable in offline mode)
00194         fMaxEvents = atoi(arg+2);
00195       else if (strncmp(arg,"-m",2)==0) // Enable memory debugging
00196         ;//      gEnableShowMem = true;
00197       else if (strncmp(arg,"-P",2)==0) // Set the histogram server port
00198         tcpPort = atoi(arg+2);
00199       else if (strcmp(arg,"-T")==0)
00200         testMode = true;
00201       else if (strcmp(arg,"-g")==0)
00202         forceEnableGraphics = true;
00203       else if (strncmp(arg,"-H",2)==0)
00204         hostname = strdup(arg+2);
00205       else if (strncmp(arg,"-E",2)==0)
00206         exptname = strdup(arg+2);
00207       else if (strncmp(arg,"-b",2)==0){
00208         fBufferName = std::string(arg+2);
00209       }else if (strcmp(arg,"-h")==0)
00210         PrintHelp(); // does not return
00211       else if(arg[0] == '-')// Check if a TRootanaDisplay or user-defined options
00212         if(!CheckOptionRAD(args[i]))
00213           if(!CheckOption(args[i]))
00214             PrintHelp(); // does not return
00215     }
00216
00217   // Do quick check if we are processing online or offline.
00218   // Want to know before we initialize.
00219   fIsOffline = false;
00220   for (unsigned int i=1; i<args.size(); i++){
00221     const char* arg = args[i].c_str();
00222     if (arg[0] != '-')
00223       {
00224         fIsOffline = true;
00225       }
00226   }
00227
00228
00229   MainWindow *mainWindow=0;
00230   if(fCreateMainWindow){
00231     mainWindow = new MainWindow(gClient->GetRoot(), 200, 300);
00232   }
00233
00234    gROOT->cd();
00235    fOnlineHistDir = new TDirectory("rootana", "rootana online plots");
00236
00237 #ifdef HAVE_LIBNETDIRECTORY
00238    if (tcpPort)
00239      StartNetDirectoryServer(tcpPort, fOnlineHistDir);
00240 #else
00241    if (tcpPort)
00242      fprintf(stderr,"ERROR: No support for the TNetDirectory server!\n");
00243 #endif
00244
00245    // Initialize the event loop with user initialization.
00246    Initialize();
00247
00248    for (unsigned int i=1; i<args.size(); i++){
00249      const char* arg = args[i].c_str();
00250      if (arg[0] != '-')
00251        {
00252            ProcessMidasFile(fApp,arg);
00253        }
00254    }
00255
00256    if (testMode){
00257      std::cout << "Entering test mode." << std::endl;
00258      fOnlineHistDir->cd();
00259      TH1D* hh = new TH1D("test", "test", 100, 0, 100);
00260      hh->Fill(1);
00261      hh->Fill(10);
00262      hh->Fill(50);
00263
00264      fApp->Run(kTRUE);
00265      if(fCreateMainWindow) delete mainWindow;
00266      return 0;
00267    }
00268
00269    // if we processed some data files,
00270    // do not go into online mode.
00271    if (fIsOffline){
00272      if(fCreateMainWindow) delete mainWindow;
00273      return 0;
00274    }
00275
00276 #ifdef HAVE_MIDAS
00277    ProcessMidasOnline(fApp, hostname, exptname);;
00278 #endif
00279
00280    if(fCreateMainWindow) delete mainWindow;
00281
00282    Finalize();
00283
00284    return 0;
00285
00286 }

Here is the call graph for this function:

Here is the caller graph for this function:

virtual void TRootanaEventLoop::Finalize (  )  [virtual]

Called after the last event has been processed, but before any open output files are closed.

void TRootanaEventLoop::Finalize (  )  [virtual]

Called after the last event has been processed, but before any open output files are closed.

Definition at line 110 of file TRootanaEventLoop.cxx.

Referenced by ExecuteLoop().

00110 {};

Here is the caller graph for this function:

static TRootanaEventLoop& TRootanaEventLoop::Get ( void   )  [static]
TRootanaEventLoop & TRootanaEventLoop::Get ( void   )  [static]

Definition at line 59 of file TRootanaEventLoop.cxx.

References fTRootanaEventLoop.

Referenced by main().

00059                                               {
00060
00061   if(!fTRootanaEventLoop){
00062     std::cerr << "Singleton Not Instantiated! "
00063               << " Need to call something like SomeClass::CreateSingleton<SomeClass>(); Exiting!"
00064               <<std::endl; exit(0);
00065   }
00066   return *fTRootanaEventLoop;
00067 }

Here is the caller graph for this function:

int TRootanaEventLoop::GetCurrentRunNumber (  )  const [inline]

Current Run Number.

Definition at line 107 of file TRootanaEventLoop.hxx.

References fCurrentRunNumber.

00107 {return fCurrentRunNumber;};

int TRootanaEventLoop::GetCurrentRunNumber (  )  const [inline]

Current Run Number.

Definition at line 107 of file TRootanaEventLoop.hxx.

References fCurrentRunNumber.

Referenced by MyTestLoop::ProcessMidasEvent(), TRootanaDisplay::QuitButtonAction(), and TRootanaDisplay::UpdatePlotsAction().

00107 {return fCurrentRunNumber;};

Here is the caller graph for this function:

TDataContainer* TRootanaEventLoop::GetDataContainer (  )  [inline]

Method to get the data container that event loop owns.

Definition at line 49 of file TRootanaEventLoop.hxx.

References fDataContainer.

00049 {return fDataContainer;};

TDataContainer* TRootanaEventLoop::GetDataContainer (  )  [inline]

Method to get the data container that event loop owns.

Definition at line 49 of file TRootanaEventLoop.hxx.

References fDataContainer.

00049 {return fDataContainer;};

VirtualOdb* TRootanaEventLoop::GetODB (  )  [inline]

Get pointer to ODB variables.

Definition at line 138 of file TRootanaEventLoop.hxx.

References fODB.

00138 {return fODB;}

VirtualOdb* TRootanaEventLoop::GetODB (  )  [inline]

Get pointer to ODB variables.

Definition at line 138 of file TRootanaEventLoop.hxx.

References fODB.

00138 {return fODB;}

bool TRootanaEventLoop::GetSuppressTimestampWarnings (  )  [inline]

Suppress timestamp warnings? true = suppress warnings.

Definition at line 179 of file TRootanaEventLoop.hxx.

References fSuppressTimestampWarnings.

00179 { return fSuppressTimestampWarnings;};

bool TRootanaEventLoop::GetSuppressTimestampWarnings (  )  [inline]

Suppress timestamp warnings? true = suppress warnings.

Definition at line 179 of file TRootanaEventLoop.hxx.

References fSuppressTimestampWarnings.

00179 { return fSuppressTimestampWarnings;};

virtual void TRootanaEventLoop::Initialize ( void   )  [virtual]

Called after the arguments are processes but before reading the first event is read

Reimplemented in Analyzer, TRootanaDisplay, and TRootanaDisplay.

void TRootanaEventLoop::Initialize ( void   )  [virtual]

Called after the arguments are processes but before reading the first event is read

Reimplemented in Analyzer, TRootanaDisplay, and TRootanaDisplay.

Definition at line 104 of file TRootanaEventLoop.cxx.

Referenced by ExecuteLoop().

00104 {};

Here is the caller graph for this function:

bool TRootanaEventLoop::IsOffline (  )  const [inline]

Are we processing offline data?

Definition at line 104 of file TRootanaEventLoop.hxx.

References fIsOffline.

00104 {return fIsOffline;};

bool TRootanaEventLoop::IsOffline (  )  const [inline]

Are we processing offline data?

Definition at line 104 of file TRootanaEventLoop.hxx.

References fIsOffline.

Referenced by TRootanaDisplay::InitializeMainWindow().

00104 {return fIsOffline;};

Here is the caller graph for this function:

bool TRootanaEventLoop::IsOnline (  )  const [inline]

Are we processing online data?

Definition at line 101 of file TRootanaEventLoop.hxx.

References fIsOffline.

00101 {return !fIsOffline;};

bool TRootanaEventLoop::IsOnline (  )  const [inline]

Are we processing online data?

Definition at line 101 of file TRootanaEventLoop.hxx.

References fIsOffline.

Referenced by TRootanaDisplay::InitializeMainWindow(), TRootanaDisplay::ProcessMidasEvent(), TRootanaDisplay::QuitButtonAction(), and TRootanaDisplay::UpdatePlotsAction().

00101 {return !fIsOffline;};

Here is the caller graph for this function:

bool TRootanaEventLoop::IsRootFileValid (  )  [inline]

Check if output ROOT file is valid and open.

Definition at line 148 of file TRootanaEventLoop.hxx.

References fOutputFile.

00148                         {
00149     if(fOutputFile) return true;
00150     return false;
00151   }

bool TRootanaEventLoop::IsRootFileValid (  )  [inline]

Check if output ROOT file is valid and open.

Definition at line 148 of file TRootanaEventLoop.hxx.

References fOutputFile.

00148                         {
00149     if(fOutputFile) return true;
00150     return false;
00151   }

int TRootanaEventLoop::IsRootOutputEnabled (  )  [inline]

Definition at line 156 of file TRootanaEventLoop.hxx.

References fDisableRootOutput.

00156 {return !fDisableRootOutput;};

int TRootanaEventLoop::IsRootOutputEnabled (  )  [inline]

Definition at line 156 of file TRootanaEventLoop.hxx.

References fDisableRootOutput.

00156 {return !fDisableRootOutput;};

void TRootanaEventLoop::OpenRootFile ( int  run  )

Open output ROOT file.

void TRootanaEventLoop::OpenRootFile ( int  run  )

Open output ROOT file.

Definition at line 375 of file TRootanaEventLoop.cxx.

References fDisableRootOutput, fOutputFile, fOutputFilename, and NetDirectoryExport().

Referenced by ProcessMidasFile().

00375                                            {
00376
00377   if(fDisableRootOutput) return;
00378
00379   if(fOutputFile) {
00380     fOutputFile->Write();
00381     fOutputFile->Close();
00382     fOutputFile=0;
00383   }
00384
00385   char filename[1024];
00386   sprintf(filename, "%s%05d.root",fOutputFilename.c_str(), run);
00387   fOutputFile = new TFile(filename,"RECREATE");
00388   std::cout << "Opened output file with name : " << filename << std::endl;
00389
00390
00391 #ifdef HAVE_LIBNETDIRECTORY
00392   NetDirectoryExport(fOutputFile, "outputFile");
00393 #endif
00394 }

Here is the call graph for this function:

Here is the caller graph for this function:

virtual bool TRootanaEventLoop::PreFilter ( TDataContainer &  dataContainer  )  [inline, virtual]

The PreFilter method allows user to specify whether to ignore a particular event. Specifically, if PreFilter returns

true -> then ProcessMidasEvent will be called or false -> then ProcessMidasEvent will not be called

This is particularly useful for the RootanaDisplay, where you might want to only process and plot certain events.

Definition at line 98 of file TRootanaEventLoop.hxx.

00098 {return true;}

virtual bool TRootanaEventLoop::PreFilter ( TDataContainer &  dataContainer  )  [inline, virtual]

The PreFilter method allows user to specify whether to ignore a particular event. Specifically, if PreFilter returns

true -> then ProcessMidasEvent will be called or false -> then ProcessMidasEvent will not be called

This is particularly useful for the RootanaDisplay, where you might want to only process and plot certain events.

Definition at line 98 of file TRootanaEventLoop.hxx.

Referenced by ProcessMidasFile().

00098 {return true;}

Here is the caller graph for this function:

void TRootanaEventLoop::PrintHelp (  )  [private]

Help Message.

void TRootanaEventLoop::PrintHelp (  )  [private]

Help Message.

Definition at line 134 of file TRootanaEventLoop.cxx.

References Usage(), and UsageRAD().

Referenced by ExecuteLoop().

00134                                  {
00135
00136   printf("\nUsage:\n");
00137   printf("\n./analyzer.exe [-h] [-Hhostname] [-Eexptname] [-eMaxEvents] [-P9091] [-p9090] [-m] [-g] [file1 file2 ...]\n");
00138   printf("\n");
00139   printf("\t-h: print this help message\n");
00140   printf("\t-T: test mode - start and serve a test histogram\n");
00141   printf("\t-Hhostname: connect to MIDAS experiment on given host\n");
00142   printf("\t-Eexptname: connect to this MIDAS experiment\n");
00143   printf("\t-bbuffer: connect to this MIDAS buffer\n");
00144   printf("\t-P: Start the TNetDirectory server on specified tcp port (for use with roody -Plocalhost:9091)\n");
00145   printf("\t-p: Start the old midas histogram server on specified tcp port (for use with roody -Hlocalhost:9090)\n");
00146   printf("\t-eXXX: Number of events XXX to read from input data files\n");
00147   //printf("\t-m: Enable memory leak debugging\n");
00148   printf("\t-g: Enable graphics display when processing data files\n");
00149   UsageRAD();  // Print description of TRootanaDisplay options.
00150   Usage();  // Print description of user options.
00151   printf("\n");
00152   printf("Example1: analyze online data: ./analyzer.exe -P9091\n");
00153   printf("Example2: analyze existing data: ./analyzer.exe /data/alpha/current/run00500.mid\n");
00154
00155   exit(1);
00156 }

Here is the call graph for this function:

Here is the caller graph for this function:

virtual bool TRootanaEventLoop::ProcessMidasEvent ( TDataContainer &  dataContainer  )  [pure virtual]

The main method, called for each event. Users must implement this function!

Implemented in Analyzer, TRootanaDisplay, MyTestLoop, and TRootanaDisplay.

virtual bool TRootanaEventLoop::ProcessMidasEvent ( TDataContainer &  dataContainer  )  [pure virtual]

The main method, called for each event. Users must implement this function!

Implemented in Analyzer, TRootanaDisplay, MyTestLoop, and TRootanaDisplay.

Referenced by ProcessMidasFile().

Here is the caller graph for this function:

int TRootanaEventLoop::ProcessMidasFile ( TApplication *  app,
const char *  fname
)
int TRootanaEventLoop::ProcessMidasFile ( TApplication *  app,
const char *  fname
)

Treat the begin run and end run events differently.

Definition at line 290 of file TRootanaEventLoop.cxx.

References BeginRun(), CheckEventID(), TDataContainer::CleanupEvent(), TMidasFile::Close(), CloseRootFile(), EndRun(), fCurrentRunNumber, fDataContainer, fMaxEvents, fODB, TMidasEvent::GetData(), TMidasEvent::GetSerialNumber(), TMidasFile::Open(), OpenRootFile(), PreFilter(), PrintCurrentStats(), ProcessMidasEvent(), TMidasFile::Read(), and TDataContainer::SetMidasEventPointer().

Referenced by ExecuteLoop().

00291 {
00292   TMidasFile f;
00293   bool tryOpen = f.Open(fname);
00294
00295   if (!tryOpen){
00296     printf("Cannot open input file \"%s\"\n",fname);
00297     return -1;
00298   }
00299
00300
00301   int i=0;
00302   while (1)
00303     {
00304       TMidasEvent event;
00305       if (!f.Read(&event))
00306         break;
00307
00308       /// Treat the begin run and end run events differently.
00309       int eventId = event.GetEventId();
00310
00311
00312
00313       if ((eventId & 0xFFFF) == 0x8000){// begin run event
00314
00315         event.Print();
00316
00317         // Load ODB contents from the ODB XML file
00318         if (fODB) delete fODB;
00319         fODB = new XmlOdb(event.GetData(),event.GetDataSize());
00320
00321         fCurrentRunNumber = event.GetSerialNumber();
00322         OpenRootFile(fCurrentRunNumber);
00323         BeginRun(0,event.GetSerialNumber(),0);
00324
00325       } else if ((eventId & 0xFFFF) == 0x8001){// end run event
00326
00327         event.Print();
00328         //EndRun(0,fCurrentRunNumber,0);
00329
00330
00331       } else if ((eventId & 0xFFFF) == 0x8002){
00332
00333         event.Print();
00334         printf("Log message: %s\n", event.GetData());
00335
00336       }else if(CheckEventID(eventId)){ // all other events; check that this event ID should be processed.
00337
00338         // Set the bank list for midas event.
00339         event.SetBankList();
00340
00341         // Set the midas event pointer in the physics event.
00342         fDataContainer->SetMidasEventPointer(event);
00343
00344         //ProcessEvent if prefilter is satisfied...
00345                                 if(PreFilter(*fDataContainer))
00346                                          ProcessMidasEvent(*fDataContainer);
00347
00348         // Cleanup the information for this event.
00349         fDataContainer->CleanupEvent();
00350
00351       }
00352
00353       PrintCurrentStats();
00354
00355       // Check if we have processed desired number of events.
00356       i++;
00357       if ((fMaxEvents!=0)&&(i>=fMaxEvents)){
00358         printf("Reached event %d, exiting loop.\n",i);
00359         break;
00360       }
00361     }
00362
00363   f.Close();
00364
00365   EndRun(0,fCurrentRunNumber,0);
00366   CloseRootFile();
00367
00368   // start the ROOT GUI event loop
00369   //  app->Run(kTRUE);
00370
00371   return 0;
00372 }

Here is the call graph for this function:

Here is the caller graph for this function:

void TRootanaEventLoop::ProcessThisEventID ( int  eventID  )  [inline]

Provide a way to force program to only process certain event IDs. This method can be called repeatedly to specify several different event IDs to accept. If the method is not called then all eventIDs are accepted.

Definition at line 167 of file TRootanaEventLoop.hxx.

References fProcessEventIDs.

00167                                       {
00168     fProcessEventIDs.push_back(eventID);
00169   };

void TRootanaEventLoop::ProcessThisEventID ( int  eventID  )  [inline]

Provide a way to force program to only process certain event IDs. This method can be called repeatedly to specify several different event IDs to accept. If the method is not called then all eventIDs are accepted.

Definition at line 167 of file TRootanaEventLoop.hxx.

References fProcessEventIDs.

00167                                       {
00168     fProcessEventIDs.push_back(eventID);
00169   };

void TRootanaEventLoop::SetCurrentRunNumber ( int  run  )  [inline]

Current Run Number.

Definition at line 110 of file TRootanaEventLoop.hxx.

References fCurrentRunNumber.

00110 {fCurrentRunNumber = run;};

void TRootanaEventLoop::SetCurrentRunNumber ( int  run  )  [inline]

Current Run Number.

Definition at line 110 of file TRootanaEventLoop.hxx.

References fCurrentRunNumber.

00110 {fCurrentRunNumber = run;};

void TRootanaEventLoop::SetOnlineName ( std::string  name  )  [inline]

Definition at line 162 of file TRootanaEventLoop.hxx.

References fOnlineName.

00162 {fOnlineName = name;};

void TRootanaEventLoop::SetOnlineName ( std::string  name  )  [inline]

Definition at line 162 of file TRootanaEventLoop.hxx.

References fOnlineName.

00162 {fOnlineName = name;};

void TRootanaEventLoop::SetOutputFilename ( std::string  name  )  [inline]

Set the output filename. File name will be XXX.root, where XXX is run number

Definition at line 160 of file TRootanaEventLoop.hxx.

References fOutputFilename.

00160 {fOutputFilename = name;};

void TRootanaEventLoop::SetOutputFilename ( std::string  name  )  [inline]

Set the output filename. File name will be XXX.root, where XXX is run number

Definition at line 160 of file TRootanaEventLoop.hxx.

References fOutputFilename.

Referenced by MyTestLoop::MyTestLoop().

00160 {fOutputFilename = name;};

Here is the caller graph for this function:

void TRootanaEventLoop::SuppressTimestampWarnings (  )  [inline]

Suppress the warning methods regarding old timestamp events for online ie warnings about analyzer falling behind data taking.

Definition at line 176 of file TRootanaEventLoop.hxx.

References fSuppressTimestampWarnings.

00176 { fSuppressTimestampWarnings = true;};

void TRootanaEventLoop::SuppressTimestampWarnings (  )  [inline]

Suppress the warning methods regarding old timestamp events for online ie warnings about analyzer falling behind data taking.

Definition at line 176 of file TRootanaEventLoop.hxx.

References fSuppressTimestampWarnings.

00176 { fSuppressTimestampWarnings = true;};

virtual void TRootanaEventLoop::Usage ( void   )  [virtual]

Called when there is a usage error. This code should print a usage message and then return.

Reimplemented in MyTestLoop.

void TRootanaEventLoop::Usage ( void   )  [virtual]

Called when there is a usage error. This code should print a usage message and then return.

Reimplemented in MyTestLoop.

Definition at line 112 of file TRootanaEventLoop.cxx.

Referenced by PrintHelp().

00112 {};

Here is the caller graph for this function:

virtual void TRootanaEventLoop::UsageRAD ( void   )  [protected, virtual]

Also a special version of usage for TRootanaDisplay. See CheckOptionRAD.

Reimplemented in TRootanaDisplay, and TRootanaDisplay.

void TRootanaEventLoop::UsageRAD ( void   )  [protected, virtual]

Also a special version of usage for TRootanaDisplay. See CheckOptionRAD.

Reimplemented in TRootanaDisplay, and TRootanaDisplay.

Definition at line 113 of file TRootanaEventLoop.cxx.

Referenced by PrintHelp().

00113 {};

Here is the caller graph for this function:

Member Data Documentation

TApplication * TRootanaEventLoop::fApp [private]

Definition at line 260 of file TRootanaEventLoop.hxx.

Referenced by ExecuteLoop(), and TRootanaEventLoop().

std::string TRootanaEventLoop::fBufferName [private]

Buffer to connect to.

Definition at line 247 of file TRootanaEventLoop.hxx.

Referenced by ExecuteLoop(), and TRootanaEventLoop().

bool TRootanaEventLoop::fCreateMainWindow [private]

Definition at line 263 of file TRootanaEventLoop.hxx.

Referenced by DisableAutoMainWindow(), ExecuteLoop(), and TRootanaEventLoop().

int TRootanaEventLoop::fCurrentRunNumber [private]

Current run number.

Definition at line 230 of file TRootanaEventLoop.hxx.

Referenced by GetCurrentRunNumber(), ProcessMidasFile(), SetCurrentRunNumber(), and TRootanaEventLoop().

TDataContainer * TRootanaEventLoop::fDataContainer [private]

Pointer to the physics event; the physics event is what we pass to user. The midas event is accessible through physics event. We make a single instance of the physics event for whole execution, because sometimes the decoded information needs to persist across multiple midas events.

Definition at line 238 of file TRootanaEventLoop.hxx.

Referenced by GetDataContainer(), ProcessMidasFile(), and TRootanaEventLoop().

bool TRootanaEventLoop::fDisableRootOutput [private]

Variable for disabling/enabling Root output.

Definition at line 221 of file TRootanaEventLoop.hxx.

Referenced by DisableRootOutput(), IsRootOutputEnabled(), OpenRootFile(), and TRootanaEventLoop().

bool TRootanaEventLoop::fIsOffline [private]

Are we processing offline or online data?

Definition at line 227 of file TRootanaEventLoop.hxx.

Referenced by ExecuteLoop(), IsOffline(), IsOnline(), and TRootanaEventLoop().

int TRootanaEventLoop::fMaxEvents [private]

Definition at line 257 of file TRootanaEventLoop.hxx.

Referenced by ExecuteLoop(), ProcessMidasFile(), and TRootanaEventLoop().

VirtualOdb * TRootanaEventLoop::fODB [private]

Pointer to the ODB access instance.

Definition at line 224 of file TRootanaEventLoop.hxx.

Referenced by GetODB(), ProcessMidasFile(), TRootanaEventLoop(), and ~TRootanaEventLoop().

TDirectory * TRootanaEventLoop::fOnlineHistDir [protected]

TDirectory for online histograms.

Definition at line 198 of file TRootanaEventLoop.hxx.

Referenced by ExecuteLoop(), MyTestLoop::ProcessMidasEvent(), and TRootanaEventLoop().

std::string TRootanaEventLoop::fOnlineName [private]

Name of program, as seen by MIDAS.

Definition at line 250 of file TRootanaEventLoop.hxx.

Referenced by SetOnlineName(), and TRootanaEventLoop().

TFile * TRootanaEventLoop::fOutputFile [private]

Output ROOT file.

Definition at line 214 of file TRootanaEventLoop.hxx.

Referenced by CloseRootFile(), CreateOutputFile(), IsRootFileValid(), OpenRootFile(), and TRootanaEventLoop().

std::string TRootanaEventLoop::fOutputFilename [private]

Base part of the output filename File name will be XXX.root, where XXX is run number

Definition at line 218 of file TRootanaEventLoop.hxx.

Referenced by OpenRootFile(), SetOutputFilename(), and TRootanaEventLoop().

std::vector< int > TRootanaEventLoop::fProcessEventIDs [private]

This is the set of eventIDs to process.

Definition at line 241 of file TRootanaEventLoop.hxx.

Referenced by CheckEventID(), and ProcessThisEventID().

bool TRootanaEventLoop::fSuppressTimestampWarnings [private]

Bool for suppressing the warnings about old timestamps.

Definition at line 253 of file TRootanaEventLoop.hxx.

Referenced by GetSuppressTimestampWarnings(), SuppressTimestampWarnings(), and TRootanaEventLoop().

static TRootanaEventLoop * TRootanaEventLoop::fTRootanaEventLoop = NULL [static, protected]

The static pointer to the singleton instance.

Definition at line 195 of file TRootanaEventLoop.hxx.

Referenced by CreateSingleton(), and Get().

The documentation for this class was generated from the following files:
Generated on 5 May 2014 for ROOT Analyzer by  doxygen 1.6.1
