TDbiResultKey Class Reference

Concept Summarises the composition of a single TDbiResultSet. More...

#include <TDbiResultKey.hxx>

Inheritance diagram for TDbiResultKey:
Inheritance graph
[legend]
Collaboration diagram for TDbiResultKey:
Collaboration graph
[legend]

List of all members.

Classes

struct  VRecKey
 Container for a SeqNo and CreationDate pair. More...

Public Member Functions

 TDbiResultKey (const TDbiResultKey *that=0)
 TDbiResultKey (std::string tableName, std::string rowName, UInt_t seqno, TVldTimeStamp ts)
 .....................................................................
virtual ~TDbiResultKey ()
std::string AsString () const
Float_t Compare (const TDbiResultKey *that) const
Int_t GetNumVrecs () const
std::string GetTableRowName () const
Bool_t IsEqualTo (const TDbiResultKey *that) const
void AddVRecKey (UInt_t seqno, TVldTimeStamp ts)

Static Public Member Functions

static const TDbiResultKey * GetEmptyKey ()

Private Attributes

std::string fTableName
 Name of database table.
std::string fRowName
 Name of row objects.
std::list< TDbiResultKey::VRecKey > fVRecKeys
 Key for individual TDbiValidityRec.
Int_t fNumVRecKeys
 Optimisation: list::size() is slow!

Static Private Attributes

static TDbiResultKey fgEmptyKey

Detailed Description

Concept Summarises the composition of a single TDbiResultSet.

Id
TDbiResultKey.hxx,v 1.1 2011/01/18 05:49:20 finch Exp

Purpose To serve as summary of a single query. Contact: A.Finch@lancaster.ac.uk

Definition at line 34 of file TDbiResultKey.hxx.

Constructor & Destructor Documentation

TDbiResultKey::TDbiResultKey ( const TDbiResultKey *  that = 0  )

Definition at line 35 of file TDbiResultKey.cxx.

References SK_DBI_Trace.

00035                                                                :
00036 fNumVRecKeys(0)
00037 {
00038 //
00039 //
00040 //  Purpose:  Default constructor
00041 //
00042
00043
00044   SK_DBI_Trace( "Creating TDbiResultKey" << "  ");
00045   if ( that ) *this = *that;
00046 }

TDbiResultKey::TDbiResultKey ( std::string  tableName,
std::string  rowName,
UInt_t  seqno,
TVldTimeStamp  ts
)

.....................................................................

Definition at line 50 of file TDbiResultKey.cxx.

References AddVRecKey(), and SK_DBI_Trace.

00053                                              :
00054 fTableName(tableName),
00055 fRowName(rowName),
00056 fNumVRecKeys(0)
00057 {
00058 //
00059 //
00060 //  Purpose:  Standard constructor
00061 //
00062 //  Contact:   N. West
00063 //
00064 //  Specification:-
00065 //  =============
00066 //
00067 //  o  Create TDbiResultKey.
00068
00069
00070   SK_DBI_Trace( "Creating TDbiResultKey" << "  ");
00071
00072   this->AddVRecKey(seqno,ts);
00073 }

Here is the call graph for this function:

TDbiResultKey::~TDbiResultKey (  )  [virtual]

Definition at line 77 of file TDbiResultKey.cxx.

References SK_DBI_Trace.

00077                               {
00078 //
00079 //
00080 //  Purpose: Destructor
00081 //
00082 //  Contact:   N. West
00083 //
00084 //  Specification:-
00085 //  =============
00086 //
00087 //  o  Destroy TDbiResultKey
00088
00089
00090   SK_DBI_Trace( "Destroying TDbiResultKey" << "  ");
00091
00092 }

Member Function Documentation

void TDbiResultKey::AddVRecKey ( UInt_t  seqno,
TVldTimeStamp  ts
)

Definition at line 96 of file TDbiResultKey.cxx.

References fNumVRecKeys, and fVRecKeys.

Referenced by TDbiResultSetAgg::CreateKey(), and TDbiResultKey().

00096                                                              {
00097 //
00098 //
00099 //  Purpose:  Add a TDbiValidityRec key.
00100 //
00101
00102   fVRecKeys.push_back(VRecKey(seqno,ts));
00103   ++fNumVRecKeys;
00104
00105 }

Here is the caller graph for this function:

std::string TDbiResultKey::AsString (  )  const

Definition at line 109 of file TDbiResultKey.cxx.

References TVldTimeStamp::AsString(), fNumVRecKeys, fRowName, fTableName, and fVRecKeys.

00109                                         {
00110 //
00111 //
00112 //  Purpose:  Return a string that summarises this key giving:-
00113 //            1)  The table and row names.
00114 //            2)  The number of validity records (aggregates)
00115 //            3)  The range of SEQNOs
00116 //            4)  The range of CREATIONDATEs.
00117
00118   ostringstream os;
00119   os << "Table:" << fTableName << " row:" << fRowName;
00120   if ( fVRecKeys.empty() ) os << " No vrecs";
00121   else {
00122     os << ".  " << fNumVRecKeys << " vrec";
00123     if ( fNumVRecKeys > 1 ) os << "s (seqno min..max;creationdate min..max):";
00124     else                    os << " (seqno;creationdate):";
00125     os << " ";
00126     std::list<VRecKey>::const_iterator itr    = fVRecKeys.begin();
00127     std::list<VRecKey>::const_iterator itrEnd = fVRecKeys.end();
00128     UInt_t seqnoMin    = itr->SeqNo;
00129     UInt_t seqnoMax    = seqnoMin;
00130     TVldTimeStamp tsMin = itr->CreationDate;
00131     TVldTimeStamp tsMax = tsMin;
00132     ++itr;
00133     while ( itr != itrEnd ) {
00134       UInt_t       seqno = itr->SeqNo;
00135       TVldTimeStamp ts    = itr->CreationDate;
00136       if ( seqno < seqnoMin ) seqnoMin = seqno;
00137       if ( seqno > seqnoMax ) seqnoMax = seqno;
00138       if (    ts < tsMin    ) tsMin    = ts;
00139       if (    ts > tsMax    ) tsMax    = ts;
00140       ++itr;
00141     }
00142     os << seqnoMin;
00143     if ( seqnoMin < seqnoMax ) os << ".." << seqnoMax;
00144     os << ";" << tsMin.AsString("s");
00145     if ( tsMin < tsMax ) os << ".." <<  tsMax.AsString("s");
00146   }
00147   return string(os.str());
00148
00149 }

Here is the call graph for this function:

Float_t TDbiResultKey::Compare ( const TDbiResultKey *  that  )  const

Definition at line 152 of file TDbiResultKey.cxx.

References fRowName, fTableName, fVRecKeys, GetNumVrecs(), and SK_DBI_Debug.

Referenced by IsEqualTo().

00152                                                               {
00153 //
00154 //
00155 //  Purpose:  Compare 2 TDbiResultKeys
00156 //
00157 //  Return:    = -2. Table names don't match.
00158 //             = -1. Table names match but row names don't
00159 //                   i.e. contain different TDbiTableRow sub-classes.
00160 //             >= f  Table and row names match and fraction f of the
00161 //                   SEQNOs have same creation date.
00162 //                   So f = 1.  = perfect match.
00163
00164 //  Program Notes:-
00165 //  =============
00166
00167 //  None.
00168
00169   // Check in table and row names.
00170   if ( fTableName != that->fTableName ) return -2.;
00171   if ( fRowName   != that->fRowName   ) return -1.;
00172
00173   // Pick the key with the most entries and compare the other to it.
00174
00175   SK_DBI_Debug( "Comparing " << *this << " to "
00176                         << *that << "  ");
00177
00178   const TDbiResultKey* keyBig   = this;
00179   const TDbiResultKey* keySmall = that;
00180   if ( that->GetNumVrecs() > this->GetNumVrecs() ) {
00181     keyBig   = that;
00182     keySmall = this;
00183   }
00184   int numVrecs = keyBig->GetNumVrecs();
00185   if ( numVrecs == 0 ) return 0.;
00186
00187   std::map<UInt_t,TVldTimeStamp> seqnoToCreationDate;
00188   std::list<TDbiResultKey::VRecKey>::const_iterator itrEnd = keyBig->fVRecKeys.end();
00189   for (  std::list<TDbiResultKey::VRecKey>::const_iterator itr = keyBig->fVRecKeys.begin();
00190          itr != itrEnd;
00191          ++itr ) seqnoToCreationDate[itr->SeqNo] = itr->CreationDate;
00192   float match = 0;
00193   itrEnd = keySmall->fVRecKeys.end();
00194   for (  std::list<TDbiResultKey::VRecKey>::const_iterator itr = keySmall->fVRecKeys.begin();
00195          itr != itrEnd;
00196          ++itr ) {
00197     SK_DBI_Debug( "Comparing seqno " << itr->SeqNo << " with creation date " << itr->CreationDate
00198                          << " to " <<  seqnoToCreationDate[itr->SeqNo] << "  ");
00199     if ( seqnoToCreationDate[itr->SeqNo] == itr->CreationDate ) ++match;
00200   }
00201   SK_DBI_Debug( "Match results: " << match << " out of " << numVrecs << "  ");
00202
00203   return match/numVrecs;
00204
00205 }

Here is the call graph for this function:

Here is the caller graph for this function:

static const TDbiResultKey* TDbiResultKey::GetEmptyKey (  )  [inline, static]

Definition at line 53 of file TDbiResultKey.hxx.

References fgEmptyKey.

Referenced by TDbiResultSet::GetKey().

00053 { return &fgEmptyKey; }

Here is the caller graph for this function:

Int_t TDbiResultKey::GetNumVrecs (  )  const [inline]

Definition at line 54 of file TDbiResultKey.hxx.

References fNumVRecKeys.

Referenced by Compare().

00054 { return fNumVRecKeys; }

Here is the caller graph for this function:

std::string TDbiResultKey::GetTableRowName (  )  const

Definition at line 209 of file TDbiResultKey.cxx.

References fRowName, and fTableName.

00209                                                {
00210 //
00211 //
00212 //  Purpose:  Return TableName::RowName
00213
00214   ostringstream os;
00215   os << fTableName << "::" << fRowName;
00216   return os.str();
00217
00218 }

Bool_t TDbiResultKey::IsEqualTo ( const TDbiResultKey *  that  )  const [inline]

Definition at line 56 of file TDbiResultKey.hxx.

References Compare().

00056                                                          {
00057          return this->Compare(that) == 1.; }

Here is the call graph for this function:

Member Data Documentation

TDbiResultKey TDbiResultKey::fgEmptyKey [static, private]

Definition at line 75 of file TDbiResultKey.hxx.

Referenced by GetEmptyKey().

Int_t TDbiResultKey::fNumVRecKeys [private]

Optimisation: list::size() is slow!

Definition at line 89 of file TDbiResultKey.hxx.

Referenced by AddVRecKey(), AsString(), and GetNumVrecs().

std::string TDbiResultKey::fRowName [private]

Name of row objects.

Definition at line 83 of file TDbiResultKey.hxx.

Referenced by AsString(), Compare(), and GetTableRowName().

std::string TDbiResultKey::fTableName [private]

Name of database table.

Definition at line 80 of file TDbiResultKey.hxx.

Referenced by AsString(), Compare(), and GetTableRowName().

std::list<TDbiResultKey::VRecKey> TDbiResultKey::fVRecKeys [private]

Key for individual TDbiValidityRec.

Definition at line 86 of file TDbiResultKey.hxx.

Referenced by AddVRecKey(), AsString(), and Compare().

The documentation for this class was generated from the following files:
