TDbiValidityRec Class Reference

Concept A concrete data type corresponding to a single row in an auxillary validity range database table. More...

#include <TDbiValidityRec.hxx>

Inheritance diagram for TDbiValidityRec:
Inheritance graph
[legend]
Collaboration diagram for TDbiValidityRec:
Collaboration graph
[legend]

List of all members.

Public Member Functions

 TDbiValidityRec (Int_t dbNo=-1, Bool_t isGap=kTRUE)
 TDbiValidityRec (const TDbiValidityRec &from)
 TDbiValidityRec (const TVldRange &range, TDbi::Task task, Int_t aggNo, UInt_t seqNo, Int_t dbNo=-1, Bool_t isGap=kFALSE, TVldTimeStamp time=TVldTimeStamp(), UInt_t epoch=0)
virtual ~TDbiValidityRec ()
virtual TDbiTableRow * CreateTableRow () const
Int_t GetAggregateNo () const
TVldTimeStamp GetCreationDate () const
UInt_t GetDbNo () const
UInt_t GetEpoch () const
TVldTimeStamp GetInsertDate () const
TDbi::Task GetTask () const
std::string GetL2CacheName () const
UInt_t GetSeqNo () const
const TDbiTableProxy * GetTableProxy () const
const TVldRange & GetVldRange () const
Bool_t HasExpired (const TDbiValidityRec &other) const
Bool_t HasExpired (const TVldContext &vc, const TDbi::Task &task) const
Bool_t IsCompatible (const TVldContext &vc, const TDbi::Task &task) const
Bool_t IsGap () const
Bool_t IsHigherPriority (const TDbiValidityRec &that, Bool_t useCreationDate=false) const
void AndTimeWindow (const TVldTimeStamp &start, const TVldTimeStamp &end)
void SetAggregateNo (Int_t aggNo)
void SetDbNo (Int_t dbNo)
void SetEpoch (UInt_t epoch)
void SetTableProxy (const TDbiTableProxy *tp)
void SetTimeWindow (const TVldTimeStamp &start, const TVldTimeStamp &end)
void SetVldRange (const TVldRange &range)
void Trim (const TVldTimeStamp &queryTime, const TDbiValidityRec &other)
virtual void Fill (TDbiInRowStream &rs, const TDbiValidityRec *vrec)
virtual void Store (TDbiOutRowStream &ors, const TDbiValidityRec *vrec) const
void Streamer (TDbiBinaryFile &file)
virtual Bool_t CanL2Cache () const
 Replace this with a function returning true in order to use the level 2 disk cache.
TDbiResultSet * GetOwner () const
virtual UInt_t GetIndex (UInt_t defIndex) const
void SetOwner (TDbiResultSet *owner)
virtual void Fill (TDbiInRowStream &rs, const TDbiValidityRec *vrec)=0
virtual void Store (TDbiOutRowStream &, const TDbiValidityRec *) const

Static Public Member Functions

static std::string GetL2CacheName (UInt_t seqLo, UInt_t seqHi, TVldTimeStamp ts)

Private Attributes

Int_t fAggregateNo
TVldTimeStamp fCreationDate
 Creation date.
Int_t fDbNo
 Cascade no. of source db =-1 unknown.
TVldTimeStamp fInsertDate
 Insertion date.
Bool_t fIsGap
 kTRUE if corresponds to a gap.
TDbi::Task fTask
 Task number.
Int_t fSeqNo
 Sequence number or 0 if compound.
const TDbiTableProxy * fTableProxy
 TDbiTableProxy that filled this (if any).
TVldRange fVldRange
 Validity range of record.
UInt_t fEpoch
 Calibration Epoch.
UInt_t fReality
 Reality (for possible, but improbable future use).

Detailed Description

Concept A concrete data type corresponding to a single row in an auxillary validity range database table.

Id
TDbiValidityRec.hxx,v 1.1 2011/01/18 05:49:20 finch Exp

Purpose To resolve ambiguities in the case of multiple matches to a query and to record results of validity range trimming due to neighbouring database entries. Contact: A.Finch@lancaster.ac.uk

Definition at line 39 of file TDbiValidityRec.hxx.

Constructor & Destructor Documentation

TDbiValidityRec::TDbiValidityRec ( Int_t  dbNo = -1,
Bool_t  isGap = kTRUE
)

Definition at line 121 of file TDbiValidityRec.cxx.

References SK_DBI_Trace.

00121                                                         :
00122
00123 fAggregateNo(-2),
00124 fDbNo(dbNo),
00125 fIsGap(isGap),
00126 fTask(0),
00127 fSeqNo(0),
00128 fTableProxy(0),
00129 fEpoch(0),
00130 fReality(0)
00131 {
00132 //
00133 //
00134 //  Purpose:  Default constructor
00135 //
00136 //  Arguments:.
00137 //    dbNo     in    Cascade no. of database holding record.
00138 //    isGap    in    = kTRUE if a gap.
00139 //
00140 //  Return:    n/a
00141 //
00142 //  Contact:   N. West
00143 //
00144 //  Specification:-
00145 //  =============
00146 //
00147 //  o Create ValidityRec.
00148
00149
00150 //  Program Notes:-
00151 //  =============
00152
00153 //  None.
00154
00155
00156   SK_DBI_Trace( "Creating TDbiValidityRec" << "  ");
00157 }
//.....................................................................

TDbiValidityRec::TDbiValidityRec ( const TDbiValidityRec &  from  )

Definition at line 160 of file TDbiValidityRec.cxx.

References SK_DBI_Trace.

00160                                                             : TDbiTableRow(from)
00161 {
00162 //
00163 //
00164 //  Purpose:  Copy constructor
00165 //
00166 //  Arguments:
00167 //    from    in    Object to be copied from.
00168 //
00169 //  Return:    n/a
00170 //
00171 //  Contact:   N. West
00172 //
00173 //  Specification:-
00174 //  =============
00175 //
00176 //  o Create ValidityRec.
00177
00178
00179 //  Program Notes:-
00180 //  =============
00181
00182 //  Explicit just for leak checking.
00183
00184
00185   SK_DBI_Trace( "Creating TDbiValidityRec" << "  ");
00186
00187   *this = from;
00188
00189 }

TDbiValidityRec::TDbiValidityRec ( const TVldRange &  range,
TDbi::Task  task,
Int_t  aggNo,
UInt_t  seqNo,
Int_t  dbNo = -1,
Bool_t  isGap = kFALSE,
TVldTimeStamp  time = TVldTimeStamp(),
UInt_t  epoch = 0
)

Definition at line 192 of file TDbiValidityRec.cxx.

References SK_DBI_Trace.

00199                                              :
00200 fAggregateNo(aggNo),
00201 fCreationDate(time),
00202 fDbNo(dbNo),
00203 fIsGap(isGap),
00204 fTask(task),
00205 fSeqNo(seqNo),
00206 fTableProxy(0),
00207 fVldRange(range),
00208 fEpoch(epoch),
00209 fReality(0)
00210 {
00211 //
00212 //
00213 //  Purpose:  Constructor from components
00214 //
00215 //  Arguments:
00216 //    range    in   component range
00217 //    task     in   component task
00218 //    aggNo    in   component aggregate number
00219 //    seqNo    in   component sequence number
00220 //    dbNo     in    Cascade no. of database holding record.
00221 //    isGap    in    = kTRUE if a gap.
00222 //    epoch    in   component calibration epoch
00223 //
00224 //
00225 //
00226 //  Return:    n/a
00227 //
00228 //  Contact:   N. West
00229 //
00230 //  Specification:-
00231 //  =============
00232 //
00233 //  o Create ValidityRec.
00234
00235
00236 //  Program Notes:-
00237 //  =============
00238
00239 //  None.
00240
00241
00242   SK_DBI_Trace( "Creating TDbiValidityRec" << "  ");
00243 }

TDbiValidityRec::~TDbiValidityRec (  )  [virtual]

Definition at line 247 of file TDbiValidityRec.cxx.

References SK_DBI_Trace.

00247                                   {
00248 //
00249 //
00250 //  Purpose: Destructor
00251 //
00252 //  Arguments:
00253 //    None.
00254 //
00255 //  Return:    n/a
00256 //
00257 //  Contact:   N. West
00258 //
00259 //  Specification:-
00260 //  =============
00261 //
00262 //  o  Destroy ValidityRec.
00263
00264
00265 //  Program Notes:-
00266 //  =============
00267
00268 //  None.
00269
00270
00271   SK_DBI_Trace( "Destroying TDbiValidityRec" << "  ");
00272
00273 }

Member Function Documentation

void TDbiValidityRec::AndTimeWindow ( const TVldTimeStamp &  start,
const TVldTimeStamp &  end
)

Definition at line 87 of file TDbiValidityRec.cxx.

References fVldRange, TVldRange::GetTimeEnd(), TVldRange::GetTimeStart(), and SetTimeWindow().

00088                                                                   {
00089 //
00090 //
00091 //  Purpose:  And in supplied start and end times.
00092 //
00093 //  Arguments:
00094 //    startOther   in    Start time to be ANDed in.
00095 //    endOther     in    End time to be ANDed in.
00096 //
00097 //  Return:   None.
00098 //
00099 //  Contact:   N. West
00100 //
00101 //  Specification:-
00102 //  =============
00103 //
00104 //  o Trim time windown on current record to be the overlap (and)
00105 //    with the supplied time window.
00106
00107 //  Program Notes:-
00108 //  =============
00109
00110 //  None.
00111
00112   TVldTimeStamp start = fVldRange.GetTimeStart();
00113   TVldTimeStamp end   = fVldRange.GetTimeEnd();
00114
00115   SetTimeWindow( start > startOther ? start : startOther,
00116                  end   < endOther   ? end   : endOther );
00117 }

Here is the call graph for this function:

virtual Bool_t TDbiTableRow::CanL2Cache (  )  const [inline, virtual, inherited]

Replace this with a function returning true in order to use the level 2 disk cache.

Definition at line 59 of file TDbiTableRow.hxx.

00059 { return kFALSE; }

virtual TDbiTableRow* TDbiValidityRec::CreateTableRow (  )  const [inline, virtual]

Implements TDbiTableRow.

Definition at line 60 of file TDbiValidityRec.hxx.

00060                                                {
00061                                            return new TDbiValidityRec; }

virtual void TDbiTableRow::Fill ( TDbiInRowStream &  rs,
const TDbiValidityRec *  vrec
) [pure virtual, inherited]

Implemented in TDbiConfigSet, TDbiLogEntry, and TTableRow.

Referenced by ClassImp().

Here is the caller graph for this function:

void TDbiValidityRec::Fill ( TDbiInRowStream &  rs,
const TDbiValidityRec *  vrec
) [virtual]

Definition at line 277 of file TDbiValidityRec.cxx.

References TVldRange::AsString(), TDbiInRowStream::CurRowNum(), fAggregateNo, fCreationDate, fDbNo, fEpoch, fInsertDate, fIsGap, fReality, fSeqNo, fTableProxy, fTask, fVldRange, TDbiInRowStream::GetDbNo(), TDbiInRowStream::GetTableProxy(), TDbiRowStream::HasEpoch(), and SK_DBI_Verbose.

00278                                                              {
00279 //
00280 //
00281 //  Purpose:  Fill oject from Result Set
00282 //
00283 //  Arguments:
00284 //    rs           in    Result Set used to fill object
00285 //    vrec         in    =0.  If filling other table rows it points
00286 //                       to the associated validity record.
00287 //
00288 //  Return:
00289 //
00290 //  Contact:   N. West
00291 //
00292 //  Specification:-
00293 //  =============
00294 //
00295 //  o Fill object from current row of Result Set.
00296
00297 //  Program Notes:-
00298 //  =============
00299
00300 //  None.
00301
00302     TVldTimeStamp start, end;
00303     Int_t detMask, simMask;
00304
00305 //  Establish source TDbiTableProxy and cascade no.
00306
00307     fTableProxy = rs.GetTableProxy();
00308     fDbNo       = rs.GetDbNo();
00309
00310 //  Read data from row.
00311
00312     rs >> fSeqNo >> start >> end;
00313
00314     if ( rs.HasEpoch() ) rs >> fEpoch >> fReality;
00315     else fEpoch = fReality = 0;
00316
00317     rs >> detMask >> simMask >> fTask
00318        >> fAggregateNo    >> fCreationDate  >> fInsertDate;
00319
00320     fIsGap = kFALSE;
00321
00322     TVldRange vr(detMask, simMask, start, end, "From Database");
00323     fVldRange = vr;
00324
00325     SK_DBI_Verbose(  "TDbiValidityRec for row " << rs.CurRowNum()
00326          << ": " << fVldRange.AsString()
00327          << " seq num: " << fSeqNo
00328          << " agg no: "  << fAggregateNo
00329          << " task: " << "  ");
00330 }

Here is the call graph for this function:

Int_t TDbiValidityRec::GetAggregateNo (  )  const [inline, virtual]

Reimplemented from TDbiTableRow.

Definition at line 62 of file TDbiValidityRec.hxx.

References fAggregateNo.

Referenced by TDbiCache::Adopt(), ClassImp(), TDbiConfigSet::Fill(), operator<<(), TDbiConfigStream::operator<<(), TDbiTableProxy::QueryOverlayCreationDate(), TDbiCache::Search(), TDbiValidityRecBuilder::TDbiValidityRecBuilder(), and TDbiConfigStream::Write().

00062 { return fAggregateNo; }

Here is the caller graph for this function:

TVldTimeStamp TDbiValidityRec::GetCreationDate (  )  const [inline]

Definition at line 65 of file TDbiValidityRec.hxx.

References fCreationDate.

Referenced by TDbiResultSetNonAgg::CreateKey(), TDbiResultSetAgg::CreateKey(), TDbiDBProxy::FindTimeBoundaries(), TDbiValidityRecBuilder::GetL2CacheName(), GetL2CacheName(), TDbiResultSetNonAgg::Satisfies(), and TDbiLogEntry::Write().

00065 { return fCreationDate; }

Here is the caller graph for this function:

UInt_t TDbiValidityRec::GetDbNo (  )  const [inline]

Definition at line 66 of file TDbiValidityRec.hxx.

References fDbNo.

Referenced by fCreationDate(), operator<<(), and TDbiTableProxy::Query().

00066 { return fDbNo; }

Here is the caller graph for this function:

UInt_t TDbiValidityRec::GetEpoch (  )  const [inline]

Definition at line 67 of file TDbiValidityRec.hxx.

References fEpoch.

Referenced by TDbiDBProxy::FindTimeBoundaries(), and operator<<().

00067 { return fEpoch; }

Here is the caller graph for this function:

virtual UInt_t TDbiTableRow::GetIndex ( UInt_t  defIndex  )  const [inline, virtual, inherited]

Reimplemented in TDemo2_DB_Table, and TDemo_DB_Table.

Definition at line 65 of file TDbiTableRow.hxx.

Referenced by TDbiResultSet::BuildLookUpTable().

00065 {return defIndex;}

Here is the caller graph for this function:

TVldTimeStamp TDbiValidityRec::GetInsertDate (  )  const [inline]

Definition at line 68 of file TDbiValidityRec.hxx.

References fInsertDate.

00068 { return fInsertDate; }

std::string TDbiValidityRec::GetL2CacheName ( UInt_t  seqLo,
UInt_t  seqHi,
TVldTimeStamp  ts
) [static]

Definition at line 351 of file TDbiValidityRec.cxx.

References TVldTimeStamp::AsString().

00353                                                              {
00354 //
00355 //
00356 //  Purpose:  Return the associated Level 2 Cache Name.
00357 //
00358 //  Specification:-
00359 //  =============
00360 //
00361 //  o For unaggregated queries name format: <Seqno>_<CreationDate>
00362 //
00363 //  o For aggregated queries name format:   <LowSeqno>_<HighSeqNo>_<MaxCreationDate>
00364
00365 //  Program Notes:-
00366 //  =============
00367
00368 //  The static routine centralises the definition of cache names both for
00369 //  TDbiValidityRec and TDbiValidityRecBuilder.
00370
00371   ostringstream oss;
00372   oss << seqLo << "_";
00373   if ( seqLo != seqHi )  oss << seqHi << "_";
00374   oss << ts.AsString("s");
00375   std::string str(oss.str());
00376   // Convert white space to underscore.
00377   int i = str.size();
00378   while ( i-- ) if ( str[i] == ' ' ) str[i] = '_';
00379   return str;
00380
00381 }

Here is the call graph for this function:

std::string TDbiValidityRec::GetL2CacheName (  )  const

Definition at line 334 of file TDbiValidityRec.cxx.

References GetCreationDate(), and GetSeqNo().

Referenced by TDbiTableProxy::Query().

00334                                                 {
00335 //
00336 //
00337 //  Purpose:  Return the associated Level 2 Cache Name.
00338 //
00339 //  Specification:-
00340 //  =============
00341 //
00342 //  o See GetL2CacheName(UInt_t seqLo, UInt_t seqHi, TVldTimeStamp ts);
00343
00344   return TDbiValidityRec::GetL2CacheName(this->GetSeqNo(),
00345                                         this->GetSeqNo(),
00346                                         this->GetCreationDate());
00347
00348 }

Here is the call graph for this function:

Here is the caller graph for this function:

TDbiResultSet* TDbiTableRow::GetOwner (  )  const [inline, inherited]

Definition at line 63 of file TDbiTableRow.hxx.

References TDbiTableRow::fOwner.

Referenced by TDbiResultSet::BuildLookUpTable(), and TDbiResultSetAgg::GetValidityRec().

00063 { return fOwner; }

Here is the caller graph for this function:

UInt_t TDbiValidityRec::GetSeqNo (  )  const [inline]

Definition at line 71 of file TDbiValidityRec.hxx.

References fSeqNo.

Referenced by TDbiResultSet::BuildLookUpTable(), TDbiResultSetNonAgg::CreateKey(), TDbiResultSetAgg::CreateKey(), fCreationDate(), TDbiValidityRecBuilder::GetL2CacheName(), GetL2CacheName(), TDbiValRecSet::GetTableRowBySeqNo(), operator<<(), TDbiTableProxy::Query(), TDbiTableProxy::RestoreFromL2Cache(), and TDbiResultSetNonAgg::Satisfies().

00071 { return fSeqNo; }

Here is the caller graph for this function:

const TDbiTableProxy* TDbiValidityRec::GetTableProxy (  )  const [inline]

Definition at line 72 of file TDbiValidityRec.hxx.

References fTableProxy.

Referenced by fCreationDate(), TDbiTableProxy::Query(), and TDbiConfigStream::Write().

00072 { return fTableProxy; }

Here is the caller graph for this function:

TDbi::Task TDbiValidityRec::GetTask (  )  const [inline]

Definition at line 69 of file TDbiValidityRec.hxx.

References fTask.

Referenced by TDbiLogEntry::Fill(), HasExpired(), operator<<(), TDbiTableProxy::QueryOverlayCreationDate(), and TDbiLogEntry::Write().

00069 { return fTask; }

Here is the caller graph for this function:

const TVldRange& TDbiValidityRec::GetVldRange (  )  const [inline]

Definition at line 73 of file TDbiValidityRec.hxx.

References fVldRange.

Referenced by ClassImp(), TDbiLogEntry::Fill(), HasExpired(), operator<<(), TDbiTableProxy::QueryOverlayCreationDate(), TDbiValidityRecBuilder::TDbiValidityRecBuilder(), Trim(), and TDbiLogEntry::Write().

00073 { return fVldRange;}

Here is the caller graph for this function:

Bool_t TDbiValidityRec::HasExpired ( const TVldContext &  vc,
const TDbi::Task &  task
) const

Definition at line 424 of file TDbiValidityRec.cxx.

References TVldContext::GetDetector(), TVldRange::GetDetectorMask(), TVldContext::GetSimFlag(), TVldRange::GetSimMask(), GetTask(), TVldRange::GetTimeEnd(), TVldContext::GetTimeStamp(), TVldRange::GetTimeStart(), and GetVldRange().

00425                                                               {
00426 //
00427 //
00428 //  Purpose: See if validity record has expired i.e. is compatible with
00429 //           this context query except for date.
00430 //
00431 //  Arguments:
00432 //    vc           in    Context of query
00433 //    task         in    Task of query
00434 //
00435 //
00436 //  Contact:   N. West
00437
00438 //  Program Notes:-
00439 //  =============
00440
00441 //  This method is used by TDbiResultSet to identify when ready for
00442 //  purging.
00443
00444   TVldTimeStamp    ts = vc.GetTimeStamp();
00445   const TVldRange& vr = this->GetVldRange();
00446
00447   return
00448      (       task             == this->GetTask()
00449         && ( vc.GetDetector() &  vr.GetDetectorMask() )
00450         && ( vc.GetSimFlag()  &  vr.GetSimMask() )
00451         && (    ts            >= vr.GetTimeEnd()
00452              || ts            <  vr.GetTimeStart() )
00453      );
00454
00455 }

Here is the call graph for this function:

Bool_t TDbiValidityRec::HasExpired ( const TDbiValidityRec &  other  )  const

Definition at line 385 of file TDbiValidityRec.cxx.

References fTask, fVldRange, TVldRange::GetDetectorMask(), TVldRange::GetSimMask(), GetTask(), TVldRange::GetTimeEnd(), TVldRange::GetTimeStart(), and GetVldRange().

Referenced by TDbiResultSet::Satisfies().

00385                                                                      {
00386 //
00387 //
00388 //  Purpose: See if validity record has expired i.e. is compatible with
00389 //           this one except for date.
00390 //
00391 //  Arguments:
00392 //    other        in    Other TDbiValidityRec to be compared with
00393 //
00394 //  Return:
00395 //
00396 //  Contact:   N. West
00397 //
00398 //  Specification:-
00399 //  =============
00400 //
00401 //  o See if validity record has expired i.e. is compatible with
00402 //    this one except for date.
00403
00404 //  Program Notes:-
00405 //  =============
00406
00407 //  This method is used by TDbiCache to select candidates for
00408 //  purging.
00409
00410   const TVldRange& otherVR =other.GetVldRange();
00411
00412   return
00413      (       other.GetTask() == fTask
00414         && ( otherVR.GetDetectorMask() & fVldRange.GetDetectorMask() )
00415         && ( otherVR.GetSimMask()      & fVldRange.GetSimMask() )
00416         && (    otherVR.GetTimeStart() >= fVldRange.GetTimeEnd()
00417              || otherVR.GetTimeEnd()   <= fVldRange.GetTimeStart() )
00418      );
00419
00420 }

Here is the call graph for this function:

Here is the caller graph for this function:

Bool_t TDbiValidityRec::IsCompatible ( const TVldContext &  vc,
const TDbi::Task &  task
) const

Definition at line 460 of file TDbiValidityRec.cxx.

References TVldContext::AsString(), TVldRange::AsString(), fTask, fVldRange, TVldRange::IsCompatible(), and SK_DBI_Debug.

Referenced by TDbiResultSet::Satisfies().

00461                                                                 {
00462 //
00463 //
00464 //  Purpose: See if result is compatible with query.
00465 //
00466 //  Arguments:
00467 //    vc           in    Context of new query
00468 //    task         in    Task of new query
00469 //
00470 //  Return:
00471 //
00472 //  Contact:   N. West
00473 //
00474 //  Specification:-
00475 //  =============
00476 //
00477 //  o See if result is compatible with query.
00478
00479 //  Program Notes:-
00480 //  =============
00481
00482 //  None.
00483
00484    SK_DBI_Debug(  " TDbiValidityRec::IsCompatible : tasks:"
00485      << task << "," << fTask
00486      << " is compat: " << fVldRange.IsCompatible(vc) << "  "
00487      << "   range " << fVldRange.AsString() << "  "
00488      << "   context " << vc.AsString() << "  ");
00489
00490   return task == fTask  && fVldRange.IsCompatible(vc);
00491
00492 }

Here is the call graph for this function:

Here is the caller graph for this function:

Bool_t TDbiValidityRec::IsGap (  )  const [inline]

Definition at line 79 of file TDbiValidityRec.hxx.

References fIsGap.

Referenced by ClassImp(), TDbiValidityRecBuilder::GetL2CacheName(), operator<<(), TDbiTableProxy::Query(), TDbiResultSetAgg::Streamer(), and Trim().

00079 { return fIsGap; }

Here is the caller graph for this function:

Bool_t TDbiValidityRec::IsHigherPriority ( const TDbiValidityRec &  that,
Bool_t  useCreationDate = false
) const

Definition at line 497 of file TDbiValidityRec.cxx.

References fCreationDate, fEpoch, fInsertDate, fVldRange, and TVldRange::GetTimeStart().

Referenced by ClassImp().

00498                                                                       {
00499 //
00500 //  Purpose:  Compare priorities (used in context queries to resolve ambiguities between VLD entries).
00501 //
00502 //  Arguments:
00503 //    that             in    The TDbiValidityRec to be compared with
00504 //    useCreationDate  in    If false (the default value) use the T2K resolution scheme
00505 //                           which is resolved, in order, by EPOCH, STARTTIME, INSERTDATE
00506 //                           If true use the MINOS resolution scheme which is resolved by CREATIONDATE.
00507 //
00508 //  Return:   True if this is of higher priority than that.
00509
00510   if ( useCreationDate) return fCreationDate > that.fCreationDate;
00511
00512   if ( fEpoch != that.fEpoch ) return fEpoch > that.fEpoch;
00513   if ( fVldRange.GetTimeStart() != that.fVldRange.GetTimeStart() )
00514     return fVldRange.GetTimeStart() > that.fVldRange.GetTimeStart();
00515   return fInsertDate > that.fInsertDate;
00516
00517 }

Here is the call graph for this function:

Here is the caller graph for this function:

void TDbiValidityRec::SetAggregateNo ( Int_t  aggNo  )  [inline]

Definition at line 88 of file TDbiValidityRec.hxx.

References fAggregateNo.

Referenced by TDbiConfigStream::Write().

00088 { fAggregateNo = aggNo; }

Here is the caller graph for this function:

void TDbiValidityRec::SetDbNo ( Int_t  dbNo  )  [inline]

Definition at line 89 of file TDbiValidityRec.hxx.

References fDbNo.

Referenced by ClassImp().

00089 { fDbNo = dbNo; }

Here is the caller graph for this function:

void TDbiValidityRec::SetEpoch ( UInt_t  epoch  )  [inline]

Definition at line 90 of file TDbiValidityRec.hxx.

References fEpoch.

00090 { fEpoch = epoch; }

void TDbiTableRow::SetOwner ( TDbiResultSet *  owner  )  [inline, inherited]

Definition at line 68 of file TDbiTableRow.hxx.

References TDbiTableRow::fOwner.

Referenced by ClassImp().

00068 {fOwner = owner;}

Here is the caller graph for this function:

void TDbiValidityRec::SetTableProxy ( const TDbiTableProxy *  tp  )  [inline]

Definition at line 91 of file TDbiValidityRec.hxx.

References fTableProxy.

00091 { fTableProxy = tp; }

void TDbiValidityRec::SetTimeWindow ( const TVldTimeStamp &  start,
const TVldTimeStamp &  end
)

Definition at line 522 of file TDbiValidityRec.cxx.

References fVldRange, TVldRange::GetDataSource(), TVldRange::GetDetectorMask(), and TVldRange::GetSimMask().

Referenced by AndTimeWindow(), and Trim().

00523                                                              {
00524 //
00525 //
00526 //  Purpose:  Set supplied start and end times.
00527 //
00528 //  Arguments:
00529 //    start        in    Start time to be set,
00530 //    end          in    End time to be set.
00531 //
00532 //  Return:   None.
00533 //
00534 //  Contact:   N. West
00535 //
00536 //  Specification:-
00537 //  =============
00538 //
00539 //  o Set time windown on current record.
00540
00541 //  Program Notes:-
00542 //  =============
00543
00544 //  The method here is rather clumsy, but I don't know of anything
00545 //  better!
00546
00547   TVldRange  range(fVldRange.GetDetectorMask(),
00548                   fVldRange.GetSimMask(),
00549                   start,
00550                   end,
00551                   fVldRange.GetDataSource() );
00552   fVldRange = range;
00553
00554 }

Here is the call graph for this function:

Here is the caller graph for this function:

void TDbiValidityRec::SetVldRange ( const TVldRange &  range  )  [inline]

Definition at line 94 of file TDbiValidityRec.hxx.

References fVldRange.

Referenced by ClassImp().

00094 { fVldRange=range;}

Here is the caller graph for this function:

virtual void TDbiTableRow::Store ( TDbiOutRowStream &  ,
const TDbiValidityRec *
) const [inline, virtual, inherited]

Reimplemented in TDbiConfigSet, and TDbiLogEntry.

Definition at line 73 of file TDbiTableRow.hxx.

Referenced by TDbiSqlValPacket::AddRow().

00074                                                               { assert(0); }

Here is the caller graph for this function:

void TDbiValidityRec::Store ( TDbiOutRowStream &  ors,
const TDbiValidityRec *  vrec
) const [virtual]

Definition at line 558 of file TDbiValidityRec.cxx.

References fAggregateNo, fCreationDate, fEpoch, fInsertDate, fReality, fSeqNo, fTask, fVldRange, TVldRange::GetDetectorMask(), TVldRange::GetSimMask(), TVldRange::GetTimeEnd(), TVldRange::GetTimeStart(), and TDbiRowStream::HasEpoch().

Referenced by TDbiSqlValPacket::Recreate().

00559                                                                     {
00560 //
00561 //
00562 //  Purpose:  Stream object to output row stream
00563 //
00564 //  Arguments:
00565 //    ors          in    Output row stream.
00566 //    vrec         in    =0.  If filling other table rows it points
00567 //                       to the associated validity record.
00568 //
00569 //  Return:
00570 //
00571 //  Contact:   N. West
00572 //
00573 //  Specification:-
00574 //  =============
00575 //
00576 //  o  Stream object to output row stream.
00577
00578 //  Program Notes:-
00579 //  =============
00580
00581 //  None.
00582
00583 //  Write data to row.
00584
00585     ors << fSeqNo
00586         << fVldRange.GetTimeStart()
00587         << fVldRange.GetTimeEnd();
00588     if ( ors.HasEpoch() ) ors << fEpoch << fReality;
00589     ors << fVldRange.GetDetectorMask()
00590         << fVldRange.GetSimMask()
00591         << fTask
00592         << fAggregateNo
00593         << fCreationDate
00594         << fInsertDate;
00595 }

Here is the call graph for this function:

Here is the caller graph for this function:

void TDbiValidityRec::Streamer ( TDbiBinaryFile &  file  )

Definition at line 598 of file TDbiValidityRec.cxx.

References fAggregateNo, fCreationDate, fDbNo, fEpoch, fInsertDate, fIsGap, fReality, fSeqNo, fTableProxy, fTask, fVldRange, TDbiBinaryFile::IsReading(), and TDbiBinaryFile::IsWriting().

Referenced by TDbiResultSet::Streamer().

00598                                                    {
00599 //
00600 //
00601 //  Purpose:  I/O to binary file
00602 //
00603 //  Program Notes:-
00604 //  =============
00605
00606 //  Don't store the pointer fTableProxy (don't want to get into storing
00607 //  pointers!); the TDbiCache will fix it up on input
00608
00609   if ( file.IsReading() ) {
00610     file >> fAggregateNo
00611          >> fCreationDate
00612          >> fEpoch
00613          >> fReality
00614          >> fDbNo
00615          >> fInsertDate
00616          >> fIsGap
00617          >> fTask
00618          >> fSeqNo
00619          >> fVldRange;
00620     fTableProxy = 0;
00621   }
00622   else if ( file.IsWriting() ) {
00623     file << fAggregateNo
00624          << fCreationDate
00625          << fEpoch
00626          << fReality
00627          << fDbNo
00628          << fInsertDate
00629          << fIsGap
00630          << fTask
00631          << fSeqNo
00632          << fVldRange;
00633   }
00634 }

Here is the call graph for this function:

Here is the caller graph for this function:

void TDbiValidityRec::Trim ( const TVldTimeStamp &  queryTime,
const TDbiValidityRec &  other
)

Definition at line 638 of file TDbiValidityRec.cxx.

References fAggregateNo, fVldRange, TVldRange::GetTimeEnd(), TVldRange::GetTimeStart(), GetVldRange(), IsGap(), and SetTimeWindow().

Referenced by ClassImp().

00639                                                         {
00640 //
00641 //
00642 //  Purpose:  Trim this validity record so that represents
00643 //            best validity record for query.
00644 //
00645 //  Arguments:
00646 //    queryTime    in    Time of query
00647 //    other        in    TDbiValidity record satisfying query
00648 //
00649 //  Return:    None.
00650 //
00651 //  Contact:   N. West
00652 //
00653 //  Specification:-
00654 //  =============
00655 //
00656 //  o Update this validity record so that it remains the best
00657 //    validity record taking into account the supplied record.
00658
00659
00660 //  Program Notes:-
00661 //  =============
00662
00663 //  This is the function that deal with validity management.
00664 //  It takes into account that several validity records may
00665 //  overlap and that the best one is the one with:-
00666 //    For MINOS:  the latest creation date
00667 //    For T2K:    the highest EPOCH,TIMESTART,INSERTDATE
00668 //  that brackets the query date.  Other higher priority entries
00669 //  may trim start or end times.
00670
00671 //  Assumptions:-
00672 //  ===========
00673 //
00674 //  That entries are submitted in strict descending priority i.e.:-
00675 //
00676 //  1)  Entries for a higher priority database precede those from a
00677 //      lower priority one.
00678 //
00679 //  2)  Within a database entries are in descending CREATIONDATE or
00680 //      EPOCH,TIMESTART,INSERTDATE order.
00681 //
00682 //  This means that, until an entry that overlaps the supplied query time
00683 //  is reach, the entries just restrict the possible time window.  The first
00684 //  entry that overlaps the supplied time is accepted with a trimmed window
00685 //  and all subsequent entries ignored.
00686
00687 //  Ignore other records that are either gaps or have wrong
00688 //  aggregate number.
00689
00690   if ( fAggregateNo != other.fAggregateNo || other.IsGap() ) return;
00691
00692 //  If this record is not a gap then the other record can be ignore
00693 //  as it is of lower priority.
00694
00695   if ( ! IsGap() ) return;
00696
00697   TVldTimeStamp start      = fVldRange.GetTimeStart();
00698   TVldTimeStamp end        = fVldRange.GetTimeEnd();
00699   TVldTimeStamp startOther = other.GetVldRange().GetTimeStart();
00700   TVldTimeStamp endOther   = other.GetVldRange().GetTimeEnd();
00701
00702 // If entry brackets query date, then use it but with a validity that
00703 // is trimmed by the current record.
00704
00705   if ( startOther <= queryTime && endOther > queryTime ) {
00706     if ( start < startOther ) start = startOther;
00707     if ( end   > endOther   ) end   = endOther;
00708     *this = other;
00709     SetTimeWindow(start,end);
00710   }
00711
00712 // It doesn't bracket, so use it to trim the window
00713
00714   else {
00715
00716     if ( endOther <= queryTime ) {
00717       if ( start < endOther   ) SetTimeWindow(endOther,end);
00718     }
00719     else if ( startOther > queryTime ) {
00720       if ( end   > startOther ) SetTimeWindow(start, startOther);
00721     }
00722   }
00723
00724 }

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

Int_t TDbiValidityRec::fAggregateNo [private]

Aggregate number or:- -1 Non-aggregated data or multiple aggregates -2 undefined aggregates

Definition at line 113 of file TDbiValidityRec.hxx.

Referenced by Fill(), GetAggregateNo(), SetAggregateNo(), Store(), Streamer(), and Trim().

TVldTimeStamp TDbiValidityRec::fCreationDate [private]

Creation date.

Definition at line 116 of file TDbiValidityRec.hxx.

Referenced by Fill(), GetCreationDate(), IsHigherPriority(), Store(), and Streamer().

Int_t TDbiValidityRec::fDbNo [private]

Cascade no. of source db =-1 unknown.

Definition at line 119 of file TDbiValidityRec.hxx.

Referenced by Fill(), GetDbNo(), SetDbNo(), and Streamer().

UInt_t TDbiValidityRec::fEpoch [private]

Calibration Epoch.

Definition at line 141 of file TDbiValidityRec.hxx.

Referenced by Fill(), GetEpoch(), IsHigherPriority(), SetEpoch(), Store(), and Streamer().

TVldTimeStamp TDbiValidityRec::fInsertDate [private]

Insertion date.

Definition at line 122 of file TDbiValidityRec.hxx.

Referenced by Fill(), GetInsertDate(), IsHigherPriority(), Store(), and Streamer().

Bool_t TDbiValidityRec::fIsGap [private]

kTRUE if corresponds to a gap.

Definition at line 125 of file TDbiValidityRec.hxx.

Referenced by Fill(), IsGap(), and Streamer().

UInt_t TDbiValidityRec::fReality [private]

Reality (for possible, but improbable future use).

Definition at line 144 of file TDbiValidityRec.hxx.

Referenced by Fill(), Store(), and Streamer().

Int_t TDbiValidityRec::fSeqNo [private]

Sequence number or 0 if compound.

Definition at line 131 of file TDbiValidityRec.hxx.

Referenced by Fill(), GetSeqNo(), Store(), and Streamer().

const TDbiTableProxy* TDbiValidityRec::fTableProxy [private]

TDbiTableProxy that filled this (if any).

Definition at line 135 of file TDbiValidityRec.hxx.

Referenced by Fill(), GetTableProxy(), SetTableProxy(), and Streamer().

TDbi::Task TDbiValidityRec::fTask [private]

Task number.

Definition at line 128 of file TDbiValidityRec.hxx.

Referenced by Fill(), GetTask(), HasExpired(), IsCompatible(), Store(), and Streamer().

TVldRange TDbiValidityRec::fVldRange [private]

Validity range of record.

Definition at line 138 of file TDbiValidityRec.hxx.

Referenced by AndTimeWindow(), Fill(), GetVldRange(), HasExpired(), IsCompatible(), IsHigherPriority(), SetTimeWindow(), SetVldRange(), Store(), Streamer(), and Trim().

The documentation for this class was generated from the following files:
Generated on 11 Aug 2013 for SKDatabase by  doxygen 1.6.1
