TDemo_DB_Table Class Reference

#include <TDemo_DB_Table.hxx>

Inheritance diagram for TDemo_DB_Table:

Collaboration diagram for TDemo_DB_Table:

Public Member Functions
	TDemo_DB_Table ()
	Required default constructor.
	TDemo_DB_Table (const TDemo_DB_Table &from)
	Required copy constructor.
virtual	~TDemo_DB_Table ()
int	GetChannelId () const
Int_t	GetIParm1 () const
Int_t	GetIParm2 () const
Int_t	GetIParm3 () const
Float_t	GetFParm1 () const
Float_t	GetFParm2 () const
Float_t	GetFParm3 () const
virtual UInt_t	GetIndex (UInt_t defIndex) const
virtual TTableRow *	MakeTableRow () const
	Required method to create new row.
virtual void	Fill (TResultInputStream &ris)
	Required method to fill self from a ResultInputStream.
virtual void	Print (const Option_t *="") const
virtual TDbiTableRow *	CreateTableRow () const
virtual void	Fill (TDbiInRowStream &rs, const TDbiValidityRec *vrec)
const char *	GetName () const
	Return class name but strip off leading "T".
virtual Bool_t	CanL2Cache () const
	Replace this with a function returning true in order to use the level 2 disk cache.
virtual Int_t	GetAggregateNo () const
TDbiResultSet *	GetOwner () const
void	SetOwner (TDbiResultSet *owner)
virtual void	Store (TDbiOutRowStream &, const TDbiValidityRec *) const
Private Attributes
int	fChannelId
	Channel ID.
Int_t	fIParm1
	Integer parameters.
Int_t	fIParm2
Int_t	fIParm3
Float_t	fFParm1
	Floating point parameters.
Float_t	fFParm2
Float_t	fFParm3

Detailed Description

    This is an example TTableRow subclass used to read rows of
    demonstration DEMO_DB_TABLE.  It can be used as the starting point
    for other subclasses.

    For table XXX_YYY (all tables names are upper case) the corresponding TTableRow subclass is

        ND::TXxx_Yyy  (arbitrary capitalisation).

    This is a demonstration table row

Definition at line 21 of file TDemo_DB_Table.hxx.

Constructor & Destructor Documentation

TDemo_DB_Table::TDemo_DB_Table ( )

Required default constructor.

Definition at line 24 of file TDemo_DB_Table.cxx.

References SK_DBI_Trace.

00024                                 {
00025
00026    // Default constructor
00027
00028     SK_DBI_Trace("TDemo_DB_Table: Default ctor at:" << (void*) this);
00029
00030 }

TDemo_DB_Table::TDemo_DB_Table ( const TDemo_DB_Table & from )

Required copy constructor.

Definition at line 35 of file TDemo_DB_Table.cxx.

References SK_DBI_Trace.

00035                                                          {
00036
00037    // Copy constructor
00038
00039     SK_DBI_Trace("TDemo_DB_Table: Copy ctor at:" << (void*) this);
00040
00041     *this = from;
00042
00043 }

TDemo_DB_Table::~TDemo_DB_Table ( ) [virtual]

Definition at line 47 of file TDemo_DB_Table.cxx.

References SK_DBI_Trace.

00047                                  {
00048
00049    // Destructor
00050
00051     SK_DBI_Trace("TDemo_DB_Table: dtor at:" << (void*) this);
00052
00053 }

Member Function Documentation

virtual Bool_t TDbiTableRow::CanL2Cache ( ) const [inline, virtual, inherited]

Replace this with a function returning true in order to use the level 2 disk cache.

Definition at line 59 of file TDbiTableRow.hxx.

00059 { return kFALSE; }

virtual TDbiTableRow* TTableRow::CreateTableRow ( ) const [inline, virtual, inherited]

Implements TDbiTableRow.

Definition at line 25 of file TTableRow.hxx.

References TTableRow::MakeTableRow().

00025 { return this->MakeTableRow();}

Here is the call graph for this function:

virtual void TTableRow::Fill	(	TDbiInRowStream &	rs,
		const TDbiValidityRec *	vrec
	)			`[inline, virtual, inherited]`

Implements TDbiTableRow.

Definition at line 27 of file TTableRow.hxx.

00027                                                                         {
00028         TResultInputStream ris(rs);
00029         this->Fill(ris);
00030     }

void TDemo_DB_Table::Fill ( TResultInputStream & ris ) [virtual]

Required method to fill self from a ResultInputStream.

This method is used to fill a row. A ResultInputStream is an object with operator >> methods for most basic types.

Individual data items are read from it in the order in which they appear in the database table but notice that the first two rows (SEQNO and ROW_COUNTER) which are not part of the row's state, do not have to be skipped.

Also notice how the row state can include objects even though the stored state can only store basic types. E_CHAN_ID is stored as a MySQL INT but is used to fill a TTFBChannelId.

Reimplemented from TTableRow.

Definition at line 57 of file TDemo_DB_Table.cxx.

References fChannelId, fFParm1, fFParm2, fFParm3, fIParm1, fIParm2, and fIParm3.

00057                                                  {
00058
00059 /// This method is used to fill a row.  A ResultInputStream is an object
00060 /// with operator >> methods for most basic types.
00061 ///
00062 /// Individual data items are read from it in the order in which they
00063 /// appear in the database table but notice that the first two rows (SEQNO
00064 /// and ROW_COUNTER) which are not part of the row's state, do not have to
00065 /// be skipped.
00066 ///
00067 /// Also notice how the row state can include objects even though the
00068 /// stored state can only store basic types. E_CHAN_ID is stored as a
00069 /// MySQL INT but is used to fill a TTFBChannelId.
00070
00071
00072   UInt_t id;
00073   ris >> id >> fIParm1 >> fIParm2 >> fIParm3 >> fFParm1 >> fFParm2 >> fFParm3;
00074   fChannelId = id;
00075
00076 }

virtual Int_t TDbiTableRow::GetAggregateNo ( ) const [inline, virtual, inherited]

Reimplemented in TDbiConfigSet, TDbiLogEntry, and TDbiValidityRec.

Definition at line 62 of file TDbiTableRow.hxx.

Referenced by TDbiResultSet::BuildLookUpTable().

00062 { return -1; }

Here is the caller graph for this function:

int TDemo_DB_Table::GetChannelId ( ) const [inline]

Standard Getters (here they just give access to the row's state but could equally well perform services based on that state e.g. apply calibration.)

Definition at line 38 of file TDemo_DB_Table.hxx.

References fChannelId.

00038 { return fChannelId; }

Float_t TDemo_DB_Table::GetFParm1 ( ) const [inline]

Definition at line 42 of file TDemo_DB_Table.hxx.

References fFParm1.

00042 { return fFParm1;}

Float_t TDemo_DB_Table::GetFParm2 ( ) const [inline]

Definition at line 43 of file TDemo_DB_Table.hxx.

References fFParm2.

00043 { return fFParm2;}

Float_t TDemo_DB_Table::GetFParm3 ( ) const [inline]

Definition at line 44 of file TDemo_DB_Table.hxx.

References fFParm3.

00044 { return fFParm3;}

virtual UInt_t TDemo_DB_Table::GetIndex ( UInt_t defIndex ) const [inline, virtual]

Return unique "Natural Index" of row in table. Optional, the default is to return the row position, which is unique but arbitrary.

Reimplemented from TDbiTableRow.

Definition at line 48 of file TDemo_DB_Table.hxx.

References fChannelId.

00048 {return fChannelId;}

Int_t TDemo_DB_Table::GetIParm1 ( ) const [inline]

Definition at line 39 of file TDemo_DB_Table.hxx.

References fIParm1.

00039 { return fIParm1;}

Int_t TDemo_DB_Table::GetIParm2 ( ) const [inline]

Definition at line 40 of file TDemo_DB_Table.hxx.

References fIParm2.

00040 { return fIParm2;}

Int_t TDemo_DB_Table::GetIParm3 ( ) const [inline]

Definition at line 41 of file TDemo_DB_Table.hxx.

References fIParm3.

00041 { return fIParm3;}

const char* TTableRow::GetName ( ) const [inline, inherited]

Return class name but strip off leading "T".

Definition at line 38 of file TTableRow.hxx.

00038                                 {
00039         const char* name = TObject::GetName();
00040         if ( strncmp("",name,4) == 0 ) name += 4;
00041         if ( strncmp("T",   name,1) == 0 ) name += 1;
00042         return name;
00043     }

TDbiResultSet* TDbiTableRow::GetOwner ( ) const [inline, inherited]

Definition at line 63 of file TDbiTableRow.hxx.

References TDbiTableRow::fOwner.

Referenced by TDbiResultSet::BuildLookUpTable(), and TDbiResultSetAgg::GetValidityRec().

00063 { return fOwner; }

Here is the caller graph for this function:

virtual TTableRow* TDemo_DB_Table::MakeTableRow ( ) const [inline, virtual]

Required method to create new row.

Implements TTableRow.

Definition at line 51 of file TDemo_DB_Table.hxx.

00051 {return new TDemo_DB_Table;}

void TDemo_DB_Table::Print ( const Option_t * = "" ) const [virtual]

Definition at line 80 of file TDemo_DB_Table.cxx.

References fChannelId, fFParm1, fFParm2, fFParm3, fIParm1, fIParm2, fIParm3, and SK_DBI_Log.

Referenced by main().

00080                                                 {
00081
00082   // Programming note: The arg isn't used but is there so as to avoid compiler
00083   // warnings about hidden method TObject::Print(const Option_t*).
00084
00085   SK_DBI_Log("DEMO_DB_TABLE row for channel " << fChannelId
00086            << " integer parms: "       << fIParm1 << "," << fIParm2 << "," << fIParm3
00087            << " floating point parms " << fFParm1 << "," << fFParm2 << "," << fFParm3 );
00088
00089 }

Here is the caller graph for this function:

void TDbiTableRow::SetOwner ( TDbiResultSet * owner ) [inline, inherited]

Definition at line 68 of file TDbiTableRow.hxx.

References TDbiTableRow::fOwner.

Referenced by ClassImp().

00068 {fOwner = owner;}

Here is the caller graph for this function:

virtual void TDbiTableRow::Store	(	TDbiOutRowStream &	,
		const TDbiValidityRec *
	)			const `[inline, virtual, inherited]`

Reimplemented in TDbiConfigSet, and TDbiLogEntry.

Definition at line 73 of file TDbiTableRow.hxx.

Referenced by TDbiSqlValPacket::AddRow().

00074                                                               { assert(0); }

Here is the caller graph for this function:

Member Data Documentation

int TDemo_DB_Table::fChannelId [private]

Channel ID.

Definition at line 60 of file TDemo_DB_Table.hxx.

Referenced by Fill(), GetChannelId(), GetIndex(), and Print().

Float_t TDemo_DB_Table::fFParm1 [private]

Floating point parameters.

Definition at line 64 of file TDemo_DB_Table.hxx.

Referenced by Fill(), GetFParm1(), and Print().

Float_t TDemo_DB_Table::fFParm2 [private]

Definition at line 64 of file TDemo_DB_Table.hxx.

Referenced by Fill(), GetFParm2(), and Print().

Float_t TDemo_DB_Table::fFParm3 [private]

Definition at line 64 of file TDemo_DB_Table.hxx.

Referenced by Fill(), GetFParm3(), and Print().

Int_t TDemo_DB_Table::fIParm1 [private]

Integer parameters.

Definition at line 62 of file TDemo_DB_Table.hxx.

Referenced by Fill(), GetIParm1(), and Print().

Int_t TDemo_DB_Table::fIParm2 [private]

Definition at line 62 of file TDemo_DB_Table.hxx.

Referenced by Fill(), GetIParm2(), and Print().

Int_t TDemo_DB_Table::fIParm3 [private]

Definition at line 62 of file TDemo_DB_Table.hxx.

Referenced by Fill(), GetIParm3(), and Print().

The documentation for this class was generated from the following files:

src/TDemo_DB_Table.hxx
src/TDemo_DB_Table.cxx
