TDbiConfigSet Class Reference

Concept A concrete data type corresponding to a single row in a database table of configuration data. More...

#include <TDbiConfigSet.hxx>

Inheritance diagram for TDbiConfigSet:
Inheritance graph
[legend]
Collaboration diagram for TDbiConfigSet:
Collaboration graph
[legend]

List of all members.

Classes

struct  Param
 Internal structure used by TDbiCfgDialog to store Name/Value/Type triplets. More...

Public Member Functions

virtual ~TDbiConfigSet ()
virtual TDbiTableRow * CreateTableRow () const
Int_t GetAggregateNo () const
UInt_t GetNumParams () const
string GetParamName (UInt_t parNo) const
TDbiFieldType GetParamType (UInt_t parNo) const
string GetParamValue (UInt_t parNo) const
void Clear (const Option_t *="")
void PushBack (const string &name, const string &value, const TDbiFieldType &type)
 Purpose: Add another entry to the end of the existing row.
void SetAggregateNo (Int_t aggNo)
virtual void Fill (TDbiInRowStream &rs, const TDbiValidityRec *vrec)
virtual void Store (TDbiOutRowStream &ors, const TDbiValidityRec *vrec) const
virtual Bool_t CanL2Cache () const
 Replace this with a function returning true in order to use the level 2 disk cache.
TDbiResultSet * GetOwner () const
virtual UInt_t GetIndex (UInt_t defIndex) const
void SetOwner (TDbiResultSet *owner)

Private Attributes

vector< Param * > fParams
Int_t fAggregateNo

Detailed Description

Concept A concrete data type corresponding to a single row in a database table of configuration data.

Id
TDbiConfigSet.hxx,v 1.1 2011/01/18 05:49:19 finch Exp

Purpose Table row proxy for all Config data. Contact: A.Finch@lancaster.ac.uk

Definition at line 44 of file TDbiConfigSet.hxx.

Constructor & Destructor Documentation

TDbiConfigSet::~TDbiConfigSet (  )  [virtual]

Definition at line 36 of file TDbiConfigSet.cxx.

References fParams.

00036                               {
00037 //
00038 //
00039 //  Purpose:  Destructor
00040
00041
00042   for ( vector<Param*>::iterator itr = fParams.begin();
00043         itr != fParams.end();
00044         ++itr ) delete (*itr);
00045
00046 }

Member Function Documentation

virtual Bool_t TDbiTableRow::CanL2Cache (  )  const [inline, virtual, inherited]

Replace this with a function returning true in order to use the level 2 disk cache.

Definition at line 59 of file TDbiTableRow.hxx.

00059 { return kFALSE; }

void TDbiConfigSet::Clear ( const Option_t *  = ""  )  [inline]

Definition at line 63 of file TDbiConfigSet.hxx.

References fParams.

Referenced by TDbiConfigStream::operator<<().

00063 { fParams.clear(); }

Here is the caller graph for this function:

virtual TDbiTableRow* TDbiConfigSet::CreateTableRow (  )  const [inline, virtual]

Implements TDbiTableRow.

Definition at line 54 of file TDbiConfigSet.hxx.

00054                                                {
00055                                               return new TDbiConfigSet; }

void TDbiConfigSet::Fill ( TDbiInRowStream &  rs,
const TDbiValidityRec *  vrec
) [virtual]

     Purpose:  Fill object from Result Set

     Arguments:
       rs           in    Result Set used to fill object
       vrec         in    Associated validity record (or 0 if filling
                                                       TDbiValidityRec)

     Return:

     Contact:   N. West

     Specification:-
     =============

     o Fill object from current (and only) row of Result Set.

Implements TDbiTableRow.

Definition at line 107 of file TDbiConfigSet.cxx.

References TDbiRowStream::CurColFieldType(), TDbiRowStream::CurColName(), TDbiInRowStream::CurColValue(), fAggregateNo, fParams, TDbiValidityRec::GetAggregateNo(), TDbiRowStream::IncrementCurCol(), TDbiConfigSet::Param::Name, TDbiRowStream::NumCols(), TDbiConfigSet::Param::Type, and TDbiConfigSet::Param::Value.

00108                                                      {
00109
00110 //  Program Notes:-
00111 //  =============
00112
00113 //  None.
00114
00115
00116 // Don't count leading SeqNo or ROW_COUNTER, they have already been skipped.
00117   UInt_t numParams = rs.NumCols()-2;
00118
00119   for (UInt_t iParam = 0; iParam < numParams; ++iParam ) {
00120     Param* par = new Param;
00121     par->Name  = rs.CurColName();
00122     par->Value = rs.CurColValue();
00123     par->Type  = rs.CurColFieldType();
00124
00125    fParams.push_back(par);
00126     rs.IncrementCurCol();
00127   }
00128
00129   fAggregateNo =  vrec->GetAggregateNo ();
00130
00131 }

Here is the call graph for this function:

Int_t TDbiConfigSet::GetAggregateNo (  )  const [inline, virtual]

Reimplemented from TDbiTableRow.

Definition at line 56 of file TDbiConfigSet.hxx.

References fAggregateNo.

00056 { return fAggregateNo; }

virtual UInt_t TDbiTableRow::GetIndex ( UInt_t  defIndex  )  const [inline, virtual, inherited]

Reimplemented in TDemo2_DB_Table, and TDemo_DB_Table.

Definition at line 65 of file TDbiTableRow.hxx.

Referenced by TDbiResultSet::BuildLookUpTable().

00065 {return defIndex;}

Here is the caller graph for this function:

UInt_t TDbiConfigSet::GetNumParams (  )  const [inline]

Definition at line 57 of file TDbiConfigSet.hxx.

References fParams.

Referenced by GetParamName(), GetParamType(), GetParamValue(), operator<<(), and TDbiConfigStream::operator>>().

00057 { return fParams.size(); }

Here is the caller graph for this function:

TDbiResultSet* TDbiTableRow::GetOwner (  )  const [inline, inherited]

Definition at line 63 of file TDbiTableRow.hxx.

References TDbiTableRow::fOwner.

Referenced by TDbiResultSet::BuildLookUpTable(), and TDbiResultSetAgg::GetValidityRec().

00063 { return fOwner; }

Here is the caller graph for this function:

string TDbiConfigSet::GetParamName ( UInt_t  parNo  )  const

     Purpose:  Get the name of selected parameter.

     Arguments:
       parNo        in    parNo (in range 0..GetNumParams())

     Return:    The name of selected parameter
                 or "" if parNo out of range.

     Contact:   N. West

     Specification:-
     =============

     o Get the name of selected parameter  or "" if parNo out of range.

Definition at line 150 of file TDbiConfigSet.cxx.

References fParams, and GetNumParams().

Referenced by operator<<(), and TDbiConfigStream::operator>>().

00150                                                      {
00151
00152
00153 //  Program Notes:-
00154 //  =============
00155
00156 //  None.
00157
00158  return ( parNo <= GetNumParams() ) ?
00159    fParams[parNo]->Name : "";
00160
00161 }

Here is the call graph for this function:

Here is the caller graph for this function:

TDbiFieldType TDbiConfigSet::GetParamType ( UInt_t  parNo  )  const

Definition at line 164 of file TDbiConfigSet.cxx.

References fParams, GetNumParams(), and TDbi::kUnknown.

Referenced by operator<<().

00164                                                             {
00165 //
00166 //
00167 //  Purpose:  Get the type of selected parameter.
00168 //
00169 //  Arguments:
00170 //    parNo        in    parNo (in range 0..GetNumParams())
00171 //
00172 //  Return:    The type of selected parameter
00173 //              or TDbi::kUnknown if parNo out of range.
00174 //
00175 //  Contact:   N. West
00176 //
00177 //  Specification:-
00178 //  =============
00179 //
00180 //  o Get the type of selected parameter  or TDbi::kUnknown if
00181 //    parNo out of range.
00182
00183 //  Program Notes:-
00184 //  =============
00185
00186 //  None.
00187
00188  return ( parNo <= GetNumParams() ) ?
00189    fParams[parNo]->Type : TDbiFieldType(TDbi::kUnknown);
00190
00191 }

Here is the call graph for this function:

Here is the caller graph for this function:

string TDbiConfigSet::GetParamValue ( UInt_t  parNo  )  const
     Purpose:  Get the value of selected parameter.

     Arguments:
       parNo        in    parNo (in range 0..GetNumParams())

     Return:    The value of selected parameter
                 or "" if parNo out of range.

     Contact:   N. West

     Specification:-
     =============

     o Get the value of selected parameter  or "" if parNo out of range.

Definition at line 209 of file TDbiConfigSet.cxx.

References fParams, and GetNumParams().

Referenced by operator<<(), and TDbiConfigStream::operator>>().

00209                                                       {
00210
00211 //  Program Notes:-
00212 //  =============
00213
00214 //  None.
00215
00216  return ( parNo <= GetNumParams() ) ?
00217    fParams[parNo]->Value : "";
00218
00219 }

Here is the call graph for this function:

Here is the caller graph for this function:

void TDbiConfigSet::PushBack ( const string &  name,
const string &  value,
const TDbiFieldType &  type
)

Purpose: Add another entry to the end of the existing row.

Definition at line 223 of file TDbiConfigSet.cxx.

References fParams.

Referenced by TDbiConfigStream::operator<<().

00225                                                        {
00226 //
00227 //
00228
00229   fParams.push_back(new Param(name,value,type));
00230 }

Here is the caller graph for this function:

void TDbiConfigSet::SetAggregateNo ( Int_t  aggNo  )  [inline]

Definition at line 67 of file TDbiConfigSet.hxx.

References fAggregateNo.

Referenced by TDbiConfigStream::operator<<(), and TDbiConfigStream::Write().

00067 { fAggregateNo = aggNo; }

Here is the caller graph for this function:

void TDbiTableRow::SetOwner ( TDbiResultSet *  owner  )  [inline, inherited]

Definition at line 68 of file TDbiTableRow.hxx.

References TDbiTableRow::fOwner.

Referenced by ClassImp().

00068 {fOwner = owner;}

Here is the caller graph for this function:

void TDbiConfigSet::Store ( TDbiOutRowStream &  ors,
const TDbiValidityRec *  vrec
) const [virtual]
     Purpose:  Stream object to output row stream

     Arguments:
       ors          in    Output row stream.
       vrec         in    =0.  If filling other table rows it points
                          to the associated validity record.

     Return:

     Contact:   N. West

     Specification:-
     =============

     o  Stream object to output row stream.

     Program Notes:-
     =============

     This method sneaks round the back of the TDbiRowStream interface
     and directly uses the private Store method as the data is already
     in string form.  Its all in a good cause because this allows
     TDbiConfigSet to output data from any type of table.

Reimplemented from TDbiTableRow.

Definition at line 259 of file TDbiConfigSet.cxx.

References fParams, and TDbiOutRowStream::Store().

00260                                                                   {
00261
00262   for ( vector<Param*>::const_iterator itr = fParams.begin();
00263         itr != fParams.end();
00264         ++itr ) ors.Store((*itr)->Value.c_str());
00265
00266 }

Here is the call graph for this function:

Member Data Documentation

Int_t TDbiConfigSet::fAggregateNo [private]

Aggregate number or:- -1 Non-aggregated data or multiple aggregates -2 undefined aggregates

Definition at line 104 of file TDbiConfigSet.hxx.

Referenced by Fill(), GetAggregateNo(), and SetAggregateNo().

vector<Param*> TDbiConfigSet::fParams [private]

Definition at line 99 of file TDbiConfigSet.hxx.

Referenced by Clear(), Fill(), GetNumParams(), GetParamName(), GetParamType(), GetParamValue(), PushBack(), Store(), and ~TDbiConfigSet().

The documentation for this class was generated from the following files:
