TDbiDBProxy Class Reference

Concept Object to query a specific database table. More...

#include <TDbiDBProxy.hxx>

Collaboration diagram for TDbiDBProxy:

[legend]

List of all members.

Public Types
typedef const std::vector< UInt_t >	SeqList_t
Public Member Functions
	TDbiDBProxy (TDbiCascader &cascader, const string &tableName, const TDbiTableMetaData *metaData, const TDbiTableMetaData *metaValid, const TDbiTableProxy *tableProxy)
virtual	~TDbiDBProxy ()
Bool_t	HasEpoch () const
UInt_t	GetNumDb () const
const string &	GetTableName () const
const TDbiTableProxy *	GetTableProxy () const
void	StoreMetaData (TDbiTableMetaData &metaData) const
Bool_t	TableExists (Int_t selectDbNo=-1) const
void	FindTimeBoundaries (const TVldContext &vc, const TDbi::Task &task, UInt_t dbNo, const TDbiValidityRec &lowestPriorityVrec, Bool_t resolveByCreationDate, TVldTimeStamp &start, TVldTimeStamp &end) const
TDbiInRowStream *	QueryAllValidities (UInt_t dbNo, UInt_t seqNo=0) const
TDbiInRowStream *	QuerySeqNo (UInt_t seqNo, UInt_t dbNo) const
TDbiInRowStream *	QuerySeqNos (SeqList_t &seqNos, UInt_t dbNo, const string &sqlData="", const string &fillOpts="") const
	Secondary query for aggregate and extended context queries.
TDbiInRowStream *	QueryValidity (const TVldContext &vc, const TDbi::Task &task, UInt_t dbNo) const
TDbiInRowStream *	QueryValidity (const string &context, const TDbi::Task &task, UInt_t dbNo) const
TDbiInRowStream *	QueryValidity (UInt_t seqNo, UInt_t dbNo) const
Bool_t	ReplaceInsertDate (const TVldTimeStamp &ts, UInt_t SeqNo, UInt_t dbNo) const
Bool_t	RemoveSeqNo (UInt_t seqNo, UInt_t dbNo) const
Bool_t	ReplaceSeqNo (UInt_t oldSeqNo, UInt_t newSeqNo, UInt_t dbNo) const
void	SetSqlCondition (const string &sql)
Private Member Functions
	TDbiDBProxy (const TDbiDBProxy &)
TDbiDBProxy &	operator= (const TDbiDBProxy &)
Private Attributes
TDbiCascader &	fCascader
	Reference to one and only cascader.
const TDbiTableMetaData *	fMetaData
	Owned by TDbiTableProxy.
const TDbiTableMetaData *	fMetaValid
	Owned by TDbiTableProxy.
string	fSqlCondition
string	fTableName
	Table Name.
const TDbiTableProxy *	fTableProxy
	Owning TDbiTableProxy.

---

Detailed Description

Concept Object to query a specific database table.

Id

TDbiDBProxy.hxx,v 1.1 2011/01/18 05:49:19 finch Exp

Purpose To encapsulate the standard context query and the management of SEQNOs and meta-data. This allows clients to execute queries without specifying SQL. TDbiDBProxy also supports "Extended Context" queries which provides a framework in which clients can extended the basic query and can use SQL to fine tune their requests. Uage Notes The object can be "programmed" with an SQL condition using SetSqlCondition. If not null the string is prefixed with "where" and used when responding to the following validity queries:- QueryAllValidities QueryValidity Contact: A.Finch@lancaster.ac.uk

Definition at line 52 of file TDbiDBProxy.hxx.

---

Member Typedef Documentation

typedef const std::vector<UInt_t> TDbiDBProxy::SeqList_t

Definition at line 58 of file TDbiDBProxy.hxx.

---

Constructor & Destructor Documentation

TDbiDBProxy::TDbiDBProxy	(	TDbiCascader &	cascader,
		const string &	tableName,
		const TDbiTableMetaData *	metaData,
		const TDbiTableMetaData *	metaValid,
		const TDbiTableProxy *	tableProxy
	)

TDbiDBProxy::~TDbiDBProxy

(

)

[virtual]

Definition at line 82 of file TDbiDBProxy.cxx.

References fTableName, and SK_DBI_Trace.

                          {
//
//
//  Purpose: Destructor


  SK_DBI_Trace( "Destroying TDbiDBProxy "
                          << fTableName << " at " << this
                          << "  ");

}

TDbiDBProxy::TDbiDBProxy

(

const TDbiDBProxy &

)

[private]

---

Member Function Documentation

void TDbiDBProxy::FindTimeBoundaries	(	const TVldContext &	vc,
		const TDbi::Task &	task,
		UInt_t	dbNo,
		const TDbiValidityRec &	lowestPriorityVrec,
		Bool_t	resolveByCreationDate,
		TVldTimeStamp &	start,
		TVldTimeStamp &	end
	)			const

Definition at line 95 of file TDbiDBProxy.cxx.

References TDbiString::c_str(), TDbiCascader::CreateStatement(), fCascader, fTableName, TDbiValidityRec::GetCreationDate(), TVldContext::GetDetector(), TDbiValidityRec::GetEpoch(), TVldTimeStamp::GetSec(), TVldContext::GetSimFlag(), GetTableName(), TDbi::GetTimeGate(), TVldContext::GetTimeStamp(), TDbi::MakeDateTimeString(), TDbi::MakeTimeStamp(), and SK_DBI_Verbose.

                                                              {
//
//
//  Purpose: Find next time boundaries beyond standard time gate.
//
//  Arguments:
//    vc                    in    The Validity Context for the query.
//    task                  in    The task of the query.
//    dbNo                  in    Database number in cascade (starting at 0).
//    lowestPriorityVrec    in    Lowest priority VLD in the time gate
//    resolveByCreationDate in  The method for resolving VLDs:
//                                 if true use CREATIONDATE (MINOS scheme)
//                                 if false use EPOCH,TIMESTART,INSERTDATE (T2K scheme)
//    start                 out   Lower time boundary or TVldTimeStamp(0,0) if none
//    end                   out   Upper time boundary or TVldTimeStamp(0x7FFFFFFF,0) if none
//
//  Specification:-
//  =============
//
//  o Find the next time boundary (either TIMESTART or TIMEEND)
//    outside the current time gate that is potentionally of higher priority.
//
//  Explanation:-
//  ===========
//
//
//  In oder to keep the number of VLDs to a manageable level when doing a
//  Standard Context query, a time gate around the context is imposed and
//  any VLD rejected if it does not overlap the query. However, this
//  implies that the maximum validity of the query result set is also
//  limited by the time gate and hence the interface will again have to
//  query the database when a context outside the time gate is
//  requested. This function attempts to open up the validity of the
//  result set by looking for the nearest start or end of a VLD outside
//  the time gate that is of higher priority. In MINOS, priority is just
//  CREATIONDATE, so the function just looks for VLDs with a higher
//  CREATIONDATE.  For T2K the priority scheme is more complicated:
//  EPOCH,TIMESTART,INSERTDATE and it is not possible to construct a SQL
//  query that only considers higher priority VLDs so the function makes a
//  simplification and only rejects VLDs with a lower EPOCH number.  The
//  consequence of this is that it may accept VLDs that are of a lower
//  priority than the current one and hence the result set validity does
//  not get opened up to its full extent.  All this means is that the
//  interface will have to make another query earlier that it need do but
//  at least it will not miss a VLD boundary and should still keep the current
//  results longer than it would have if this function had not been
//  called.

  SK_DBI_Verbose( "FindTimeBoundaries for table " <<  fTableName
                            << " context " << vc
                            << " task " << task
                            << " Lowest priority VLD creation date: " <<  lowestPriorityVrec.GetCreationDate()
                            << " and EPOCH: " << lowestPriorityVrec.GetEpoch()
                            << " resolve by: " << ( resolveByCreationDate ? "CREATIONDATE" : "EPOCH")
                            << " database " << dbNo << "  ");

//  Set the limits wide open
  start = TVldTimeStamp(0,0);
  end   = TVldTimeStamp(0x7FFFFFFF,0);

//  Construct a Time Gate on the current date.

  const TVldTimeStamp curVTS = vc.GetTimeStamp();
  Int_t timeGate = TDbi::GetTimeGate(this->GetTableName());
  time_t vcSec = curVTS.GetSec() - timeGate;
  TVldTimeStamp startGate(vcSec,0);
  vcSec += 2*timeGate;
  TVldTimeStamp endGate(vcSec,0);
  string startGateString(TDbi::MakeDateTimeString(startGate));
  string endGateString(TDbi::MakeDateTimeString(endGate));

// Extract information for TVldContext.

  DbiDetector::Detector_t    detType(vc.GetDetector());
  DbiSimFlag::SimFlag_t       simFlg(vc.GetSimFlag());

// Use an auto_ptr to manage ownership of TDbiStatement and TSQLStatement
  auto_ptr<TDbiStatement> stmtDb(fCascader.CreateStatement(dbNo));

  for (int i_limit =1; i_limit <= 4; ++i_limit ) {
    TDbiString sql("select ");
    if ( i_limit == 1 ) sql  << "min(TIMESTART) from " << fTableName
                             << "VLD where TIMESTART > '" << endGateString << "' ";
    if ( i_limit == 2 ) sql  << "min(TIMEEND) from " << fTableName
                             << "VLD where TIMEEND > '" << endGateString  << "' ";
    if ( i_limit == 3 ) sql  << "max(TIMESTART) from " << fTableName
                             << "VLD where TIMESTART < '" << startGateString << "' ";
    if ( i_limit == 4 ) sql  << "max(TIMEEND) from " << fTableName
                             << "VLD where TIMEEND < '" << startGateString  << "' ";
    sql << " and DetectorMask & " << static_cast<unsigned int>(detType)
        << " and SimMask & " << static_cast<unsigned int>(simFlg)
        << " and  Task = " << task;
    if ( resolveByCreationDate )
         sql << " and CREATIONDATE >= '" << TDbi::MakeDateTimeString(lowestPriorityVrec.GetCreationDate()) << "'";
    else sql << " and EPOCH >= " << lowestPriorityVrec.GetEpoch();
    SK_DBI_Verbose( "  FindTimeBoundaries query no. " << i_limit
                          << " SQL:" <<sql.c_str() << "  ");

    auto_ptr<TSQLStatement> stmt(stmtDb->ExecuteQuery(sql.c_str()));


//  If the query returns data, convert to a time stamp and trim the limits
    TString date;
    if ( ! stmt.get() || ! stmt->NextResultRow() || stmt->IsNull(0) ) continue;
    date = stmt->GetString(0);
    if ( date.IsNull() ) continue;
    TVldTimeStamp ts(TDbi::MakeTimeStamp(date.Data()));
    SK_DBI_Verbose( "  FindTimeBoundaries query result: " << ts << "  ");
    if ( i_limit <= 2 && ts < end   ) end   = ts;
    if ( i_limit >= 3 && ts > start ) start = ts;

  }

  SK_DBI_Verbose( "FindTimeBoundaries for table " <<  fTableName
                        << " found " << start << " .. " << end << "  ");

}

Here is the call graph for this function:

UInt_t TDbiDBProxy::GetNumDb

(

)

const

Definition at line 220 of file TDbiDBProxy.cxx.

References fCascader, and TDbiCascader::GetNumDb().

Referenced by TDbiValidityRecBuilder::TDbiValidityRecBuilder().

                                   {
//
//
//  Purpose:  Return the number of databases in the cascade.

  return fCascader.GetNumDb();

}

Here is the call graph for this function:

Here is the caller graph for this function:

const string& TDbiDBProxy::GetTableName

(

)

const [inline]

Definition at line 72 of file TDbiDBProxy.hxx.

References fTableName.

Referenced by FindTimeBoundaries(), QueryValidity(), and TDbiValidityRecBuilder::TDbiValidityRecBuilder().

{ return fTableName; }

Here is the caller graph for this function:

const TDbiTableProxy* TDbiDBProxy::GetTableProxy

(

)

const [inline]

Definition at line 73 of file TDbiDBProxy.hxx.

References fTableProxy.

{ return fTableProxy; }

Bool_t TDbiDBProxy::HasEpoch

(

)

const

Definition at line 230 of file TDbiDBProxy.cxx.

References fMetaValid, and TDbiTableMetaData::HasEpoch().

Referenced by QueryValidity().

                                   {
  return fMetaValid->HasEpoch();
}

Here is the call graph for this function:

Here is the caller graph for this function:

TDbiDBProxy& TDbiDBProxy::operator=

(

const TDbiDBProxy &

)

[private]

TDbiInRowStream * TDbiDBProxy::QueryAllValidities	(	UInt_t	dbNo,
		UInt_t	seqNo = 0
	)			const

Definition at line 235 of file TDbiDBProxy.cxx.

References TDbiCascader::CreateStatement(), fCascader, fMetaValid, fSqlCondition, fTableName, fTableProxy, TDbiString::GetString(), and SK_DBI_Verbose.

Referenced by ClassImp().

                                                                                 {
//
//
//  Purpose:  Apply all validities query to database..
//
//  Arguments:
//    dbNo         in    Database number in cascade (starting at 0).
//    seqNo        in    Just this SEQNO if >0 or all if 0 [default: 0]
//
//  Return:    New TDbiResultSet object.
//             NB  Caller is responsible for deleting..
//
//  Contact:   N. West
//
//  Specification:-
//  =============
//
//  o Ask for every row in associated validity range table and return
//    query results qualifying selection by fSqlCondition if defined.

//  Program Notes:-
//  =============

//  This function is provided to support database maintenance
//  rather than standard TDbi related I/O


// Generate SQL for validity table.

  TDbiString sql;

  sql << "select * from " << fTableName << "VLD";
  if ( fSqlCondition != "" ) sql << " where " << fSqlCondition;
  if ( seqNo > 0 ) {
    if ( fSqlCondition == "" ) sql << " where ";
    else                       sql << " and ";
    sql << "seqno = " << seqNo;
  }
  sql  << ";" << '\0';

  SK_DBI_Verbose( "Database: " << dbNo
                         << " query: " << sql.GetString() << "  ");

//  Apply query and return result..

  TDbiStatement* stmtDb = fCascader.CreateStatement(dbNo);
  return new TDbiInRowStream(stmtDb,sql,fMetaValid,fTableProxy,dbNo);

}

Here is the call graph for this function:

Here is the caller graph for this function:

TDbiInRowStream * TDbiDBProxy::QuerySeqNo	(	UInt_t	seqNo,
		UInt_t	dbNo
	)			const

Definition at line 289 of file TDbiDBProxy.cxx.

References TDbiString::c_str(), TDbiCascader::CreateStatement(), fCascader, fMetaData, fTableName, fTableProxy, TDbiTimerManager::gTimerManager, TDbiServices::OrderContextQuery(), TDbiTimerManager::RecMainQuery(), and SK_DBI_Verbose.

Referenced by fCreationDate(), and TDbiTableProxy::Query().

                                                                         {
//
//
//  Purpose:  Apply sequence query to database..
//
//  Arguments:
//    seqNo        in    The sequence number for the query.
//    dbNo         in    Database number in cascade (starting at 0).
//
//  Return:    New TDbiResultSet object.
//             NB  Caller is responsible for deleting..
//
//  Contact:   N. West
//
//  Specification:-
//  =============
//
//  o Apply sequence query to table and return query results

//  Program Notes:-
//  =============

//  None..

// Generate SQL.

  TDbiTimerManager::gTimerManager.RecMainQuery();
  TDbiString sql;
  sql << "select * from " << fTableName << " where "
      << "    SEQNO= " << seqNo;

  if ( TDbiServices::OrderContextQuery() ) sql << " order by ROW_COUNTER";

  SK_DBI_Verbose( "Database: " << dbNo
                         << " SeqNo query: " << sql.c_str() << "  ");

//  Apply query and return result..

  TDbiStatement* stmtDb = fCascader.CreateStatement(dbNo);
  return new TDbiInRowStream(stmtDb,sql,fMetaData,fTableProxy,dbNo);

}

Here is the call graph for this function:

Here is the caller graph for this function:

TDbiInRowStream * TDbiDBProxy::QuerySeqNos	(	SeqList_t &	seqNos,
		UInt_t	dbNo,
		const string &	sqlData = "",
		const string &	fillOpts = ""
	)			const

Secondary query for aggregate and extended context queries.

Definition at line 334 of file TDbiDBProxy.cxx.

References TDbiString::c_str(), TDbiCascader::CreateStatement(), fCascader, fMetaData, fTableName, fTableProxy, TDbiTimerManager::gTimerManager, TDbiServices::OrderContextQuery(), TDbiTimerManager::RecMainQuery(), and SK_DBI_Verbose.

                                                                     {
//
//
//  Purpose:  Apply query for a list of sequence numbers to database..
//
//  Arguments:
//    seqNos       in    The vector of sequence numbers for the query.
//                       Should be in acsending order, see Program Notes
//    dbNo         in    Database number in cascade (starting at 0).
//    sqlData      in    Optional SQL extension to secondary query.
//    fillOpts     in    Optional fill options (available to TDbiTableRow
//                       objects when filling.
//
//  Return:    New TDbiResultSet object.
//             NB  Caller is responsible for deleting..
//
//  Contact:   N. West
//
//  Specification:-
//  =============
//
//  o Apply sequence query to table and return query results

//  Program Notes:-
//  =============

//  Where possible the SQL query is kept to a minimm by using
//  `BETWEEN' comparison to bracket ranges of numbers.

// Generate SQL.

  if ( seqNos.size() == 0 ) return 0;

  TDbiTimerManager::gTimerManager.RecMainQuery();
  TDbiString sql;
  sql << "select * from " << fTableName << " where ";

  if ( sqlData != "" ) sql << "( ";
  Bool_t first = kTRUE;
  SeqList_t::const_iterator itr1 = seqNos.begin();

  while ( itr1 != seqNos.end() ) {
    UInt_t seq1 = *itr1;
    UInt_t seq2 = seq1;
    SeqList_t::const_iterator itr2 = itr1;
    while ( itr2 != seqNos.end() && seq2 == *itr2 ) {
      ++itr2;
      ++seq2;
    }
    if ( first ) {
      first = kFALSE;
    }
    else {
      sql << "or ";
    }
    if ( seq2 > seq1 + 1) {
      sql << "SEQNO between " << seq1 << " and " << seq2-1 << ' ';
      itr1 = itr2;
    }
    else {
      sql << "SEQNO = " << seq1 << ' ';
      ++itr1;
    }
  }

  if ( sqlData != "" ) sql << ")  and " << "(" << sqlData << ")" << " ";

  sql << "order by SEQNO";

  if ( TDbiServices::OrderContextQuery() ) sql << ",ROW_COUNTER";

  SK_DBI_Verbose( "Database: " << dbNo
                         << " SeqNos query: " << sql.c_str() << "  ");

//  Apply query and return result..

  TDbiStatement* stmtDb = fCascader.CreateStatement(dbNo);
  return new TDbiInRowStream(stmtDb,sql,fMetaData,fTableProxy,dbNo,fillOpts);

}

Here is the call graph for this function:

TDbiInRowStream * TDbiDBProxy::QueryValidity	(	UInt_t	seqNo,
		UInt_t	dbNo
	)			const

Definition at line 535 of file TDbiDBProxy.cxx.

References TDbiString::c_str(), TDbiCascader::CreateStatement(), fCascader, fMetaValid, fSqlCondition, fTableName, fTableProxy, and SK_DBI_Verbose.

                                                             {
//
//
//  Purpose:  Apply validity query to database..
//
//  Arguments:
//    seqNo        in    The SEQNO of the validity rec.
//
//  Return:    New TDbiResultSet object.
//             NB  Caller is responsible for deleting..
//
//  Contact:   N. West
//
//  Specification:-
//  =============
//
//  o Apply query to associated validity range table and return query
//    results qualifying selection by fSqlCondition if defined.


// Generate SQL for validity table.

  TDbiString sql;
  sql << "select * from " << fTableName << "VLD where ";
  if ( fSqlCondition != "" ) sql << fSqlCondition << " and ";
  sql << "SEQNO = " << seqNo << ";";

  SK_DBI_Verbose( "Database: " << dbNo
                         << " SEQNO query: " << sql.c_str() << "  ");

//  Apply query and return result..

  TDbiStatement* stmtDb = fCascader.CreateStatement(dbNo);
  return new TDbiInRowStream(stmtDb,sql,fMetaValid,fTableProxy,dbNo);

}

Here is the call graph for this function:

TDbiInRowStream * TDbiDBProxy::QueryValidity	(	const string &	context,
		const TDbi::Task &	task,
		UInt_t	dbNo
	)			const

Definition at line 482 of file TDbiDBProxy.cxx.

References TDbiString::c_str(), TDbiCascader::CreateStatement(), fCascader, fMetaValid, fSqlCondition, fTableName, fTableProxy, HasEpoch(), TDbi::kAnyTask, and SK_DBI_Verbose.

                                                             {
//
//
//  Purpose:  Apply validity query to database..
//
//  Arguments:
//    context      in    The Validity Context (see TDbiSqlContext)
//    task         in    The task of the query.
//    dbNo         in    Database number in cascade (starting at 0).
//
//  Return:    New TDbiResultSet object.
//             NB  Caller is responsible for deleting..
//
//  Contact:   N. West
//
//  Specification:-
//  =============
//
//  o Apply query to associated validity range table and return query
//    results qualifying selection by fSqlCondition if defined.


// Generate SQL for validity table.

  TDbiString sql;

// In the MINOS  scheme queries are  ordered by creation date (the later the better)
// but if the table has an EPOCH column then the T2K scheme is used (EPOCH,TIMESTART,INSERTDATE)

  string orderByName("CREATIONDATE desc");
  if ( this->HasEpoch() ) orderByName = "EPOCH desc,TIMESTART desc,INSERTDATE desc";
  sql << "select * from " << fTableName << "VLD"
      << " where " ;
  if ( fSqlCondition != ""
      ) sql << fSqlCondition << " and ";
  sql << context;
  if ( task != TDbi::kAnyTask
       ) sql << " and  Task = " << task
             << " order by " << orderByName << ";" << '\0';

  SK_DBI_Verbose( "Database: " << dbNo
                         << " query: " << sql.c_str() << "  ");

//  Apply query and return result..

  TDbiStatement* stmtDb = fCascader.CreateStatement(dbNo);
  return new TDbiInRowStream(stmtDb,sql,fMetaValid,fTableProxy,dbNo);

}

Here is the call graph for this function:

TDbiInRowStream * TDbiDBProxy::QueryValidity	(	const TVldContext &	vc,
		const TDbi::Task &	task,
		UInt_t	dbNo
	)			const

Definition at line 420 of file TDbiDBProxy.cxx.

References TVldContext::GetDetector(), TVldTimeStamp::GetSec(), TVldContext::GetSimFlag(), GetTableName(), TDbi::GetTimeGate(), TVldContext::GetTimeStamp(), and TDbi::MakeDateTimeString().

Referenced by TDbiTableProxy::Query(), and TDbiValidityRecBuilder::TDbiValidityRecBuilder().

                                                             {
//
//
//  Purpose:  Apply validity query to database..
//
//  Arguments:
//    vc           in    The Validity Context for the query.
//    task         in    The task of the query.
//    dbNo         in    Database number in cascade (starting at 0).
//
//  Return:    New TDbiResultSet object.
//             NB  Caller is responsible for deleting..
//
//  Contact:   N. West
//
//  Specification:-
//  =============
//
//  o Apply query to associated validity range table and return query
//    results qualifying selection by fSqlCondition if defined.

//  Program Notes:-
//  =============

//  Rather than search over the full table this function places
//  a time gate round the context time and then trims any validity
//  range returned to this gate.  See FindTimeBoundaries to get a
//  more accurate validity range.

//  Construct a search window on the current date.

  const TVldTimeStamp curVTS = vc.GetTimeStamp();
  Int_t timeGate = TDbi::GetTimeGate(this->GetTableName());
  time_t vcSec = curVTS.GetSec() - timeGate;
  TVldTimeStamp startGate(vcSec,0);
  vcSec += 2*timeGate;
  TVldTimeStamp endGate(vcSec,0);

// Extract information for TVldContext.

  string startGateString(TDbi::MakeDateTimeString(startGate));
  string endGateString(TDbi::MakeDateTimeString(endGate));
  DbiDetector::Detector_t    detType(vc.GetDetector());
  DbiSimFlag::SimFlag_t       simFlg(vc.GetSimFlag());

// Generate SQL for context.

  TDbiString context;
  context << "    TimeStart <= '" << endGateString << "' "
          << "and TimeEnd    > '" << startGateString << "' "
          << "and DetectorMask & " << static_cast<unsigned int>(detType)
          << " and SimMask & " << static_cast<unsigned int>(simFlg);

//  Apply query and return result..

  return this->QueryValidity(context.GetString(),task,dbNo);

}

Here is the call graph for this function:

Here is the caller graph for this function:

Bool_t TDbiDBProxy::RemoveSeqNo	(	UInt_t	seqNo,
		UInt_t	dbNo
	)			const

Definition at line 575 of file TDbiDBProxy.cxx.

References TDbiString::c_str(), TDbiCascader::CreateStatement(), fCascader, fTableName, TDbiString::GetString(), SK_DBI_Severe, and SK_DBI_Verbose.

Referenced by TDbiSqlValPacket::Store().

                                                  {
//
//
//  Purpose:  Remove sequence number in main and auxiliary tables.
//
//  Arguments:
//    seqNo        in    The sequence number to be removed.
//    dbNo         in    Database number in cascade (starting at 0).
//
//  Return:    kTRUE if output successful,otherwise kFALSE.
//
//  Contact:   N. West
//
//  Specification:-
//  =============
//
//  o Remove sequence number in main and auxiliary tables.

//  Program Notes:-
//  =============

//  None.


// Generate SQL to remove SeqNo in main table.
  TDbiString sql;
  sql  << "delete from  " << fTableName
       << " where SEQNO = " << seqNo << ";"
       << '\0';

  SK_DBI_Verbose( "Database: " << dbNo
                        << " RemoveSeqNo SQL: " << sql.c_str() << "  ");

//  Apply query.
  auto_ptr<TDbiStatement> stmtDb(fCascader.CreateStatement(dbNo));
  if ( ! stmtDb.get() ) return false;
  if ( ! stmtDb->ExecuteUpdate(sql.c_str()) || stmtDb->PrintExceptions() ) {
       SK_DBI_Severe( "SQL: " << sql.c_str()
                           << " Failed. " << "  ");
    return false;
  }

// Generate SQL to remove SeqNo in validity table.
  sql.GetString().erase();
  sql << "delete from  " << fTableName
      << "VLD where SEQNO = " << seqNo << ";"
      << '\0';

  SK_DBI_Verbose( "Database: " << dbNo
                        << " RemoveSeqNo SQL: " << sql.c_str() << "  ");

//  Apply query.
  if (  ! stmtDb->ExecuteUpdate(sql.c_str()) ||  stmtDb->PrintExceptions() ) {
       SK_DBI_Severe( "SQL: " << sql.c_str()
                           << " Failed. " << "  ");
    return false;
  }

  return true;

}

Here is the call graph for this function:

Here is the caller graph for this function:

Bool_t TDbiDBProxy::ReplaceInsertDate	(	const TVldTimeStamp &	ts,
		UInt_t	SeqNo,
		UInt_t	dbNo
	)			const

Definition at line 640 of file TDbiDBProxy.cxx.

References TVldTimeStamp::AsString(), TDbiString::c_str(), TDbiCascader::CreateStatement(), fCascader, fTableName, SK_DBI_Severe, and SK_DBI_Verbose.

                                                       {
//
//
//  Purpose:  Replace insertion date for row in auxiliary table.
//
//  Arguments:
//    ts           in    Time stamp for new insertion date.
//    SeqNo        in    The sequence number of the row to be replaced.
//    dbNo         in    Database number in cascade (starting at 0).
//
//  Return:    kTRUE if output successful,otherwise kFALSE.
//
//  Contact:   N. West


// Generate SQL.
  TDbiString sql;
  sql << "update  " << fTableName
      << "VLD set INSERTDATE = \'" << ts.AsString("s")
      << "\' where SEQNO = " << SeqNo << ";"
      << '\0';

  SK_DBI_Verbose( "Database: " << dbNo
                        << " ReplaceInsertDate SQL: "
                        << sql.c_str() << "  ");

//  Apply query.
  auto_ptr<TDbiStatement> stmtDb(fCascader.CreateStatement(dbNo));
  if ( ! stmtDb.get() ) return false;
  if (! stmtDb->ExecuteUpdate(sql.c_str()) || stmtDb->PrintExceptions() ) {
       SK_DBI_Severe( "SQL: " << sql.c_str()
                           << " Failed. " << "  ");
    return false;
  }

  return true;

}

Here is the call graph for this function:

Bool_t TDbiDBProxy::ReplaceSeqNo	(	UInt_t	oldSeqNo,
		UInt_t	newSeqNo,
		UInt_t	dbNo
	)			const

Definition at line 682 of file TDbiDBProxy.cxx.

References TDbiString::c_str(), TDbiCascader::CreateStatement(), fCascader, fTableName, TDbiCascader::GetConnection(), TDbiString::GetString(), SK_DBI_Severe, SK_DBI_Verbose, and SK_DBI_Warn.

                                                   {
//
//
//  Purpose:  Replace sequence number in main and auxiliary tables.
//
//  Arguments:
//    oldSeqNo     in    The old sequence number.
//    nwSeqNo      in    The new sequence number.
//    dbNo         in    Database number in cascade (starting at 0).
//
//  Return:    kTRUE if output successful,otherwise kFALSE.
//
//  Contact:   N. West
//
//  Specification:-
//  =============
//
//  o Replace sequence number in main and auxiliary tables.

//  Program Notes:-
//  =============

//  None.

  if ( ! fCascader.GetConnection(dbNo) ) {
    SK_DBI_Warn(  "Cannot renumber " << oldSeqNo
       << " no connection to cascade entry " << dbNo << "  ");
    return false;
  }

// Generate SQL to replace SeqNo in validity table.
  TDbiString sql;
  sql << "update  " << fTableName
      << "VLD set SEQNO = " << newSeqNo
      << " where SEQNO = " << oldSeqNo << ";"
      << '\0';

  SK_DBI_Verbose( "Database: " << dbNo
                        << " ReplaceSeqNo SQL: " << sql.c_str() << "  ");

//  Apply query.
  auto_ptr<TDbiStatement> stmtDb(fCascader.CreateStatement(dbNo));
  if ( ! stmtDb.get() ) return false;
  if ( ! stmtDb->ExecuteUpdate(sql.c_str()) || stmtDb->PrintExceptions() ) {
       SK_DBI_Severe( "SQL: " << sql.c_str()
                           << " Failed. " << "  ");
    return false;
  }

// Generate SQL to replace SeqNo in main table.
  sql.GetString().erase();
  sql  << "update  " << fTableName
       << " set SEQNO = " << newSeqNo
       << " where SEQNO = " << oldSeqNo << ";"
       << '\0';

  SK_DBI_Verbose( "Database: " << dbNo
                        << " ReplaceSeqNo SQL: " << sql.c_str() << "  ");

//  Apply query.
  if ( ! stmtDb->ExecuteUpdate(sql.c_str()) || stmtDb->PrintExceptions() ) {
       SK_DBI_Severe( "SQL: " << sql.c_str()
                           << " Failed. " << "  ");
    return false;
  }

  return true;

}

Here is the call graph for this function:

void TDbiDBProxy::SetSqlCondition

(

const string &

sql

)

[inline]

Definition at line 114 of file TDbiDBProxy.hxx.

References fSqlCondition.

Referenced by TDbiTableProxy::SetSqlCondition().

                                                   {
                                                  fSqlCondition = sql; }

Here is the caller graph for this function:

void TDbiDBProxy::StoreMetaData

(

TDbiTableMetaData &

metaData

)

const

Definition at line 756 of file TDbiDBProxy.cxx.

References TDbiTableMetaData::Clear(), TDbiConnection::Connect(), TDbiConnection::DisConnect(), fCascader, TDbiCascader::GetConnection(), TDbiCascader::GetNumDb(), TDbiConnection::GetServer(), TDbiTableMetaData::SetColFieldType(), TDbiTableMetaData::SetColIsNullable(), TDbiTableMetaData::SetColName(), SK_DBI_Verbose, TDbiTableMetaData::TableName(), and UtilString::ToUpper().

Referenced by TDbiTableProxy::RefreshMetaData().

                                                                  {
//
//
//  Purpose:  Store table meta data.
//
//  Arguments:
//    metaData   in    Empty TDbiTableMetaData object apart from table name.



  const char* tableName = metaData.TableName().c_str();
  SK_DBI_Verbose( "Get meta-data for table: " << tableName << "  ");

//  Check each Db in turn until table found and store table meta data.

  for ( UInt_t dbNo = 0; dbNo < fCascader.GetNumDb(); dbNo++ ) {
    TDbiConnection* connection = fCascader.GetConnection(dbNo);
    TSQLServer* server = connection->GetServer();
    if ( ! server ) continue;
    connection->Connect();
    TSQLTableInfo* meta = server->GetTableInfo(tableName);
    if ( ! meta ) {
      connection->DisConnect();
      continue;
    }
    SK_DBI_Verbose( "Meta-data query succeeded on cascade entry " << dbNo << "  ");

    // Clear out any existing data, although there should not be any.
    metaData.Clear();

    const TList* cols =  meta->GetColumns();
    TIter colItr(cols);
    int col = 0;
    while ( TSQLColumnInfo* colInfo = dynamic_cast<TSQLColumnInfo*>(colItr.Next()) ) {

      ++col;
      string name(colInfo->GetName());
      name = UtilString::ToUpper(name);
      metaData.SetColName(name,col);

      TDbiFieldType fldType(colInfo->GetSQLType(),
                           colInfo->GetLength(),
                           colInfo->GetTypeName());

      // For now continue to check for unsigned (even though not supported)
      if ( !colInfo->IsSigned() ) fldType.SetUnsigned();
      metaData.SetColFieldType(fldType,col);

      metaData.SetColIsNullable(col,colInfo->IsNullable());

      SK_DBI_Verbose(  "Column "         << col << " " << name
           << " SQL type "      << colInfo->GetSQLType()
           << " SQL type name " << colInfo->GetTypeName()
           << " DBI type "      << fldType.AsString()
           << " data size: "    << fldType.GetSize()
           << " col size: "     << colInfo->GetLength() << "  ");

    }
    delete meta;
    connection->DisConnect();
    return;
  }
}

Here is the call graph for this function:

Here is the caller graph for this function:

Bool_t TDbiDBProxy::TableExists

(

Int_t

selectDbNo = -1

)

const

Definition at line 822 of file TDbiDBProxy.cxx.

References fCascader, fTableName, and TDbiCascader::TableExists().

Referenced by TDbiValidityRecBuilder::TDbiValidityRecBuilder().

                                                      {
//
//
//  Purpose:  Return true if table exists on selected cascade entry
//            or any entry if selectDbNo=-1 (default)


  return fCascader.TableExists(fTableName,selectDbNo);

}

Here is the call graph for this function:

Here is the caller graph for this function:

---

Member Data Documentation

TDbiCascader& TDbiDBProxy::fCascader [private]

Reference to one and only cascader.

Definition at line 127 of file TDbiDBProxy.hxx.

Referenced by FindTimeBoundaries(), GetNumDb(), QueryAllValidities(), QuerySeqNo(), QuerySeqNos(), QueryValidity(), RemoveSeqNo(), ReplaceInsertDate(), ReplaceSeqNo(), StoreMetaData(), and TableExists().

const TDbiTableMetaData* TDbiDBProxy::fMetaData [private]

Owned by TDbiTableProxy.

Definition at line 130 of file TDbiDBProxy.hxx.

Referenced by QuerySeqNo(), and QuerySeqNos().

const TDbiTableMetaData* TDbiDBProxy::fMetaValid [private]

Owned by TDbiTableProxy.

Definition at line 133 of file TDbiDBProxy.hxx.

Referenced by HasEpoch(), QueryAllValidities(), and QueryValidity().

string TDbiDBProxy::fSqlCondition [private]

Optional condition to be applied. See Usage Notes.

Definition at line 137 of file TDbiDBProxy.hxx.

Referenced by QueryAllValidities(), QueryValidity(), and SetSqlCondition().

string TDbiDBProxy::fTableName [private]

Table Name.

Definition at line 140 of file TDbiDBProxy.hxx.

Referenced by FindTimeBoundaries(), GetTableName(), QueryAllValidities(), QuerySeqNo(), QuerySeqNos(), QueryValidity(), RemoveSeqNo(), ReplaceInsertDate(), ReplaceSeqNo(), TableExists(), and ~TDbiDBProxy().

const TDbiTableProxy* TDbiDBProxy::fTableProxy [private]

Owning TDbiTableProxy.

Definition at line 143 of file TDbiDBProxy.hxx.

Referenced by GetTableProxy(), QueryAllValidities(), QuerySeqNo(), QuerySeqNos(), and QueryValidity().

---

The documentation for this class was generated from the following files:

• src/TDbiDBProxy.hxx
• src/TDbiDBProxy.cxx
